Instructions for assembly, maintenance and safe use.
Please retain for future reference.
TP885 Alaska
WARNING!
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
CONTAINS SMALL PARTS. CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
ADULT SUPERVISION IS REQUIRED
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 12 YEARS.
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
MAXIMUM COMBINED USER WEIGHT FOR SWING FRAMES 200KGS
TP885 ALASKA
TP886 GALAPAGOS
TP887 FIORDLAND
TP821 885 886 887 Roundwood Deck In8000-A 23.02.18 NEW.indd 1
TP886 Galapagos
SINGLE SEAT USER WEIGHT - 60KGS
SINGLE SEAT USER WEIGHT - 60KGS
NEST SWING USER WEIGHT - 120KGS
2.5 Hrs
Build Time
x2
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
TP887 Fiordland
GLIDE RIDE USER WEIGHT - 35KGS PER SEAT
GLIDE RIDE USER WEIGHT - 35KGS PER SEAT
23/02/2018 14:44
