Averos Loris X2 Configuration Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Loris X2 Configuration Guide
Product Name
Rev #
Release date
Reference documents
Release summary
Loris X2
1.4
th
5
July, 2018
Loris X2 Quick Start Guide_1.0
This Guide provides necessary steps to Install and deploy Loris
X2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Loris X2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Averos Loris X2

  • Page 1 Loris X2 Configuration Guide Product Name Loris X2 Rev # Release date July, 2018 Reference documents Loris X2 Quick Start Guide_1.0 Release summary This Guide provides necessary steps to Install and deploy Loris...
  • Page 2 This Guide provides configuration of Loris X2 12-04-2018 Network setup 28-05-2018 Marks updated; Hardware Description added 05-07-2018 Breakdown of Raw data added 25-04-2019 Updated Loris X2 configuring Wi-Fi as WAN method Updated formatting of document Added IP Scanning software Ver 1.4 Page 0 | 30...

  • Page 3: Table Of Contents

    POE Injector with Wi-Fi ......................... 7 Active Passive POE selection (Optional) ....................8 Device Status ............................10 Loris X2 Configuration ......................... 11 5.1. Finding Loris X2 IP Address ......................11 5.2. Enabling WIFI for Configuration (Optional) ................13 5.3. MQTT Configuration ........................15 5.4.
  • Page 4 Figure 9 Loris X2 MAC Address ........................11 Figure 10 Advance IP Scanner Home Screen ....................11 Figure 11 Loris X2 IP Address using Advance IP Scanner ................12 Figure 12 Loris X2 Configuration Page ......................12 Figure 13 Loris X2 Enabling Wi-Fi ........................ 13 Figure 14 Loris X2 Wi-Fi button timings ......................
  • Page 5 This document contains proprietary information and is not intended for public distribution. All information within this document is the property of Averos, unless otherwise stated. All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of Averos Ver 1.4...

  • Page 6: Introduction

    1.1. Hardware Description 1) Reset Button 2) Power LED 3) Status LED 4) POE Port 5) Wall Mount bracket 6) Serial Sticker Figure 1 Loris X2 Front View Figure 2 Loris X2 Back View Ver 1.4 Page 4 | 30...

  • Page 7: Required Software

    Loris X2 Configuration Guide 1.2. Required Software Please download (No need to install): Software Name Version Download link MQTT Fx http://www.jensd.de/apps/mqttfx/1.7.1/mqttfx-1.7.1-windows-x64.exe Advance IP Scanner https://www.advanced-ip-scanner.com/ Ver 1.4 Page 5 | 30...

  • Page 8: Hardware Installation

    Loris X2 Configuration Guide Hardware Installation 2.1. POE Injector Figure 3 Loris X2 Wiring using LAN 2.2. POE Switch Figure 4 Loris X2 Wiring using POE Ver 1.4 Page 6 | 30...

  • Page 9: Poe Injector With Wi-Fi

    Loris X2 Configuration Guide 2.3. POE Injector with Wi-Fi Figure 5 Loris X2 Wiring using Wi-Fi Ver 1.4 Page 7 | 30...

  • Page 10: Active Passive Poe Selection (Optional)

    Active Passive POE selection (Optional) By default, the Loris X2 is ship in Passive POE mode. Although most of the Active POE switch support the mode but it is recommended to switch Loris X2 in Active POE mode when using Active POE switch.

  • Page 11: Figure 8 Loris X2 Active Poe Configuration

    Loris X2 Configuration Guide 3. After successful insertion of jumper your Loris X2 board will be as follows Figure 8 Loris X2 Active POE Configuration Ver 1.4 Page 9 | 30...

  • Page 12: Device Status

    Device Status After 2 to 5 seconds Loris X2 Power LED will turn ON, indicating that device is now booting up. Now wait for 1 to 2 minutes until the device gets boots up. Following is the status of device with respect to status LED on Loris X2.

  • Page 13: Loris X2 Configuration

    Loris X2 Configuration 5.1. Finding Loris X2 IP Address 1. Note down your Loris X2 MAC Address. MAC Address of Loris X2 is written at the back of device Figure 9 Loris X2 MAC Address 2. Open Advanced IP scanner Software 3.

  • Page 14: Figure 11 Loris X2 Ip Address Using Advance Ip Scanner

    Loris X2 Configuration Guide 4. After successful scan, you find your Loris X2 IP Address as per your MAC Address Figure 11 Loris X2 IP Address using Advance IP Scanner 5. Now open Loris X2 Configuration page by typing the IP address in your browser Figure 12 Loris X2 Configuration Page Ver 1.4...

  • Page 15: Enabling Wifi For Configuration (Optional)

    After this LED will blink in the same format as in Error! Reference source not found.. LED blink indicate WiFi SSID is turned ON. Figure 13 Loris X2 Enabling Wi-Fi Figure 14 Loris X2 Wi-Fi button timings Ver 1.4 Page 13 | 30...

