Summary of Contents for Dayang Fresco-S
- Page 1 Fresco‐S Multi‐viewer Quick Setting‐up Manual DayangTechnologyDevelopmentInc ...
-
Page 2: Table Of Contents
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual Contents System components ......................... 2 1, Hardware‐Fresco‐S chassis front panel ................. 2 2, Hardware‐Fresco‐S chassis rear panel................... 2 3, Equipments connection diagram .................. 2 Description of equipments connection ................... 3 1, Equipments preparation ....................... 3 2, Start‐up settings ........................ 3 3, Start‐up test and verification .................... 6 ... -
Page 3: System Components
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual Fresco‐S Multi‐viewer Quick Setting‐up Manual System components 1, Hardware‐Fresco‐S chassis front panel 2, Hardware‐Fresco‐S chassis rear panel 3, Equipments connection diagram 2 ... -
Page 4: Description Of Equipments Connection
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual Description of equipments connection 1, Equipments preparation 2 PCs are control terminal and monitor end. Multiple Fresco‐S multi‐viewer chassis (cascading according to real needs). Big screens used to display multi‐viewer output signals. Signal sources and signal cables which take function of connection between signal sources and multi‐viewer chassis (according to real needs). ... - Page 5 Dayan ng Technology Dev velopment Inc F Fresco‐S Multi‐view wer Quick Setting‐ ‐up Manual Next, p plug two pow wer supply ca bles, take do own front pan nel, and turn n on left and right side power switch. In th he process o of multi‐view wer ...
- Page 6 Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual After configuration, open MVDesign software, press connect button in software window to pop‐up login window, input IP address in starting up interface of Fresco‐S chassis (such as 100.0.2.129), the default password is admin, then press login button. After login, click 【Device】 menu, choose 【Network Setup】 to pop‐up 【Network Setup】 window. users are able to modify IP, subnet mask and gateway based on real requirements. Users can also modify default password. Click 【 Device】 menu, choose 【 Modify Password】...
-
Page 7: 3, Start-Up Test And Verification
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual When complete modification of IP address and login password, can use new IP and password to login Fresco‐S multi‐viewer. 3, Start‐up test and verification After successful start‐up, need to test Fresco‐S inputs and outputs. In test process at least need one SDI signal source (traditional device), one HDMI signal source (laptop), one displayer ... -
Page 8: 4, The Settings Of Key Parameters
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual Orderly connect all SDI signal sources to four modules with 16 SDI inputs in all, and orderly connect all HDMI signal sources to four modules with 4 HDMI inputs in all, verify normality of each signal by use of displayer. In the meantime, users can also check HDMI outputs and HD‐SDI outputs. By this way can quickly judge outputs and inputs of multi‐viewer are whether normal or not. if there are any problems with VA modules, please contact customer service to change. ... - Page 9 Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual video standard to 1080/50P (default) or 1080/59.94P. Lower is the part of audio config, digital audio input is for default, and Audio Group represents the sequence of modules. 2) Video config With regard to probing "video frozen" and "video black" of video signal. For digital signal, ...
-
Page 10: 5, Interaction Between Control Terminal And Fresco Equipment
Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual The probing thresholds of audio overload and audio too low are related to maximum value and minimum value. the empirical value of former is ‐6dBFS, and ‐20dBFS for later. i.e. audio under ‐20dBFS is considered to be too low, and audio over ‐6dBFS is too high. 5, Interaction between control terminal and Fresco equipment Start MVDesign software, and login specified Fresco‐S multi‐viewer by its IP address, import proper layout templates according to practical use and based on this to complete quick edit ... - Page 11 Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual In edit area, can modify current layout template, like following picture. After finish edit, save this layout. Use " Synchronism" button to upload layout of control terminal to multi‐viewer and display it in the screens. Can also use "Reverse Synchronism" button ...
- Page 12 Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual Analog Clock LOGO Alarm frame Text Volume Meter 4:3 video 1 16:9 video PIP Metadata Info. 4 3 Tally Signal UMD Video Background This layout is one of layout templates in Fresco‐S, including video, volume meter, text, UMD, video background, analog/digital clock, metadata and some other frequently used elements. The numbers shown on layout indicate the output sequence of displayers. Users are able to overlay video windows on background or not. Volume meters can be ...
- Page 13 Dayang Technology Development Inc Fresco‐S Multi‐viewer Quick Setting‐up Manual their needs to achieve best display effect. 12 ...
