HJH office PROVIDER Assembly Instructions

Advertisement

Aufbau
A Stecken Sie die Hebel auf die Mechanik.
B Montieren Sie die Mechanik an der Sitzflä-
che.
C Montieren Sie die Rückenlehne am Sitz.
D Drücken Sie je eine Stuhlrolle in die fünf
Öffnungen des Fußkreuzes. Stecken Sie die
Gasfeder mittig in das Fußkreuz.
E Setzen Sie das Sitzteil auf die Gasdruckfeder.
Stecken Sie nun die Plastikabdeckung auf
das hintere Ende der Mechanik.
F Setzen Sie sich nun mehrmals auf den Stuhl,
damit die Verbindung zwischen Sitz, Gas-
feder und Fuß gefestigt wird. Anschließend
können Sie die Gasfeder bedienen und die
Stuhlhöhe individuell einstellen.
#
Bezeichnung
Stück
1
Rückenlehne
1x
2
Sitzteil
1x
3
Mechanik
1x
4
Hebel
2x
5
Gasfeder
1x
6
Fußkreuz
1x
7
Rollen
5x
8
Schraube 8x35mm
2x
9
Schraube 8x25mm
2x
10
Schraube 8x20mm
4x
11
Beilagscheibe M8
8x
12
Inbusschlüssel
1x
Assembly
A Fix the levers onto the mechanism.
B Mount the mechanism onto the seat.
C Mount the backrest onto the seat.
D Insert the five castors into designated holes
at the bottom of the 5-star base. Insert the
gaslift into the center of the base.
E Place the seat onto the gaslift and fix the
plastic-cover onto the back end of the me-
chanik.
F Repeatedly sit onto the chair, so that the
connections between the seat, gaslift and
foot tighten. Now you can adjust the chair to
your individual needs.
#
Part
Count
1
Backrest
1x
2
Seat
1x
3
Mechanism
1x
4
Lever
2x
5
Gaslift
1x
6
Base
1x
7
Castor
5x
8
Screw 8x35mm
2x
9
Screw 8x25mm
2x
10
Screw 8x20mm
4x
11
Washer M8
8x
12
Allen wrench
1x
PROVIDER
Aufbauanleitung
Assembly instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PROVIDER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for HJH office PROVIDER

  • Page 1 E Setzen Sie das Sitzteil auf die Gasdruckfeder. plastic-cover onto the back end of the me- Stecken Sie nun die Plastikabdeckung auf chanik. PROVIDER das hintere Ende der Mechanik. F Repeatedly sit onto the chair, so that the F Setzen Sie sich nun mehrmals auf den Stuhl,...
  • Page 2 Hinweis / Remark Packen Sie zunächst alle Teile der Lieferung aus und prüfen Sie diese auf eventuelle Transportschäden. Um einen leichten Aufbau zu gewährleisten, empfehlen wir alle Schrauben nur leicht anzuziehen. Erst nach- dem alle Schrauben in das jeweilige Gewinde einge- führt wurden sollten diese fest angezogen werden.
