  • Page 1 User Manual Machine Vision Computer AVM-3110 Series...

  • Page 2: Table Of Contents

    Contents Contents AVM-3110 Series Machine Vision Computer User Manual Prefaces………………………………………………………………………..04 Revision……………………………………………………….……………………..……………….…………………………04 Copyright and Trademarks Notice………………………………………………………..……………….……….04 Disclaimer………………………………….…….…………………….……………………….………………….………….04 Technical Support and Assistance…………………………………….………………………….…………………04 Safety Instructions…………..………….………………………………….………..…………………....04 Package List……………………………………………………………………………………………………..………….…05 Ordering Information…………………………..………………………………….……………………….….…………05 Optional Accessory………...…………………................05 Chapter 1 Product Introductions……………………...…………..…06 1.1 Overview………………….………..………….…………..………….…………………..…..………….…………..07 1.2 AVM-3110 Series Specification………………..…..………..…………………..……..….………………08 1.3 Panel I/O………..……………..………………………..………………………………………………………………10 1.3.1 Front Panel……………......…………………………………………………….…………10...
  • Page 3 Contents AVM-3110 Series Machine Vision Computer User Manual Chapter 4 BIOS Setup….………...……………………..…………………..59 4.1 BIOS Introduction…….….…………………………………………………………………….…….…..….………60 4.2 Main Setup….……….……………………………………….…………………………….…….….…………………61 4.2.1 System Date……………………………………………………………………..…..……..…………………61 4.2.2 System Time..……………………………………………..………………………...……….………………61 4.3 Advanced Setup……………………………………………………..…………………..…………………………62 4.3.1 CPU Configuration..…………………….…………………….………………………………….………..62 4.3.2 PCH-FW Configuration………………………………………….………………………………………..63 4.3.3 SATA And RST Configuration………………………………….…………..…………………………..64 4.3.4 Trusted Computing (Optional)…….………………………….……………….……………………..65 4.3.5 ACPI Settings..………………………………………………………….………………..…..………………66...

  • Page 4: Prefaces

    This user’s manual is for informational purposes only and is subject to change without prior notice. It does not represent commitment from Aversix Inc. This product might include unintentional typographical or technical errors. Aversix will periodically correct such erroneous files and incorporate these corrections into the new version of the file.

  • Page 5: Package List

    AVM-3110 Series Machine Vision Computer User Manual Package List Item Description Q’ty AVM-3110 Series Machine Vision Computer Utility DVD Driver Wall Mount Kit Accessory Kit Ordering Information Model No. Product Description Intel® 9th/8th Core-i High Performance Machine Vision System with 3x LAN and 4x Removable AVM-3110 2.5”...

  • Page 6: Chapter 1 Product Introductions

    AVM-3110 Series Machine Vision Computer User Manual Chapter 1 Product Introductions...

  • Page 7: Overview

    The AVM-3110 series system feature a wide range of DC power inputs from 9V to 48V, wide temperature from -40°C to +70°C, high tolerance to shock 3G/vibration 50G, and industrial-grade protection (Power Reverse, ESD, OVP, OCP, Surge, etc.).

  • Page 8: Avm-3110 Series Specification

    AVM-3110 Series Machine Vision Computer User Manual 1.2 AVM-3110 Series Specification Processor Graphics • Integrated Intel® UHD Graphics 630 Support 9th/ 8th Intel® Core™ i3 / i5 / i7 Desktop 35W/ 65W LGA 1151 Processors (Core™ i7/ i5/ i3) • Intel® Core™ i7-9700TE •...
  • Page 9 AVM-3110 Series Machine Vision Computer User Manual Expansion Protection • AVM-3110: N/A • Over Voltage Protection (OVP) Up to 52V • AVM-3111P: 1x PCI Slot • Reverse Voltage Protection (RVP) up to -48V • AVM-3111E: 1x PCIe X16 Slot • Over Current Protection (OCP) 20A •...

  • Page 10: Panel I/O

    AVM-3110 Series Machine Vision Computer User Manual 1.3 Panel I/O 1.3.1 Front Panel Power on/off button Remote Power on/off Terminal Block Press to power-on or power-off the system Used to plug a remote power on/off terminal block AT/ATX mode select switch...
  • Page 11 AVM-3110 Series Machine Vision Computer User Manual AVM-3110 Series AVM-3112 Series AVM-3111 Series...
  • Page 12 AVM-3110 Series Machine Vision Computer User Manual AVM-3113 Series AVM-3114 Series...

