- Page 1 LITHIUM ION BATTERY USER`S MANUAL VERSION: 201901029...
-
Page 2: Table Of Contents
Table of Contents …………………………………….… Introduction Page 2 ……………... Warning label and Safety Operation Page 2 ………..Battery Specifications & Presentation Page 4 ……………. Battery and Accessories Presentation Page 5 ………………………..……… Battery Installation Page 8 …………………………………………. Charging Page 8 …………………………………………... Storage Page 9 …………………………………………. -
Page 3: Introduction
Introduction EVOLUTION lithium-ion battery is a type of Lithium iron phosphate battery (LiFePO4), it is a reliable power source that doesn’t fade over time. Whether it's a new or five-year-old vehicle, EVOLUTION lithium ion battery vehicles will give you all the acceleration and hill-climbing power they could want. - Page 4 Safety Operation Improper handling of batteries and electrical components can result in serious injury or death. Do not remove the battery pack cover. Do not attempt to remove batteries or battery cables. Do not use the battery pack without the control module installed. All battery and electrical service must be performed by an authorized service facility and personnel.
-
Page 5: Battery Specifications & Presentation
Battery Specification Model EV48-60 EV48-110 EV48-130 EV48-165 Dimension 12＂x 13＂x 9＂ 23＂x 13＂x 9＂ 23＂x 13＂x 9＂ 31＂x 13＂x 9＂ (L x W x H) inch General Parameters Casing material Aluminum alloy Aluminum alloy Aluminum alloy Aluminum alloy IP level... -
Page 6: Battery And Accessories Presentation
Battery and Accessories Presentation 1. LiFePO4 Lithium-ion Batteries Pack with Aluminum Alloy Casing. Battery Positive Terminal Battery Negative Terminal 4. RS485: Connector Port for Lithium Battery Power Indicator 5. SW: Inspection Light & Button for BMS 6. Vent Valve for Lithium-ion Battery Pack 7. - Page 7 Battery Indicator Evolution lithium battery provides two different shape optional battery indicators for customer, round shape and diamond shape. Also provide the connecting cable for the battery indicator. Connecting cables Clock wise Push in Push the battery indictor male plug into Rotate clockwise the Lock cap to the port as following direction.
- Page 8 Wiring diagram for battery indicator as following: Battery power indicator display introduction Battery indicator shows the amount of usable power in the battery pack, it should be installed on the dash panel where the place is obvious to check for drivers. Below are displaying: Each of LED lights indicates 10% of ...
-
Page 9: Battery Installation
Battery Installation NOTE: It is highly recommended that the vehicle be testing driven before installation of the EVOLUTION lithium battery product to ensure that the vehicles existing systems operate as normal. Step 1: Remove the seat bottom. Remove the vehicles existing lead acid ... -
Page 10: Storage
At the end of the storage period, charge the battery pack to 100% before operating the vehicle. Warranty EVOLUTION Lithium-ion Battery Pack and Battery Management System are warrantied for FIVE years or 80,000KM, whichever comes first, starting from date of delivery to the Purchaser`s location against defective material or workmanship. -
Page 11: Recycling
Damages resulting from an accident or collision, or from the neglect, abuse battery pack system. This warranty is in lieu of all other express warranties. EVOLUTION will not be liable for consequential or incidental damages. Lithium-Ion Battery Recycling Lithium-Ion batteries must be collected and recycled separately from other waste. - Page 12 APPENDIX A LITHIUM BATTERY CHARGER USER`S GUIDE...
- Page 13 Evolution charger for lithium-ion battery. Evolution has two models of lithium-ion battery charger. DANGER: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, CAREFULLY READ AND FOLLOW THESE IMPORTANT SAFETY AND OPERATING INSTRUCTIONS BEFORE INSTALLING OR OPERATING THE CHARGER.
- Page 14 APPENDIX A Operation Instructions Charger LED Display Troubleshooting Instruction If a fault occurs, count the number of red flashes between pauses and refer to the table below. --RED --GREEN Battery Charger Manual Evolution...
- Page 15 APPENDIX A Battery Charger Manual Evolution...
- Page 16 15830 El Prado Road Unit D, Chino, CA 91708, USA Tel: +1(909)-393-6800 Email: info@evolutionelectricvehicle.com Website: http://www.evolutionelectricvehicle.com Copyrighted Material EVOLUTION ELECTRIC VEHICLES INC reserves the right to change or improve the manual obeying to products and company policy alterations at any time without notice.
