- Page 1 Tornado PROFESSIONAL SANITIZATION MACHINES USE AND MAINTENANCE MANUAL ORIGINAL INSTRUCTION DOC. 10098249 - Ver. AA - 05-2020...
-
Page 3: Table Of Contents
CONTENTS CONTENTS ...........................3 GENERAL SAFETY REGULATIONS ...................4 MACHINE WITH CONNECTION TO THE ELECTRICITY GRID ................4 BATTERY-POWERED MACHINE ..........................6 USING THE MACHINE ............................7 DEACTIVATION OF THE MACHINE ........................9 MAINTENANCE ..............................10 TRANSPORT ................................. 11 LOCATION OF THE MAIN MACHINE COMPONENTS .............12 GENERAL DESCRIPTION ......................12 DEFINITION OF LEVELS OF WARNING ...................... -
Page 4: General Safety Regulations
GENERAL SAFETY REGULATIONS The following symbols are used to indicate any potentially hazardous situations. Always read this information carefully and take the necessary precautions to protect any people and/or objects that may be present. Operator cooperation is paramount for accident prevention. No accident directly responsible for the machine's operation. - Page 5 equal to that shown on the serial number plate. • The power supply cable outlet must have an earth connection in compliance with the regulatory standards. • If the machine packaging contains the cable to connect to the mains supply, it should only be used for the above-mentioned machine.
-
Page 6: Battery-Powered Machine
EXTENSION CABLE (electrical versions) WARNING: • Only use the materials expressly recommended by a service technician as cable extensions (contact an authorized retailer) or else high quality models. When using an extension, respect its minimum cross-section. BATTERY-POWERED MACHINE DANGER: • In case of danger, act promptly, moving the main switch to position “0”. WARNING: •... -
Page 7: Using The Machine
RECHARGING THE BATTERIES (battery-powered versions) DANGER: • If the battery charger power cable is damaged or broken, it should be replaced by the charger manufacturer or authorized service personnel, or by another • The socket for the battery charger cable must have a prescribed earth connection. - Page 8 USING THE MACHINE DANGER: • The nebulized product must never be directed towards equipment containing electrical components. • If the machine is used in dangerous areas (e.g. petrol stations), the relative safety standards must be observed. It is forbidden to use the machine in environments with a potentially explosive atmosphere.
-
Page 9: Deactivation Of The Machine
ATTENTION: • Children must be supervised to ensure they do not play with the machine. • During the working of the machine, pay attention to other people and especially to children. • Read the labels on the machine carefully. Do not cover them for any reason, and replace them immediately if they become damaged. -
Page 10: Maintenance
• • If the machine is left unattended, it must be protected from any accidental movements. • electrical versions, you must also disconnect the power cable from the mains socket. ATTENTION: • The machine must only be stored in temperatures ranging from +10 °C to +40 °C. -
Page 11: Transport
ATTENTION: • Block the wheels before lifting the machine. • Lift the machine with equipment that can sustain the weight to be lifted. • follow the supplied routine maintenance instructions scrupulously. • If any parts need to be replaced, always request ORIGINAL spare parts from an authorized Dealer or Retailer. -
Page 12: Location Of The Main Machine Components
LOCATION OF THE MAIN MACHINE COMPONENTS The machine's main components are the following: 6. Battery charger display (battery-powered versions). 7. Battery charger power socket (battery-powered versions). 1. Control handlebars. 8. Pivoting front wheel with parking brake. 2. Sanitizing solution tank lid. 9. -
Page 13: Purpose And Content Of The Manual
The aim of this manual is to provide customers with all the information needed to use the machine in the safest, most appropriate and most autonomous way. This includes information concerning technical aspects, safety, operation, downtime, maintenance, spare parts and machine. If in doubt about the correct interpretation of instructions, contact your nearest TMB Customer Service Center to obtain the necessary TARGET GROUP... -
Page 14: Safety
SERIAL NUMBER PLATE The serial number plate is located at the rear of the machine, and indicates the general characteristics thereof, always be provided together with any request for assistance or when purchasing spare parts. TECHNICAL DATA Tornado Tornado Tornado TECHNICAL DATA... -
Page 15: Labels Used On The Machine
LABELS USED ON THE MACHINE Label indicating the need to read the Use and Maintenance Manual: Applied in the vicinity of the steering column in order to remind the operator to read the user and maintenance manual before using the machine. ATTENTION! -120 volt): Used on the machine to warn the operator that there is a danger of electrocution with a voltage from 110-120 volt. -
Page 16: How To Move The Machine
HOW TO MOVE THE MACHINE To transport the machine safely, proceed as follows: DANGER: before starting any task, make sure the current regulations concerning the safe transport of dangerous substances are scrupulously observed. 1. Check that the sanitizing solution tank is empty, otherwise empty it. ATTENTION: It is recommended to wear the appropriate PPE (Personal Protective Equipment), suitable for the work to be carried out. -
Page 17: Connecting The Batteries To The Machine's Electrical System (Battery-Powered Versions)
The various phases for inserting the batteries in the battery compartment are as follows: 1. Carry out the steps necessary to secure the machine, see paragraph “MACHINE SAFETY” on page 16. 2. Go to the front of the machine and remove the cap (4) from the tank ( 3. -
Page 18: Filling The Sanitizing Product Tank
2. Carry out the steps necessary to secure the machine (see paragraph “MACHINE SAFETY” on page 16). ATTENTION: malfunction of the device. Carefully read the use and maintenance instructions of the battery charger that is used for charging, this document is delivered along with the machine. -
Page 19: Starting Work
STARTING WORK To start working, proceed as follows: 1. Make all the checks listed in “PREPARING TO WORK”. 2. Go to the rear of the machine and switch it on, turning the main switch (1) to position “I” ( 3. Remove the spray gun from the holder. 5. -
Page 20: At The End Of The Work
AT THE END OF THE WORK At the end of the work, and before carrying out any type of maintenance, perform the following operations: 3. For electrical versions, disconnect the plug (3) of the power cable from the mains supply socket ( CAUTION: We recommend handling the power cable with dry hands to avoid serious injury. -
Page 21: Cleaning The Nebulizer System
CLEANING THE NEBULIZER SYSTEM To clean the nebulizer system, proceed as follows: 1. Go to the front of the machine and remove the cap (1) from the tank ( 2. Remove the plastic chassis (2) of the machine ( The equipment needed for removing the bolts is not included with the machine. 4. -
Page 22: Troubleshooting
TROUBLESHOOTING This chapter lists the most common problems linked with the use of the machine. If you are unable to resolve the problems with the information given here, please contact your nearest assistance center. PROBLEM POSSIBLE CAUSE SOLUTION THE MACHINE “I”. -
Page 23: Ec Declaration Of Conformity
EC DECLARATION OF CONFORMITY The undersigned company: Via Cà Nova Zampieri, 5 37057 San Giovanni Lupatoto (VR) declares under its sole responsibility that the products Tornado B comply with the requirements of the following Directives: • 2006/42/EC: Machinery Directive. •... - Page 24 The undersigned company: Via Cà Nova Zampieri, 5 37057 San Giovanni Lupatoto (VR) declares under its sole responsibility that the products Tornado 230V 50Hz - Tornado 110V 60Hz comply with the requirements of the following Directives: • 2006/42/EC: Machinery Directive.
