Kit contents
1-Swing out gate
1-large bearing
1-small bearing
1-seal for bearing
Tools recommended for installation
1-large adjustable wrench or channel locks
1-red grease
Rear swing out shown with optional Jerry can holders on both sides.
____________________________________________________________________________________
Installation Instructions
FJ Cruiser swing out gate
DEMELLO-OFFROAD
www.demello-offroad.com
Page 1 of 7
INSTALLATION INSTRUCTIONS
Swing out Gate installation and
accessories
2007-2016 Toyota FJ Cruiser
phone:
1-951-735-4417
fax:
1-951-735-4644
1-carter pin
1-aluminum cap
1-large washer
1-castle nut
1-allen wrench 1/8in
1-rubber mallet
www.demello-offroad.com
