FlightTech Intercoms ITC-404SP Manual page 8

JACK-1, PIN #
J1-10
JACK-2, PIN #
JACK -3
8
CONNECTION
J1-1 PASSENGER MIC
J1-2 PASSENGER MIC
J1-3 MIC LOW SIDE
J1-4 MIC LOW SIDE
J1-5 PTT OUT
J1-6 MIC AUDIO OUT
J1-7 PILOT PTT
J1-8 PILOT MIC
J1-9 COPILOT PTT
COPILOT MIC
CONNECTION
J2-1 A/C PLUS VOLT
J2-2 GROUND
J2-3
LOW LEVEL AUDIO
J2-4 AUX STEREO IN
J2-5 AUX STEREO IN
J2-6
GROUND
J2-7 PASS HP AUDIO
J2-8 PASS HP AUDIO
J2-9 PILOT HP AUDIO
J2-10 PILOT HP AUDIO
CONNECTION
J3-1 CELL PHONE MIC, TIP
CELL PHONE HP
J3-2
AUDIO, RING
GROUND/SHIELD
J3-3