  • Page 16: Figure 15 Loris X2 Wi-Fi Settings Information

    Loris X2 Configuration Guide 2. Connect to Loris X2 Wi-Fi. You can find the SSID and Password from the back of Device. Figure 15 Loris X2 Wi-Fi Settings Information 3. After successful connection open Google chrome browser and open the configuration page by opening “192.168.100.1”...

  • Page 17: Mqtt Configuration

    MQTT Server Port: Default port is 1833. Change as per requirements • Keep Alive Timeout : Keep alive packet • MQTT Topic: Topic on which data will be posted Figure 17 Loris X2 MQTT Configuration Ver 1.4 Page 15 | 30...

  • Page 18: Ble Configuration

    Loris X2 Configuration Guide 5.4. BLE Configuration 1. Click on “System Settings” and then Click on “Device Settings” 2. Change the Settings as per requirements. Figure 18 Loris X2 BLE Configuration Ver 1.4 Page 16 | 30...

  • Page 19: Network Configuration Using Static Ip (Optional)

    Loris X2 Configuration Guide 5.5. Network Configuration using Static IP (Optional) By default DHCP is enabled in Loris X2. If static IP is required then follow the following steps: 1. Click “Network” 2. Then click “Configuration”. Figure 19 Network Configuration selection 3.

  • Page 20: Figure 21 Static Ip Selection

    Loris X2 Configuration Guide 4. Change the “Protocol” to “Static address“. Figure 21 Static IP Selection 5. Enter the IP Address in “IPv4 Address”. 6. Select the Subnet Mask in “IPv4 netmask” dropdown box. 7. Enter the Gateway IP in “IPv4 gateway”.

  • Page 21: Using Wi-Fi As Wan (Optional)

    Loris X2 Configuration Guide 5.6. Using Wi-Fi as WAN (Optional) Prerequisite • Make sure that apply te following settings by using IP Address provided by Advance IP Scanner in the Section 5.1. 1. Click “Network” then click “Wifi Settings” Figure 23 Configuring Wi-Fi Settings 2.

  • Page 22: Figure 25 Wi-Fi Network Settings

    Loris X2 Configuration Guide 3. Enter “SSID” of the Wireless network this Loris X2 will connect to. 4. Enter “BSSID” of the Wireless network this Loris X2 will connect to 5. Then select “wan” as the network. Figure 25 Wi-Fi Network Settings Ver 1.4...

  • Page 23: Figure 26 Wi-Fi Network Settings

    Loris X2 Configuration Guide 6. Click “Wireless Security” 7. Then select the encryption type 8. Enter the Security key. 9. Click on “save” when done. 10. After saving click on “enable” Figure 26 Wi-Fi Network Settings 11. Click “Network” 12. Then click “Configuration”.

  • Page 24: Figure 28 Editing Wan Network Configuration

    Loris X2 Configuration Guide 13. Click “Edit” on “WAN” network. Figure 28 Editing WAN Network Configuration 14. Click “Physical Settings” 15. Then select “Wireless Network: Client”. 16. When done click on “LAN” Figure 29 WAN Network Settings Ver 1.4 Page 22 | 30...

  • Page 25: Figure 30 Lan Settings

    Loris X2 Configuration Guide 17. Click on “Physical Settings” 18. Then select “Creates a bridge over specified interface(s)”. 19. Select “Ethernet Switch: eth0” 20. Select “Ethernet Adapter: ra0” 21. Select “Wireless Network: Master”. Figure 30 LAN Settings 22. When done click “Save and Apply”.

  • Page 26: System Reboot

    Loris X2 Configuration Guide 5.7. System Reboot 1. Click on “System Settings” and then click on “Reboot”. Figure 32 Rebooting Loris X2 2. Now click on perform Reboot link. Figure 33 Reboot Confirmation Ver 1.4 Page 24 | 30...

  • Page 27: Testing

    Prerequisite • Make sure that your MQTT Broker is working or use any public MQTT broker. • Configure Loris X2 on the same MQTT Broker. • Download and install the software MQTT.fx for testing: (Link: http://www.jensd.de/apps/mqttfx/1.3.1/mqttfx-1.3.1-windows-x64.exe 6.1. Setting up MQTT Configuration 1.

  • Page 28: Figure 35 Mqtt Brooker Addition

    Loris X2 Configuration Guide 4. Insert Profile Name: Testing 5. Broker Address: broker.mqttdashboard.com 6. Client ID: Click on Generate Button and then software will generate a random Client ID 7. Click on Save Figure 35 MQTT Brooker Addition 8. Click on Connect Button Figure 36 Connect Ver 1.4...

  • Page 29: Mqtt Topic Settings

    3. Click on Subscribe button Figure 37 MQTT Topic settings 4. After subscription, you will start receiving Beacons streams from Loris X2. The Stream of beacon is visible on the bottom right window of the software Figure 38 BLE Beacon Live Stream Ver 1.4...

  • Page 30: Packet Format

    Loris X2 Configuration Guide Packet Format The packet format for the beacon stream received by Loris X2 Gateway through MQTT is in following format: Packet Body (JSON "id":"< device WAN MAC>", "v":"< FW Ver. >", "mid":< Message ID >, "raw_beacons_data":"{ <...
