VANTAGECONTROLS.COM
1061 South 800 East · Orem, Utah 84097 · Telephone 801 229 2800 · Fax 801 224 0355
Manufacturer:
NuVo
Model Number/s:
P3500
Driver Version:
Vantage AV Object
DC Version:
v. 3.2.0.37
I.Overview
As part of its Premier Partner Program, Vantage Equinox products support the NuVo P3500, P3100, P200 and P300. After setting up
the NuVo in Design Center, the Equinox audio widget user interface automatically appears in the EQ41 and EQ73 in-wall touch
screens and on mobile devices installed with the Equinox App (available for iPhones, iPads, iPods, and Android products).
II. Features Supported / Not Supported
Feature
Zone Power/Mute
Zone power toggles mute state
Zone Volume
+/- buttons, Slider Visibility
Transport Commands
Play, Pause, Skip Next, Skip Previous
Source Selection
Swipe to streaming service, line-in, Bluetooth
Metadata
EQ40 - Limited Text; EQ41, EQ73 & EQApp - Full Cover art
Music Library (iTunes, Windows Media, NAS)
EQ40 - Cycle Playlists; EQ41, EQ73 & EQApp - Navigate/Play Albums, Artists, Genres,
Playlists
Pandora
EQ40 - Cycle Channels; EQ41, EQ73 & EQApp - Navigate/Play Configured Channels
SiriusXM
EQ40 - Cycle Presets; EQ41, EQ73 & EQApp - Navigate/Play Available Stations
TuneIn
EQ40 - Cycle Favorites; EQ41, EQ73 & EQApp - Navigate/Play Available Stations
Rhapsody
EQ40 – Cycle Playlists; EQ41, EQ73 & EQApp - Navigate/Play Albums, Artists, Genres, etc.
Deezer (Not available in USA)
EQ40 – Cycle Playlists; EQ41, EQ73 & EQApp - Navigate/Play Albums, Artists, Genres, etc.
Napster (UK only)
EQ40 – Cycle Playlists; EQ41, EQ73 & EQApp - Navigate/Play Albums, Artists, Genres, etc.
Supported
©Vantage Equinox
Widget:
Aliases:
Driver Category:
Connection Type:
Limited Support
NuVo Player
Audio
P3100, P200, P300
Media Server
Ethernet
EQ40
Not Supported
EQUINOX INTEGRATION GUIDE
Document Updated January 29, 2016
EQ41, EQ73 &
EQApp
page 1 of 9

Advertisement

loading
Need help?

Need help?

Do you have a question about the P3500 and is the answer not in the manual?

Questions and answers

Related Manuals for Nuvo P3500

Summary of Contents for Nuvo P3500

  • Page 1 I.Overview As part of its Premier Partner Program, Vantage Equinox products support the NuVo P3500, P3100, P200 and P300. After setting up the NuVo in Design Center, the Equinox audio widget user interface automatically appears in the EQ41 and EQ73 in-wall touch screens and on mobile devices installed with the Equinox App (available for iPhones, iPads, iPods, and Android products).

  • Page 2: Installation Steps

    Note: This document contains two examples of NuVo integration with Equinox products; Example 1: where the NuVo Player acts as a source for a Vantage 850D-DA distributed audio system, and Example 2: where the NuVo Player acts as the audio distribution product.
  • Page 3 Example 2: Stand-alone NuVo Player Add NuVo Player – Setup the NuVo zone Parameters – Give each zone a user In the Object Explorer, friendly name and select an area. Enter the IP Address for select Vantage...
  • Page 4 After the NuVo Player and EQ40 are configured and a Full Program or Update is done from Design Center to the Infusion Controller, you should see something like the following display on the EQ40: Equinox 40 –...
  • Page 5 NOTE: When the system program is complete it is recommended to wait at least 1 minute per NuVo zone before trying to control the NuVo Player through the Equinox UI. The Equinox UI will be gathering the metadata from the NuVo Player and, if used, the UI will be slow to respond or appear frozen.
  • Page 6 EQUINOX INTEGRATION GUIDE Full Screen View Source Change (Stand-Alone NuVo Only) If using the NuVo Player without the 850D-DA, as shown in Design Center Setup Example 2, when you change sources you will see the join group prompt. The zone’s source will not change until you tap join group.

  • Page 7: Connection Diagram Example

    EQUINOX INTEGRATION GUIDE IX. Connection Diagram Example ©Vantage Equinox NuVo Player page 7 of 9...
  • Page 8 (Vantage could lose connection to the NuVo if not).  After a full download of a Design Center project file, wait at least 1 minute per zone for the NuVo player system to fully finish sending metadata to the Infusion controller before testing.
  • Page 9 Workaround: Skips tracks or change source and then back.  After a Nuvo Player firmware update, the first time you try to control the player through an Eq73 it may take up to a minute before communication with the player is re-established. During that period it will appear that there is no communication with the player.
