Summary of Contents for Am TAP PAP CS

Page 1 TAP PAP CS Instructions...
Page 2 Intended Use The TAP PAP CS is designed to connect the TAP 3 or TAP 3 Elite oral appliance to the TAP PAP Nasal Pillow Mask to provide combination Oral Appliance and CPAP/Bi-level therapy. It is for single patient use in the home, hospital, sleep lab or other clinical setting.
Page 3 Parts and Tools for the TAP PAP CS Connector TAP PAP NPM CS Attachment Front Plate with Post Items that are included with the CS Connector but are not pictured: • Short Hex Key • Long Hex Key Items that are not included with the CS Connector but will be needed for full assembly of the TAP PAP CS.
Page 4 Assembling the TAP PAP CS Front Plate with Post to TAP 3 or 3 Elite Upper Appliance Be sure to have your TAP 3/3 Remove the TAP 3 or 3 Elite Remove the Front Plate, Elite Appliance, your TAP PAP Front Plate by removing the 2 leaving the hook attached.
Page 5 Attach the Front Plate with Using the Locking Screws Post onto the TAP 3 or 3 Elite you removed from the TAP 3 or (where you removed the Front 3 Elite in Step 2, secure the front Plate from) plate with Post to the TAP 3 Elite NOTE: Be sure the Front Plate Upper Appliance.
Page 6 Assembling the TAP PAP CS to the TAP PAP Nasal Pillow Mask 2. Continued Slide the TAP PAP Nasal Insert the Nut and Screw into Pillow Mask onto the TAP PAP the TAP PAP CS and TAP PAP Nasal Pillow Mask.
Page 7 Insert the Front Plate with Once the Front Plate with Your TAP PAP CS is fully Post (attached to the TAP 3 Elite Post is attached to the TAP PAP assembled. Refer to the Appliance) into the TAP PAP CS...
Page 8 AIRWAY MANAGEMENT 3418 Midcourt Road Suite 114 Carrollton, TX 75006 866.264.7667 AMISLEEP.COM facebook.com/airwaymanagement TAP, myTAP, TAP PAP THEMRACRYL are trademarks of Airway Technologies, LLC, registered in the U.S. and other countries. All rights reserved. 70015 REV A...
