ViziT -TU41 Series Quick Start Manual

Concierge terminal VIZIT-TK401D (the terminal) and control unit VIZIT-TU41x are parts of Concierge
Console VIZIT-PKxxx, intended for operation in VIZIT doorphones.
Intercom "Visitor - Subscriber / Abonent" (V
Intercom "Visitor - Concierge" (V
Intercom "Concierge - Visitor", (C
Intercom "Concierge - Subscriber" (C
Intercom "Subscriber - Concierge" (A
Indication of busy / free line
Calls transferring from the doorstation to concierge*
Calls transferring from the concierge to subscriber*
Redialing of the last number
Indication of operating modes, clock and calendar
Messages: English, Russian *
Speakerphone
Saving of all settings and clock in case of power failure
* - This feature is programmable in VIZIT-TU41x control unit setup.

SPECIFICATIONS

Input voltage, VDC
Power consumption, Wmax
Dimensions, mm
Weight, kg
Operating conditions:
- Ambient temperature range
- Relative humidity of air
The terminal does not contain voltage above 18 VDC.
To avoid damage do not make any connections or repair when the power is on.
The product shall not be exposed to dripping or splashing and no objects filled with liquids
shall be placed on the product.
Place the terminal on a table or fix it on a wall. The terminal mounting dimensions are given on Figure 2.
1. Install two AA batteries into the battery compartment on the terminal bottom. Observe polarity.
Batteries keep the clock and calendar running (without indication) when the power is off.
2. Connect the handset to the terminal using the cable supplied.
3. Connect the terminal to the mounting box KC-101 using the cable supplied.
4. Connect KC-101 to the control unit VIZIT-TU41x according to its operating instruction.
Concierge Console operation is given in VIZIT-TU41x operating instruction.

FEATURES

A)
C)
V) concierge-initiated
A)
C)
17
1.5
220x145x75
0.6
+1°C ... + 40°C
up to 93% at 25°C

SAFETY INSTRUCTIONS

INSTALLATION

PARTS LIST

Concierge terminal VIZIT-TK401D
Connecting box KC-101
Operating instruction
Mounting kit
Package
VIZIT-TK401D
1 pc.
1 pc.
1 pc.
1 pc.
1 pc.
