SERIES 98
EXTRUDED ALUMINUM
STOP LOGS
INSTALLATION AND MAINTENANCE
MANUAL
(Revision 0)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 98 Series and is the answer not in the manual?

Questions and answers

Michael Gastrow/Platt Construction Inc
August 5, 2025

How do i get a maintenance manual for the Serie 95 Stainless Steel Stop Log System?

Summary of Contents for Fontaine Aquanox 98 Series

  • Page 1 SERIES 98 EXTRUDED ALUMINUM STOP LOGS INSTALLATION AND MAINTENANCE MANUAL (Revision 0)
  • Page 2: Table Of Contents

    Stop log lifting beam doesn’t perform well ............12 10.3. Stop logs leak ......................12 10.4. Lip (HY-Q) Seal ......................13 Inspection and maintenance ................14 11.1. Inspection frequency ....................14 11.2. Maintenance ......................14 Warranty ....................... 15 Contact Fontaine Aquanox ................. 15 Page 2 sur 15...
  • Page 3: Introduction

    Fontaine Aquanox Stop Logs. It is intended for contractors responsible for the installation, for owners and operators of the equipment, for preventive maintenance supervisor and potential repairers to clearly diagnose problems and make to proper basic adjustments.
  • Page 4: Receiving

    Also verify the equipment tag. They must match the items listed on the bill of lading. No claims for missing parts will be accepted after the period of 5 working days. Contact Fontaine Aquanox to report any anomalies found or missing parts. 4. STORAGE Cover and protect all equipment that will not be installed immediately.
  • Page 5: Glossary For Stop Logs

    5. GLOSSARY FOR STOP LOGS Figure 1 Page 5 sur 15...
  • Page 6: Preparation For Installation

    6. PREPARATION FOR INSTALLATION 6.1. NEW CONCRETE CHANNEL WITH BOXOUTS Verify the straightness of the channel and boxouts where the frame will be installed. A plumb line, a laser and/or a straight edge can be used. 1. First verify the channel depth (height) against the submittal drawing. A variation of ± 25mm (1’’) is acceptable and will not impact the installation or operation.
  • Page 7 1. First, measure the channel width. It must be larger than the overall gate’s frame by at least 32mm (1-1/4"). 2. Verify the channel depth. A maximum difference of ± 25mm (1”) vs the depth indicated on the approved submittal drawing is acceptable and will not impact the installation or operation. 3.
  • Page 8: Embedded Frame Installation

    7. EMBEDDED FRAME INSTALLATION Always apply an anti-seize on the stainless steel fasteners. 1- Frames are usually shipped unassembled. The first step is to place the bottom section of the frame (sill). 2- Start by precisely measuring and marking the exact center of the sill.
  • Page 9: In Channel Surface Installation

    IN CHANNEL SURFACE INSTALLATION Always apply an anti-seize on the stainless steel fasteners. 1- Frames are usually shipped unassembled. The first step is to place the bottom section of the frame (sill). 2- Start by precisely measuring and marking the exact center of the sill.
  • Page 10 12- Measure across the channel, the distance between the frame sides at the top and bottom. The distance at the top and bottom should be the same. Adjust if needed. 13- Place stainless steel shims behind the frame, close to the anchors, before tightening. The frame must remain in position while the anchors are tightened.
  • Page 11: Operation With Lifting Device

    9. OPERATION WITH LIFTING DEVICE When supplied, a lifting device can be used to help placing and removing stop logs from the frame. It is basically a beam that travels in the same guide frame than the logs. It has 2 hooks aligned with the 2 handles that are located on each log.
  • Page 12: Troubleshooting

    10. TROUBLESHOOTING Never use excessive force with the lifting equipment, permanent damage to seals and lifting equipment may result. 10.1. STOP LOGS JAMMING Check installation of guides for proper dimensions. Have the guides been installed straight and plumb? ! Since the guides are embedded in the concrete, corrections of the guides will be difficult if not possible.
  • Page 13: Lip (Hy-Q) Seal

    If there are problems in the operation of a system and troubleshooting described above offers no solution, contact Fontaine Aquanox (see section 13) and have, if possible, the following information: Equipment serial number •...
  • Page 14: Inspection And Maintenance

    11. INSPECTION AND MAINTENANCE In order to maintain the gates performances at its best, Fontaine Aquanox recommends the following procedure. 11.1. INSPECTION FREQUENCY Initial inspection: after 5 uses or two weeks after start up, whichever comes first. Second inspection: 20 uses after the initial inspection or six months after start up, whichever comes first.
  • Page 15: Warranty

    Corrections by ISE Metal inc. of non-compliance described above constitute complete fulfillment of its responsibility in this manner. 13. CONTACT FONTAINE AQUANOX If needed, Fontaine-Aquanox can be contacted with the following methods: Web site: http://www.ISEAquanox.com...
