Summary of Contents for SteelMax BM-7
- Page 1 The tools of innovation. OPERATOR’S MANUAL BEVELING MACHINE 15335 E. Fremont Drive, Centennial, CO 80112 1– 87STEELMAX, FAX 303 – 690 – 9172 www.steelmax.com sales@steelmax.com...
-
Page 2: Table Of Contents
Contents 1. GENERAL INFORMATION ....................3 1.1. Application ......................... 3 1.2. Technical data......................3 1.3. Equipment included ....................4 1.4. Dimensions ........................ 5 1.5. Design ........................6 2. SAFETY PRECAUTIONS ....................7 3. STARTUP AND OPERATION ................... 9 3.1. Installing and removing the cutting inserts ..............9 3.2. -
Page 3: General Information
BM-7 1. GENERAL INFORMATION 1.1. Application The BM-7 is a beveling machine designed to bevel plates and pipes made of steel or aluminum alloys. Depending on the milling head, the machine allows you to bevel at the angle of °... -
Page 4: Equipment Included
Ø35 mm roller, without cutting inserts) 2 Plastic box 1 unit 3 Special flat wrench 1 unit 4 Grease for screws 5 g (0.2 oz) 1 unit 5 Torx T15 screwdriver 1 unit – Operator’s Manual 1 unit BM-7 Operator’s Manual... -
Page 5: Dimensions
BM-7 1.4. Dimensions 339 mm (13-11/32″) 135 mm (5-5/16″) BM-7 Operator’s Manual... -
Page 6: Design
BM-7 1.5. Design Switch lock Handle ON/OFF switch Clamping screw Sleeve Guide 45° milling head with Ø35 mm roller BM-7 Operator’s Manual... -
Page 7: Safety Precautions
19. After each use, clean the machine and the milling head with a dry cotton cloth and no chemical agents. Do not remove chips with bare hands. 20. Maintain the machine and install/remove parts and tools only after you unplug the machine from the power source. BM-7 Operator’s Manual... - Page 8 23. If you are not going to use the machine, remove it from the work area and keep it in a safe and dry place. 24. If you are not going to use the machine for an extended period, put anti-corrosion material on the steel parts. BM-7 Operator’s Manual...
-
Page 9: Startup And Operation
If all cutting edges are worn, install new inserts. Make sure that the bottom of each insert is in full contact with the socket (5). CORRECT INCORRECT Each week clean the threads of the mounting screws for inserts and put the supplied grease on the threads. BM-7 Operator’s Manual... -
Page 10: Installing And Removing The Milling Head
BM-7 3.2. Installing and removing the milling head Unplug the power cord. To remove the milling head, continue in the sequence that follows. BM-7 Operator’s Manual... - Page 11 BM-7 To install the milling head, continue in the sequence that follows. BM-7 Operator’s Manual...
-
Page 12: Adjusting The Bevel Width
(1) on the height of the end of the cutting edge (2). You can also use an optional radius insert positioner to set the guide correctly. Tighten the screw. Bevel a test edge, and if necessary adjust the position of the guide again. BM-7 Operator’s Manual... -
Page 13: Operating
After the work is finished, release the ON/OFF switch to turn off the motor. Then, wait until the rotation stops, and unplug the power cord. Clean the machine with a dry cotton cloth and no chemical agents. BM-7 Operator’s Manual... -
Page 14: Replacing The Brushes
To install, continue in reverse order. Make sure to put the terminal of the brush wire (5) between the washer (6) and the terminal of the motor wire (7). Then, let the motor operate with no load for 20 minutes. BM-7 Operator’s Manual... -
Page 15: Accessories
Next, put the positioner from the top (1) so that the edge marked with a given radius is aligned with the edges of three cutting inserts with the same radius (2). Turn the sleeve (3) until the guide is in contact with the positioner (4). BM-7 Operator’s Manual... -
Page 16: Anti-Scratch Guide Sticker
R5 cutting insert (sold per 10 in a set); only for GLW-0540-08-00-00-0 45° milling head (includes: Ø22.5 mm roller, mounting screws for inserts; GLW-0540-16-00-00-0 3 cutting inserts required) PLY-000282 Cutting insert (sold per 10 in a set) for GLW-0540-16-00-00-0 BM-7 Operator’s Manual... -
Page 17: Spare And Wearing Parts
Mounting screw for insert SRB-000289 for GLW-0540-08-00-00-0 and GLW-0540-09-00-00-0 SRB-000311 Mounting screw for insert for GLW-0540-16-00-00-0 WKT-000005 T15P screwdriver for mounting screws SMR-000005 Grease for mounting screws (5 g, 0.17 oz) SCZ-000009 Carbon brush 115 V / 230 V BM-7 Operator’s Manual... -
Page 18: Wiring Diagram
BM-7 6. WIRING DIAGRAM BM-7 Operator’s Manual... -
Page 19: Declaration Of Conformity
7. DECLARATION OF CONFORMITY Declaration of Conformity PROMOTECH sp. z o.o. ul. Elewatorska 23/1 15-620 Białystok Poland We declare with full responsibility that: BM-7 Beveling Machine is manufactured in accordance with the following standards: • EN 60745-1 • EN 55014 •... -
Page 20: Exploded Drawings And Parts List
BM-7 8. EXPLODED DRAWINGS AND PARTS LIST ITEM PART NUMBER DESCRIPTION Q-TY WKT-000005 T15P TORX PLUS SCREWDRIVER KLC-0540-07-00-00-0 SPECIAL FLAT WRENCH SMR-000005 GREASE FOR SCREWS SKR-000012 PLASTIC BOX BM-7 Operator’s Manual... - Page 21 BM-7 BM-7 Operator’s Manual...
- Page 22 HEX SOCKET BUTTON HEAD SCREW M6x12 PDK-000046 SPRING WASHER 6.1 UCW-0540-06-00-00-0 HANDLE ASSY USZ-0279-02-07-00-0 SEAL PSZ-0540-05-00-00-0 WIRE COVER RKJ-000066 MOTOR HANDLE WKR-000449 HEX SOCKET ROUND HEAD SCREW WITH FLANGE M5x16 WKR-000421 CROSS RECESSED OVAL PAN HEAD SCREW FOR PLASTIC 4x25 BM-7 Operator’s Manual...
- Page 23 ROTOR ASSY 230V WRN-0540-11-01-00-1 ROTOR ASSY 120V LOZ-000095 BALL BEARING 7x22x7 PRS-000022 INTERNAL RETAINING RING 32w LOZ-000086 BALL BEARING 12x32x10 USZ-0540-11-03-00-0 BEARING COVER PDK-0540-11-02-00-0 WASHER KRP-0540-01-01-00-1 BODY ASSY PRS-000018 INTERNAL RETAINING RING 28w SMR-000003 GREASE 0.05 kg BM-7 Operator’s Manual...
-
Page 24: Warranty Card
WARRANTY CARD No..................in the name of Manufacturer warrants the BM-7 Beveling Machine to be free of defects in material and workmanship under normal use for a period of 12 months from the date of sale. This warranty does not cover cutting inserts as well as damage or wear that arise from misuse, accident, tempering, or any other causes not related to defects in workmanship or material.
