Primrose 3x10m Instructions Manual

Instructions for all 3m width marquees

Advertisement

Quick Links

Instructions for all 3m width marquees
Thank you for purchasing a Primrose Marquee. We hope you will be very satisfied
with your purchase.
These instructions should tell you all you need to know in order to put the marquee
up. If you would like to see a video of Primrose staff erecting one of our marquees
please visit our website at www.marqueesandpartytents.co.uk
In addition if you have any questions or need any help please do not hesitate to call
us or email us.
Checking your purchase
Please check your marquee well in advance of your event. We have a high level of
quality control at our warehouse and all components are checked before they are
sent out. However, we do use third party couriers and it is possible that one box
may not be delivered to you – in this case we can replace it as long as we have
enough time to do so.
First check you have the correct number of boxes (see parts list).
If you haven't received the correct number of boxes please contact us as soon as
possible.
Please open the boxes and check the contents.
www.marqueesandpartytents.co.uk
Customer Services
0118 945 9999

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3x10m and is the answer not in the manual?

Questions and answers

Summary of Contents for Primrose 3x10m

  • Page 1 These instructions should tell you all you need to know in order to put the marquee up. If you would like to see a video of Primrose staff erecting one of our marquees please visit our website at www.marqueesandpartytents.co.uk In addition if you have any questions or need any help please do not hesitate to call us or email us.
  • Page 3 WARNING! 1. Please take care not to force the poles and joints together when erecting the frame as damage may occur to the paintwork and destroy the weatherproofing. 2. Marquees are temporary structures and are not suitable for long-term use. It is particularly important not to use your marquee in strong winds, heavy snow or extreme weather.
  • Page 4 ASSEMBLING YOUR MARQUEE Step 1 – The roof frame Requires the following parts (please refer to parts list): Part 1 – 1590mm galvanized pipe Part 2 – 1940mm galvanized pipe Part 4 – 120° 3 way connector Part 5 – 120° 4 way connector Part 12 –...
  • Page 5 The number of central apexes that you will have to construct depends on the size of your marquee: Marquee Size Number of Central Apexes 3m x 10m 3m x 8m 3m x 6m 3m x 4m Unlike the two end apexes that you have just constructed, these middle frames will not lay flat on the ground.
  • Page 6 Step 2 – The roof canopy The roof fabric is heavy, we recommend unrolling it onto the frame before inserting the legs. Requires the following part: Part 14 - Roof This part of the assembly process is easier with 3 people for any marquee over 8m long.
  • Page 7 Step 3 –Attaching the legs Requires the following parts: Part 3 – 1920mm galvanised pipe Part 6 – Foot plate (If you are not fitting the optional ground bar kit) Part G2 – Corner ground plate (If you are fitting the optional ground bar kit) Part G3 –...
  • Page 8 d) Repeat the whole process from part b), attaching the legs to the other side of the marquee. On a windy day, anchor the marquee down at this point using the corner ropes / storm straps (please refer to steps 6/7 below).
  • Page 9 Step 4 – Inserting the ground bar kit (optional) If you have purchased our optional ground bar kit, now is the time to fit the bars. Requires the following parts: Part G1 - 1940mm galvanised pipe Part G1b - 1430mm galvanised pipe Part G4 - 2 Way ground plate Part G5 - Screws The number of G1 pipes running along each 'window' side depends on the size of the marquee,...
  • Page 10 Step 5 – Attaching the walls and doors Requires the following parts: Part 15 - Side wall with windows Part 16 - End wall with doors Part 10 - Bungees Part 13 - Hooks Parts 9 and 8 - Pegs (soft ground only) Please note - the side walls have windows and the end walls have doors.
  • Page 11 b) Fix leg covers Once all of the walls and doors have been hung, fix the leg covers in place using the Velcro ties and hooks (part 13) c) Pegging in Pegs can only be used on soft ground such as grass or turf. Use the large pegs (part 8) to secure the feet and small pegs (part 9) to secure the fabric to the ground.
  • Page 12 Step 6 – Fitting corner ropes (optional) Requires the following parts: CR1 - Corner ropes CR2 - Spiral pegs Use one rope on each corner of the marquee. Tie a knot in one end of the rope and feed through the corner eyelet from underneath upward. Pull the rope through until the knot prevents the rope from pulling through any further.
  • Page 13 Next screw the peg into the ground in an appropriate position. Feed the strap to the outside of the marquee. Then attach the tensioner. First feed the strap through the tensioner as shown below. Next pull the strap through so that it is a little longer than you require. Secure the strap to the ground by pushing the peg through the metal hook.
  • Page 14 Marquee Parts List Number of Boxes: 3x10m 3 x 8m 3x 6m 3 x 4m quantity quantity quantity quantity Marquee Ground Bar Kit (optional) Tie down kit (optional) Parts List: Part Part Name Diagram 3 x 10m 3 x 8m...
  • Page 15 Side walls End walls Ground Bar Kit: Pipe 1940mm Pipe 1430mm Corner ground plate 3 Way ground plate (sides of marquee) 2 Way ground plate (ends of marquee) Screw Tie Down Kit: Strap...