  • Page 13: Top Panel

    AVM-3110 Series Machine Vision Computer User Manual 1.3.2 Top Panel CFast Socket Clear CMOS Used to insert CFast card Used to clear CMOS COM port PC/Car mode select switch COM1 ~ COM2 support RS232/422/485 Used to select PC or Car mode...
  • Page 14 AVM-3111 Series AVM-3112 Series AVM-3114 Series AVM-3113 Series...

  • Page 15: Rear Anel

    AVM-3110 Series Machine Vision Computer User Manual 1.3.3 Rear Panel USB 2.0 port SIM card Used to connect USB 2.0 device Used to insert SIM card Universal I/O Expansion Removable HDD port Used to customized I/O output Removable 2.5" SATA HDD Area...
  • Page 16 AVM-3110 Series Machine Vision Computer User Manual AVM-3111 Series AVM-3112 Series AVM-3113 Series AVM-3114 Series...

  • Page 17: Mechanical Dimensions

    AVM-3110 Series Machine Vision Computer User Manual 1.4 Mechanical Dimensions 1.4.1 AVM-3110 Series 1.4.2 AVM-3111 Series...

  • Page 18: Avm-3112 Series

    AVM-3110 Series Machine Vision Computer User Manual 1.4.3 AVM-3112 Series 1.4.4 AVM-3113 Series...

  • Page 19: Avm-3114 Series

    AVM-3110 Series Machine Vision Computer User Manual AVM-3114 Series...

  • Page 20: Chapter 2 Switches And Connectors

    AVM-3110 Series Machine Vision Computer User Manual Chapter 2 Switches and Connectors...

  • Page 21: Switch And Connector Locations

    AVM-3110 Series Machine Vision Computer User Manual 2.1 Switch and Connector Locations 2.1.1 Front View...

  • Page 22: Top View

    AVM-3110 Series Machine Vision Computer User Manual 2.1.2 Top View 2.1.3 Rear View...

  • Page 23: Switches, Leds And Connectors Definition

    AVM-3110 Series Machine Vision Computer User Manual 2.2 Switches, LEDs and Connectors Definition List of Switches and LEDs Location Definition PWR_SW2 Power Button AT_ATX2 AT / ATX Power Mode Switch RESET2 Reset Button CLR_CMOS1 Clear BIOS Switch CAR_PWR1 PC / Car Mode Switch...

  • Page 24: Switch Definitions

    AVM-3110 Series Machine Vision Computer User Manual 2.3 Switch Definitions PWR_SW2：Power Button Switch Definition Push Power On/Off System AT_ATX2：AT / ATX Power Mode Switch Definition 1-2 (Right) ATX Power Mode (Default) 2-3 (Left) AT Power Mode RESET2：Reset Button Switch Definition...
  • Page 25 AVM-3110 Series Machine Vision Computer User Manual Set the Power Ignition Step Step 1 To select power ignition by PC/CAR switch. Step 1 Pin 1-2 (Left)：PC Power Mode 2-3 (Right)：Vehicle Power Ignition Mode Step 2 To configure the power off delay time, please check the delay time setting options in advance.
  • Page 26 AVM-3110 Series Machine Vision Computer User Manual PWR_LED2：Power Status LED Power Status LED Color Power ON Blue HDD_LED2：HDD Status LED HDD Status LED Color HDD Read/Write Yellow IGN_LED2：Ignition Status LED IGN Status LED Color IGN ON Green GPIO_LED4, GPIO_LED5, GPIO_LED6：GPIO Status LED...

