Corintech EL-WiFi-TP Quick Start Manual

Thank you for purchasing a Corintech EL-
WiFi-TP sensor. This device measures the
temperature of the environment in which the
probe is situated and transmits data to a PC
via WiFi. This quick start guide provides basic
information to help you use your new product.
Getting to know your Sensor
Alarm Icon Max/Min Icon
Signal Icon
Temperature Display
Connect Probe Warning
Probe Connection Port
Screen Cycle Button
Your sensor will arrive partly charged but
ideally you should charge it for 24 hours before
use for optimum performance.
Your sensor is already displaying a temperature
reading but it will not be configured or connected
to your WiFi network until you complete the
product set-up.
Your sensor is set-up using a free software
package called EL-WiFi which is available at
Battery Icon
www.corintech.com/support.
downloads icon and select the EL-WiFi download
for the latest version of software. Once this
Temperature Scale
package is installed you're ready to set-up your
sensor.
First ensure the probe is plugged in to the
sensor then click on the EL-WiFi software icon
which is now on your PC desktop to open the
package and then click on the 'Set-Up Sensor'
USB Port
button. You can now work through the different
stages of set-up which include establishing
Getting Started
the WiFi connection between your sensor and
your PC, naming each sensor, setting alarms,
sample rate and temperature scale.
Basic data can be viewed on the
screen of the sensor.
To view this data press the button
to cycle through the different
Click on the
screens.
Set-Up
2. Max Recorded Value
Detailed information and graphical data needs
to be viewed via the EL-WiFi software package
already downloaded to enable set-up. Open
the package and click on the 'View Sensors'
button.
Viewing Sensor Data
1.Home Screen
OR
3. Min Recorded Value 4. Signal Strength 5. Data Syncing
