Coopers of Stortford 10708 Instructions For Use

Wireless Receiver w/Doorbell
Please read and retain these instruc ons for future reference
Receiver
PARTS & FUNCTION DOOR BELL
Strobe/melody switch
Flasher
Zone ID
Speaker
Battery compartment
MOUNTING
Or
Stand on firm flat surface
Hang on a wall
such as a desk or table
Doorbell pusher
PARTS & FUNCTION DOOR BELL
Call button
Name plate
MOUNTING
or use sticker provided
CODE PAIRING & MELODY SELECTION
* PLESE NOTE THE BELL PUSHER AND CHIME UNIT ARE PAIRED AND
READY TO USE.
Step1: Insert the battery into the transmitter to be used
(Doorbell button)
Step 2: Insert the batteries into the receiver (chime unit).
Step 3: Enter pairing mode for the receiver (chime unit).
Press and hold the ● zone selector button for 3
seconds. The LED in zone #1 will flash.
Step 4: Press the ● zone selector button again to move to the
zone you wish to pair with. Press ♫ button to scroll
through the melodies. Once you hear a melody you
prefer, do not press any button as the melody is set
for that zone.
Step 5: Once the zone & melody are selected, press the
Doorbell button once to pair. If successful, the
receiver (chime unit) will generate two short tones. Press the ● zone selector button to
exit the pairing mode, the system is now ready to use.
To stop the Chime while the receiver (chime unit) is alerting press the reset button.
*Calls Cost 7 pence per minute plus your telephone company's network access charge
Volume control
Vibration pad ON/OFF switch
Melody
selector button
Zone selector button
Access Door
POWER
Using C size
batteries (not included)
Battery
compartment
POWER
Open the cover
Instruc ons for Use
10708
Vibration out
DC jack
Reset button
Mounting holes
Using an AC/DC
adaptor (not included)
or
12V DC 400 mA
CR2032 (included)
Zone ID
Zone select button
Melody selector button
Head Office, 11 Bridge Street
Bishop's Stor ord CM23 2JU
Tel: 0844 482 4400*
Fax: 01279 756595
www.coopersofstor ord.co.uk
v001: 23/11/16
Indicators
- +
Chime Only
Chime/Strobe
Strobe Only