  • Page 27: Connector Definitions

    AVM-3110 Series Machine Vision Computer User Manual 2.4 Connector Definitions PWR_SW3：Remote Power Switch Connector Type：Terminal Block 1X2 2-pin, 3.5mm pitch Definition Power Button COM1_2_1：RS232 / RS422 / RS485 Connector Connector Type：9-pin D-Sub RS232 RS422 / 485 Full RS485 Half Duplex...
  • Page 28 AVM-3110 Series Machine Vision Computer User Manual COM3_1：RS232 / RS422 / RS485 Connector Connector Type：9-pin D-Sub RS232 RS422 / 485 Full RS485 Half Duplex Definition Duplex Definition Definition DCD3 TX3- DATA3- RxD3 TX3+ DATA3+ TxD3 RX3+ DTR3 RX3- DSR3 RTS3 CTS3 COM4_1：RS232 / RS422 / RS485 Connector...
  • Page 29 AVM-3110 Series Machine Vision Computer User Manual COM6_1：RS232 / RS422 / RS485 Connector Connector Type：9-pin D-Sub RS232 RS422 / 485 Full RS485 Half Duplex Definition Duplex Definition Definition DCD6 TX6- DATA6- RxD6 TX6+ DATA6+ TxD6 RX6+ DTR6 RX6- DSR6 RTS6 CTS6 DC_IN1：DC Power Input Connector (+9~48V)
  • Page 30 AVM-3110 Series Machine Vision Computer User Manual DIO1_1：Digital Input / Output Connector Connector Type：Terminal Block 2X5 18-pin, 3.5mm pitch Definition Definition External DC Voltage Input External GND...
  • Page 31 AVM-3110 Series Machine Vision Computer User Manual CN1, CN2, CN3：LAN and USB3.0 Port Connector Type: RJ45 port with LEDs and dual USB3.0 ports Definition Definition Definition LAN1_MDI0P USB2_D1- USB2_D2- LAN1_MDI0N USB2_D1+ USB2_D2+ LAN1_MDI1P LAN1_MDI2P USB3_RX1- USB3_RX2- LAN1_MDI2N USB3_RX1+ USB3_RX2+ LAN1_MDI1N...
  • Page 32 AVM-3110 Series Machine Vision Computer User Manual MINIPCIE1：Mini PCI-Express Socket (Support mPCIe, USB2.0 and SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ7# UIM1_PWR USIM1_DATA PCIE_CLK7- USIM1_CLK PCIE_CLK7+ USIM1_RST USIM1_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN8 +3.3Vaux PCIE_RXP8 +1.5V...
  • Page 33 AVM-3110 Series Machine Vision Computer User Manual MINIPCIE2：Mini PCI-Express Socket (Support mPCIe, USB2.0 and SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ8# UIM2_PWR USIM2_DATA PCIE_CLK8- USIM2_CLK PCIE_CLK8+ USIM2_RST USIM2_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN19 +3.3Vaux PCIE_RXP19 +1.5V...
  • Page 34 AVM-3110 Series Machine Vision Computer User Manual CN4：Dual Mode Mini PCI-Express (Support mPCIe, mSATA, USB2.0 and SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ9# USIM3_PWR USIM3_DATA PCIE_CLK9- USIM3_CLK PCIE_CLK9+ USIM3_RST USIM3_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN17 +3.3Vaux...
  • Page 35 AVM-3110 Series Machine Vision Computer User Manual CN5：Dual Mode Mini PCI-Express (Support mPCIe, mSATA, USB2.0 and SIM Card to Link feature) Definition Definition WAKE# +3.3Vaux +1.5V CLKREQ10# USIM4_PWR USIM4_DATA PCIE_CLK10- USIM4_CLK PCIE_CLK10+ USIM4_RST USIM4_VPP RESERVED RESERVED W_DISABLE# RESET# PCIE_RXN18 +3.3Vaux...

  • Page 36: Chapter 3 System Setup

    AVM-3110 Series Machine Vision Computer User Manual Chapter 3 System Setup...

  • Page 37: Removing Cpu Heat Sink Cover

    AVM-3110 Series Machine Vision Computer User Manual WARNING In order to pevent electric shock or system damage, before removing the bottom chassis cover, must turn off the power and disconnect the device from power source. 3.1 Removing CPU heat sink cover 1.

  • Page 38: Installing Cpu

    AVM-3110 Series Machine Vision Computer User Manual 3.2 Installing CPU 1. You can locate the CPU socket after CPU heat sink cover is removed. 2. Press down the CPU socket lever to open the socket cover.
  • Page 39 AVM-3110 Series Machine Vision Computer User Manual 3. Remove the CPU socket protective cover. 4. Install the CPU in the direction indicated by the arrow.
  • Page 40 AVM-3110 Series Machine Vision Computer User Manual 5. Press down the lever to hold the CPU socket cover.. 6. Paste thermal pad on the CPU.
  • Page 41 AVM-3110 Series Machine Vision Computer User Manual 7. Place the CPU heat block onto the thermal pad. 8. Lock the CPU heat sink with three screws.
  • Page 42 AVM-3110 Series Machine Vision Computer User Manual 9. Paste the thermal pad onto the installed CPU heat block. 10. The installation is complete .

