Summary of Contents for FirstPower Stinger
- Page 1 Version 1 Owner / Operator’s Manual Rev B.2 PATENT PENDING 8941 Dutton Dr, Twinsburg, Ohio 44087 330-963-2050...
-
Page 2: Table Of Contents
Table of Contents Stinger® Kit Overview ……………………………………………………………………………… 1 Operation Guide ……………………………………………………………………………………. 2 GoPro® Camera Installation and Usage ………………………………………….. Battery Replacement …………………………………………………………………………….. Replace Transmitter Battery …………………………………………………… Replace Receiver Batteries ………………………………………………………. Stinger® Fluid Overview ………………………………………………………………………… Recommended Maintenance and Safety ………………………………………… Specifications and Certifications …………………………………………………………... -
Page 3: Stinger® Kit Overview
Receiver: Allows for remote communication between the main assembly, Key Fob and the transmitter to turn the dispense on and off. Transmitter: Allows for Stinger® fluid to be sprayed through a press of a button from a safe location.in the Transmitter and Receiver. -
Page 4: Operation Guide
Operation Guide Step 1: Take the Main Assembly (2) out the Case (1). Typically, the Receiver (3) is left in the Main Assembly (2). If the Receiver (3) is not installed, installed it using the procedure shown on page 16. Begin with screwing a Nozzle (5) into the threaded insert on the Main Assembly (2). - Page 5 Can could leak or fail inside the Can Housing. The Stinger® can only be used with proprietary Stinger® fluids, DO NOT attempt to insert other cans into the Stinger®. Step 4: After installing a can, be sure to fully screw the orange Can Cap to the Main Assembly (2) until hand tight.
- Page 6 ON position, the transmitter may not be functioning. Warning: Any transmitter will control all powered receivers within range. Make sure that all other Stingers that are not in use have their receivers and transmitters turned off. 4 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2...
- Page 7 ON Position Switch Step 8: Attach the fully assembled Stinger® to the hot stick using the yellow universal toothed hot stick adapter (Hot Stick Adapter). Be sure to attach the Main Assembly (2) at an appropriate angle to easily aim stream of Stinger fluid to the desired location.
- Page 8 Nozzle (5) back in the Case (1). Step 11: Remove the can cap then, unscrew the can. Make sure the Main Assembly (2) is upright to prevent the Stinger® fluids from leaking onto your clothes when the can is unscrewed. Then reinstall the can cap.
- Page 9 Operation Guide Step 12: Place the Main Assembly (2) with the Receiver (3) into the Case (1) and close the Case (1). Make sure this manual is in the Case (1) if the Stinger is not in use. 7 | ©2019 FirstPower Group LLC...
-
Page 10: Gopro® Camera Installation And Usage
GoPro® Camera Installation and Usage Step 1: Lift the grey Rubber Locking Plug that is a part of the GoPro® Camera (6) so that it is touching the back of the camera. Before After Rubber Rubber Locking Locking Plug Plug Step 2: To easily slide the GoPro®... - Page 11 Step 5: After use, gently remove the camera from the Main Assembly (3) and turn it off. Steps 1-4 for reference. Place the Smartphone (6) and the camera back into the Case (1) 9 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2...
-
Page 12: Battery Replacement
Battery Replacement Replace Transmitter Battery The status of the batteries is indicated by the transmitter LED when the button is not pressed. If the LED flashes red 1 time every 3 seconds, then transmitter has low battery voltage. If the LED flashes red 2 times every 3 seconds, then the receiver has low battery voltage. -
Page 13: Replace Receiver Batteries
Step 1: Remove the Receiver (3) from its initial position shown in the “Before” figures. Gently slide it out the back of the Main Assembly (2) which is presented in the “After” figures. Before After 11 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2... - Page 14 Battery Philips Head Door Screws Step 3: Use standard Alkaline 9V batteries for replacement. Remove the old batteries and carefully replace with Battery 2 new 9V batteries Door Alkaline 9V Batteries 12 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2...
- Page 15 Battery door must be installed flush. Screws must be recessed after installing. DO NOT Battery FORCE screws in, if they don’t easily Door screw in so they are recessed, unscrew and re-install. 13 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2...
- Page 16 Step 4: Finally, insert the Receiver (3) back into the back of the Main Assembly (2) as shown in the “Before” figures. Confirm the that Receiver (3) is fully inserted into the Main Assembly (2) as shown in the “After” figures. Before After 14 | ©2019 FirstPower Group LLC Stgr-Manual-V1 Rev. B.2...
-
Page 17: Stinger® Fluid Overview
1FR has a proprietary threaded top which only allows it to be used in the Stinger®. Simply apply to a seized joint and let sit for 20-30 minutes to ensure penetration and repeat if needed. -
Page 18: Recommended Maintenance And Safety
Recommended Maintenance and Safety Recommended Maintenance Extend the life of the Stinger® by not storing outdoors or in extreme conditions Wipe the Stinger® using a clean lint-free cloth after each use. o DO NOT USE CHEMICAL SOLVENTS AS THIS WILL VOID WARRANTY. -
Page 19: Specifications And Certifications
Material: dielectric resin o ASTM D149 tested to 221 kV/in The Stinger® passes a Proximity High Voltage Withstand test to 230kV Stinger® Fluids: All Stinger® Fluids have passed ASTM 3065D for non-flammability when applied using the Stinger®... -
Page 20: Warranty Information
Warranty Information The Stinger® is warranted for one year from the date of purchase with a factory warranty. This warranty applies to parts and labor for any defects that are corrected in our shop when the product has been returned for repair. Pass through warranties provided where applicable. -
Page 21: Parts Diagram
STGR-Aerosol 2C 2C, Not included in Stinger® Kit STGR-Aerosol 3PAO 3PAO, Not included in Stinger® Kit *This product and/or service is not affiliated with, endorsed by or in any way associated with GoPro Inc. or its products and services. GoPro, HERO, Session, Karma and their respective logos are trademarks or registered trademarks of GoPro, Inc. - Page 22 Questions? Contact FirstPower Group LLC at 330-963-2050 www.firstpowergroupllc.com...
