WALL MOUNTED ELECTRIC FIREPLACE HEATER
MODEL #: 101002,111002, 101003, 111003
33"/36"/50" Wall Mounted Electric Fireplace
Read and understand this entire owner's manual, including all safety information,
before plugging in or using this product. Failure to do so could result in fire, electric
WARNING
shock, or serious personal injury.
Keep this owner's manual for future reference. If you sell or give this product away,
CAUTION
make sure this manual accompanies this product.
OWNERS MANUAL
AC 120V 60Hz 1500W
!
Advertisement
Table of Contents
Summary of Contents for Eden Branch Products 101002
- Page 1 WALL MOUNTED ELECTRIC FIREPLACE HEATER OWNERS MANUAL MODEL #: 101002,111002, 101003, 111003 33”/36"/50" Wall Mounted Electric Fireplace AC 120V 60Hz 1500W Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in fire, electric WARNING shock, or serious personal injury.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION! WARNING l Read all instructions before using this heater! l This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If provided, use handles when moving this heater. Keep combustible materials, such as furniture, pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater, and keep them away from the sides and rear. - Page 3 l ALWAYS turn this heater off before unplugging it from the outlet. l ALWAYS disconnect this unit from the power supply before performing any assembly or cleaning, or before relocating the electric fireplace. l NEVER leave this heater unattended. ALWAYS unplug this heater when not in use. l ALWAYS store this heater in a dry location.
-
Page 4: Parts And Hardware
Parts and Hardware B – Wood Screws C – Drywall anchors A – Fireplace Remote Control Instruction Manual E - Wall Bracket F-Decorative G-Decorative H - Log set I - Plastic Tray Pebbles Crystals Fixed on back of firebox Installation and Assembly Your appliance is a wall-mounted appliance. -
Page 5: Wall Mounted Installation
Wall Mounted Installation Due to the many different materials used on different walls, it is highly recommended that you consult your local builder before you install this appliance on the wall. A.Select a location that is not prone to moisture and is located at least 36" (914mm) away from combustible materials such as curtain drapes, furniture, bedding, paper, etc. - Page 6 WS-G-01,WS-G-03,BEF-36WMC Illustrated Logset / Crystal / Pebble Ember Installation (NOTE:Please make the installation according to the embers which you bought or selected.) Glass front must be removed and the appliance must be mounted in its final location before the logset / crystal / pebble embers are installed. If your fireplace come with logset, you do not need to do anything, just use as it is.
-
Page 7: Methods Of Operation
Figure 3. (Crystal medias) Figure 3. (Pebbles medias) Operation Read and understand this entire owner’s manual, including all safety information, before plugging in or using this product. Failure to do so could result in electric shock, fire, serious injury, or death. Power Plug the power cord into a 110~120 Volt 15 Amp grounded outlet (see IMPORTANT SAFETY INFORMATION on Pages 2 and 3). -
Page 8: Control Panel & Remote Control Operation
Control Panel & Remote Control Operation ON (l). Enables all functions. 1. Press ON (l). Power turns on. All functions are enabled. OFF (O). Turns off all functions on control 2. Press OFF (O). Power, flame effect, and panel and remote control. all functions turn off. -
Page 9: Temperature Limiting Control
Temperature Limiting Control This heater is equipped with a Temperature Limiting Control. Should the heater reach an unsafe temperature, the heater will automatically turn OFF. To reset: 1. Unplug the power cord from the outlet. 2. Turn the ON/OFF switch on the CONTROL PANEL to OFF. Wait 5 minutes. 3. -
Page 10: Maintenance
Maintenance Risk of electric shock! DO NOT OPEN any panels ! No user-serviceable parts inside! ALWAYS turn the heater OFF and unplug the power cord from the outlet before cleaning, performing maintenance, or moving this fireplace. Failure to do so could result in electric shock, fire, or personal injury. - Page 11 Limited Warranty J & J Global (Seller) warrants to the original Buyer only, that each product will be free from defects in material and workmanship for a period of one (1) year from date of purchase. SELLER’S SOLE OBLIGATION AND BUYER’S EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE THE REPAIR OR REPLACEMENT OF PARTS, WITHOUT CHARGE, WHICH ARE DEFECTIVE IN MATERIAL OR WORKMANSHIP.