  • Page 43: Installing Sodimm

    AVM-3110 Series Machine Vision Computer User Manual 3.3 Installing SODIMM 1. Two SODIMM sockets are available for AVM-3110 Series on the motherboard top side. Locate SODIMM socket. 2. Insert the DDR4-SODIMM module from 45 degree direction. 3. Press the module down until it’s fixed firmly by the two locking latches.

  • Page 44: Installing Mini-Pcie Or Msata Module

    AVM-3110 Series Machine Vision Computer User Manual 3.4 Installing Mini-PCI Express or mSATA Module 1. Four Mini-PCIe sockets are available for AVM-3110 series. The top CN4 and CN5 can also support mSATA. Top Side Bottom Side (MINIPCIE1, CN4, CN5) (MINIPCIE2) 2.

  • Page 45: Installing Antenna

    AVM-3110 Series Machine Vision Computer User Manual 3.5 Installing antenna 1. Four antenna holes are available for AVM-3110 series on the front and top panel. Front Panel Top Panel 2. Remove the antenna hole covers at front or top panel.
  • Page 46 AVM-3110 Series Machine Vision Computer User Manual 3. Have antenna jack penetrate through the hole. 4. Put on washer and fasten the nut with antenna jack.
  • Page 47 AVM-3110 Series Machine Vision Computer User Manual 5. Assemble the antenna and antenna jack together. 6. Attach the RF connector at the cable-end onto the Mini-PCIe wifi module.

  • Page 48: Installing Removable Sata Hdd Bay

    AVM-3110 Series Machine Vision Computer User Manual 3.6 Installing removable SATA HDD bay 1. The AVM-3110 series has four removable SATA HDD bay, two on the front panel and two on the rear panel. 2. Unscrew the two thumb screws circled below to remove the removable 2.5” SATA HDD bay.

  • Page 49: Installing Cfast1/2 Or Sim1/2 Card

    AVM-3110 Series Machine Vision Computer User Manual 3.7 Installing CFast1/2 or SIM1/2 card 1. Two CFast sockets are on the top side of the system. Unscrew two screws to remove the CFast1/ SIM or CFast2 cover plate. 2. Insert CFast/ SIM card into the socket.

  • Page 50: Installing Internal Sim3/4 Card

    AVM-3110 Series Machine Vision Computer User Manual 3.8 Installing SIM3/4 card 1. Flip the system so that SIM3/4 is facing forward. 2. Insert SIM card into the socket. Note 1 Please note that the installation of SIM1_1, SIM2_1, SIM3_1 and SIM4_1 has to match the installation of Mini-PCIe sockets.

  • Page 51: Changing Cmos Battery

    AVM-3110 Series Machine Vision Computer User Manual 3.9 Changing CMOS battery 1. The CMOS battery can be replaced from the top panel of the system. Unscrew two screws to remove the CFast1/ SIM cover plate. 2. Unscrew two screws to pull out the CMOS battery.

  • Page 52: Assembly Cpu Heat Sink Cover

    AVM-3110 Series Machine Vision Computer User Manual 3.10 Assembly CPU heat sink cover 1. Please make sure that the thermal pad is attached to the CPU heat sink and PCH heat sink. 2. Close the CPU heat sink cover. 3. Fasten the six screws on the system left side and right side.

  • Page 53: Installing Pci/ Pcie Expansion Card

    AVM-3110 Series Machine Vision Computer User Manual 3.11 Installing PCI/ PCIe expansion card 1. Unscrew two thumb screws on the front side of expansion module. 2. Pull the thumb screw in the following direction to open the expansion box cover.
  • Page 54 AVM-3110 Series Machine Vision Computer User Manual 3. Unscrew the screw securing the PCI/PCIe card bracket to remove the bracket. 4. Insert the PCI/ PCIe card into the expansion slot.
  • Page 55 AVM-3110 Series Machine Vision Computer User Manual 5. Install the screw back to secure the PCI/ PCIe card. 6. Close the chassis cover and tighten the thumb screw.

  • Page 56: Connecting Expansion Module With Pc Module

    AVM-3110 Series Machine Vision Computer User Manual 3.12 Connecting expansion module with PC module 1. Connect expansion module with PC module by inserting the gold fingers on the expansion module into the slot. 2. Fasten all screws using the connection brackets on the top and bottom of the system.

  • Page 57: Installing Stand / Wall Mount

    AVM-3110 Series Machine Vision Computer User Manual 3.13 Installing stand / wall mount 1. Wall mount kit is available for AVM-3110 series included in the standard package. 2. Lock the wall mount kit with 8 screws on the bottom or left side of the system.
  • Page 58 AVM-3110 Series Machine Vision Computer User Manual 3. The installation is complete. Stand Mount Wall Mount...

  • Page 59: Chapter 4 Bios Setup

    AVM-3110 Series Machine Vision Computer User Manual Chapter 3 Bios Setup...

  • Page 60: Bios Introduction

    AVM-3110 Series Machine Vision Computer User Manual 4.1 BIOS Introduction The system BIOS software is stored on EEPROM. The BIOS provides an interface to modify the configuration. When the battery is removed, all the parameters will be reset. BIOS Setup Power on the embedded system and by pressing <Del>...

  • Page 61: Main Setup

    AVM-3110 Series Machine Vision Computer User Manual 4.2 Main Setup Press <Del> to enter BIOS CMOS Setup Utility. The Main setup screen is showed as following when the setup utility is entered. System Date/Time is set up in the Main Menu.

  • Page 62: Advanced Setup

    AVM-3110 Series Machine Vision Computer User Manual 4.3 Advanced Setup 4.3.1 CPU Configuration...

  • Page 63: Pch-Fw Configuration

    AVM-3110 Series Machine Vision Computer User Manual ■ Intel (VMX) Virtualization Technology This item allows you to enable or disable Intel (VMX) Virtualization Technology. VT allows a single platform to run multiple operating systems in independent partitions. ■ Active Processor Cores This item allows you to choose the number of active processor cores.

  • Page 64: Sata And Rst Configuration

    AVM-3110 Series Machine Vision Computer User Manual 4.3.3 SATA And RST Configuration ■ SATA Controller(s) This item allows you to enable or disable SATA device. ■ SATA Mode Selection Allows you to select which mode SATA controller will operates. Select <AHCI> or <Intel RST Premium with Intel Optane System Acceleration>...

  • Page 65: Trusted Computing (Optional)

    AVM-3110 Series Machine Vision Computer User Manual 4.3.4 Trusted Computing ■ Security Device Support This item allows you to enable or disable BIOS support for security device. O.S. will not show Security Device. TCG EFI protocol and INT1A interface will not be available.

  • Page 66: Acpi Settings

    AVM-3110 Series Machine Vision Computer User Manual ■ TPM2.0 UEFI Spec Version This item allows you to select the supported TCG version based o your OS. TCG_1_2: Supports Windows 8 /10. TCG_2: Supports new TCG2 protocol and event format for Windows 10 or later.

  • Page 67: Super Io Configuration

    AVM-3110 Series Machine Vision Computer User Manual 4.3.6 Super IO Configuration This setting allows you to select options for the Super IO Configuration, and change the value of the selected option.
  • Page 68 AVM-3110 Series Machine Vision Computer User Manual ■ Serial Port 1 Configuration ■ Serial Port 2 Configuration...
  • Page 69 AVM-3110 Series Machine Vision Computer User Manual ■ Serial Port 3 Configuration ■ Serial Port 4 Configuration...
  • Page 70 AVM-3110 Series Machine Vision Computer User Manual ■ Serial Port 5 Configuration ■ Serial Port 6 Configuration...

  • Page 71: Serial Port Console Redirection

    AVM-3110 Series Machine Vision Computer User Manual • Serial Port This item allows you to enable or disable serial port. • Change Settings This item allows you to change the address & IRQ settings of the specified serial port. • Device Type Select Change the Serial interface.
  • Page 72 AVM-3110 Series Machine Vision Computer User Manual ■ Console Redirection These items allows you to enable or disable COM1~COM6 console redirection. ■ Legacy Console Redirection Settings Select a COM port to display redirection of Legacy OS and Legacy OPROM Messages.

  • Page 73: Hardware Monitor

    AVM-3110 Series Machine Vision Computer User Manual 4.3.8 Hardware Monitor These items display the current status of all monitored hardware devices / components such as voltages and temperatures. 4.3.9 USB Configuration...

  • Page 74: Csm Configuration

    AVM-3110 Series Machine Vision Computer User Manual ■ Legacy USB Support This item allows you to enable or disable legacy USB Support. Enabled: Allows USB keyboard/ mouse to be used in MS-DOS. Disabled: Keeps USB devices available only for EFI applications.
  • Page 75 AVM-3110 Series Machine Vision Computer User Manual ■ CSM Support Enables or disables UEFI CSM (Compatibility Support Module) to support a legacy PC boot process. ■ Boot option filter This item allows you to select which type of operating system to boot.

  • Page 76: Nvme Configuration

    AVM-3110 Series Machine Vision Computer User Manual 4.3.11 NVMe Configuration This screen displays the current NVMedevice information. 4.3.12 Network Stack Configuration ■ Network Stack This item allows you to enable or disable UEFI Network Stack.

  • Page 77: Chipset

    AVM-3110 Series Machine Vision Computer User Manual 4.4 Chipset This section allows you to configure and improve your system and allows you to set up some system features according to your preference. 4.4.1 System Agent (SA) Configuration...
  • Page 78 AVM-3110 Series Machine Vision Computer User Manual ■ Memory Configuration This item displays detailed memory configuration in the system. • Max TOLUD Maximum Value of TOLUD. Dynamic assignment would adjust TOLUD automatically based on largest MMIO length of installed graphic controller. Select <Dynamic>, <1 GB>, <1.25 GB>, <1.5 GB>, <1.75 GB>, <2GB>, <2.25GB>, <2.5GB>,...

  • Page 79: Pch-Io Configuration

    AVM-3110 Series Machine Vision Computer User Manual • Primary Display Select which of IGFX/ PEG/ PCI Graphics device should be Primary Display or select SG for Switchable Gfx. Slect <Auto>, <IGFX>, <PEG>, <PCI> or <SG> interface. • DVMT Pre-Allocated DVMT pre-allocated (fixed) Graphics memory size optimal from 32M to 1024M.
  • Page 80 AVM-3110 Series Machine Vision Computer User Manual ■ PCI Express Configuration • LAN2-I210 This item allows you to enable or disable LAN2 in the chipset. Speed Change the PCIe Port Speed. Select <AUTO> ,<Gen 1>, <Gen 2> or <Gen 3>...
  • Page 81 AVM-3110 Series Machine Vision Computer User Manual ■ HD Audio Configuration • HD Audio Control detection of the HD-Audio device. This item allows you to select <Enabled>, <Disabled> or <Auto>. Disabled: HD-Audio will be unconditionally be disabled. Enabled: HD-Audio will be unconditionally be enabled.

  • Page 82: Security

    AVM-3110 Series Machine Vision Computer User Manual 4.5 Security Security menu allow you to change administrator password and user password settings. 4.5.1 Administrator Password This item allows you to set Administrator Password. 4.5.2 User Password This item allows you to set User Password.

  • Page 83: Boot

    AVM-3110 Series Machine Vision Computer User Manual 4.6 Boot This menu allows you to setup the system boot options. 4.6.1 Setup Prompt Timeout This item sets number of seconds to wait for setup activation key. 4.6.2 Bootup NumLock State This item selects the keyboard NumLock state. Select <On> or <Off> mode.

  • Page 84: Save & Exit

    AVM-3110 Series Machine Vision Computer User Manual 4.7 Save & Exit This setting allows you to configure the boot settings. 4.7.1 Save Changes and Exit This item allows you to exit the system after saving the changes. 4.7.2 Discard Changes and Exit This item allows you to reset the system setup without saving any changes.

  • Page 85: Discard Changes And Exit

    AVM-3110 Series Machine Vision Computer User Manual 4.7.7 Restore Defaults This item allows you to restore/ load default values for all the setup options. 4.7.8 Save as User Defaults This item allows you to save the changes done so far as user defaults.
