f i r e - p a r t s . c o m
Control Number 4006611
External Roof-mounted Power Vent System
External Roof-mounted
Power Vent System
Installation,
Operation
Owner's Manual
Please read this manual thoroughly before beginning the
installation. It has information which is important for safe
installation and operation.
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
-- Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
INSTALLER: Leave this manual with the
appliance.
CONSUMER: Retain this manual for future
reference.
and
1
August 16, 2017
EuropeanHome.com
Advertisement
Summary of Contents for European Home ERPVS
- Page 1 External Roof-mounted Power Vent System Installation, Operation Owner’s Manual f i r e - p a r t s . c o m Please read this manual thoroughly before beginning the installation. It has information which is important for safe installation and operation.
-
Page 2: Table Of Contents
TABLE OF CONTENTS Important Safety Information Product Information Venting Requirements Installation Operating the System Troubleshooting Warranty Appendix A f i r e - p a r t s . c o m EuropeanHome.com External Roof-mounted Power Vent System... -
Page 3: Important Safety Information
- p a r t s . c o m TO REDUCE THE RISK OF FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: 1. This system is intended for use with European Home products 4. Follow the appliance manufacturer’s guidelines and safety ONLY. -
Page 4: Product Information
OVERVIEW The ERPVS is approved for use with the entire line of Element4 fireplaces. It accepts 5” x 8” venting and is intended for external, roof- f i r e - p a r t s . c o m mounted use ONLY. - Page 5 5. Startup and Configuration ......................4 67 01.13 1. Product Information 1.1 Function 2. Specifications PRODUCT INFORMATION The PDS 1, Proven Draft Switch, is a fixed position differential pressure switch that is used in conjunction with ENERVEX’s Mechanical Draft Systems for insufficient draft protection. If an unsafe draft condition occurs, whether this is caused by mechanical or electrical failure, the switch will shut down the heating Dimensions &...
- Page 6 PRODUCT INFORMATION Solenoid Gas Valve (PV-GS-SGV-02) Voltage 1 x 120V AC DS 1 must be installed in a vertical position with the pressure Wattage 17.1 using the mounting holes as shown on the figure. After installation marked accessible through the small of the plastic enclosure. Temp. Limit 125°F PDS. Pipe Size 1/2”...
- Page 7 PRODUCT INFORMATION Rain Shield Exhaust Connector Stack Probe Mounting Holes f i r e - p a r t s . c o m High Temperature Grommet (inside) Fan Mount Figure 1. Exploded View of PV-VM-FMA-01 Fan Mount Assembly EuropeanHome.com External Roof-mounted Power Vent System...
-
Page 8: Venting Requirements
In all installations of this power vent system the following MUST be observed: • With the ERPVS, the maximum allowable horizontal or vertical length of the fireplace venting is 82 feet (25 meters.) This distance is measured between the top of the fireplace and the top of the PV-VM-FMA-01 fan mount. - Page 9 VENTING REQUIREMENTS f i r e - p a r t s . c o m Figure 3. Configuration is NOT Permitted - Too Many Elbows Figure 4. Configuration is NOT Permitted - Venting Goes Too Far Down EuropeanHome.com External Roof-mounted Power Vent System...
- Page 10 VENTING REQUIREMENTS VERTICAL VENT TERMINATION CLEARANCES Termination Heights for Vents Above Flat or Sloped Roofs Termination Heights for Vents Above Flat or Sloped Roofs Refer to NFPA 54/ANSI Z223.1 Horizontal Overhang Roof Pitch Feet ters Vertical Wall Flat to 6/12 2 Ft.
-
Page 11: Installation
Mount to Chase The ERPVS arrives from the factory with the Stack Probe mounted onto the Exhaust Connector and six feet of silicone tubing attached to the Stack Probe. After mounting the proven draft switch (PDS, see below), the silicone tubing must be pushed firmly onto the gray (NEGATIVE -) port of the PDSonto the Stack Probe. - Page 12 Danger: Turn off electrical power before servicing. Contact with live ele cause shock or death. INSTALLATION All electrical wiring must be in accordance with requirements of authority having jurisdicti requirements, with National Electrical Code NFPA 70 — latest edition. If an external elec system must be electrically grounded in accordance with requirements of the authority ha With the Stack Probe aligned with the grommet, insert the Exhaust Connector into the venting and lower the Connector over the absence of such requirements, with the National Electrical Code NFPA 70 —...
- Page 13 Fig. 1 INSTALLATION ADC100 ADC100 3916067 01.13 DAMPER (SOLD SEPARATELY) ENERVEX 3. Mechanical Installation PDS1 ENERVEX® 3.1 Location ENERVEX The ADC100 Control Unit must be installed indoors. As shown in the diagram below, the control will be wired directly to a 120/1/60 VAC power supply. The control will also be connected to the fan, appliance and damper (if used).
- Page 14 INSTALLATION INSTALLATION MUST BE PERFORMED BY A QUALIFIED INSTALLER, SERVICE AGENCY OR THE GAS SUPPLIER. Note Work with gas components must be performed by a licensed plumber or gasfitter within the Commonwealth of Massachusetts. f i r e - p a r t s . c o m Electrical work must only be performed by a qualified, licensed electrician.
- Page 15 Some jurisdictions require a disconnect switch near to the fan. A disconnect switch is not provided with the ERPVS but may be supplied locally and wired as in Figure 9. If provided, this switch controls the fan so the system will not work when this switch is off.
- Page 16 INSTALLATION Power Vent This part must be installed indoors. E4-SA-WS-80 This part has a 26’ ca- PV-ES-PLS-WHT ble (which may NOT This part is delivered be extended) con- PV-GS-CM-ADC 100 as two devices; light nected to the fireplace This part must be in- and switch.
- Page 17 INSTALLATION 3916067 01.13 ENERVEX® 4.2 Connection Diagram The connection diagram below shows typical connections The connection diagram shown in Fig. 7 below shows typical connections for a single phase fan. If a 3-phase fan is used, a VFD must be connected between the fan and control. Fig. 7 f i r e - p a r t s .
- Page 18 - 3 (Right) ON The ERPVS must be set to produce at least 0.05” w.c. of negative draft pressure. After connecting a manometer (not included) to the system (follow the instructions for the manometer) adjust the fan speed potentiometer until -0.05” w.c. pressure is reached.
-
Page 19: Operating The System
OPERATING the SYSTEM TURNING THE SYSTEM ON Turn the PV-ES-PLS-WHT switch to the ON position. The fan will provide negative pressure (draft). Once the fan has generated enough draft to reach the draft set-point, the PV-ES-PLS-WHT indicator lamp will light and the PV-GS-SGV-02 valve will open. The gas fireplace is now ready for normal operation via the E4-SA-WS-80 wall switch or the remote control. -
Page 20: Troubleshooting
TROUBLESHOOTING 3916067 01.13 ENERVEX® 5.2 Sequence of Operation The sequence of operation flow chart is shown in figure 11 below. Fig. 11 Maintain Flashing State Idle State De- Energize for 30 seconds All for Retry Aux In Enabled Taking longer than One Flash Open Damper 90 seconds Alarm Damper Open Proof Two Flash VFD and Fan Initial PDS Proof Alarm... - Page 21 TROUBLESHOOTING 3916067 01.13 Automatic Mode: 1. Fan runs at speed setting of the potentiometer but cannot be adjusted using the potentiometer during operation. 2. If the Proven Draft Switch opens, the fan begins to ramp up. 3. If PDS closes, fan speed remains at that speed. 4.
- Page 22 European Home Warranty European Home Power Vent European Home warrants this product against defects in materials and workmanship for a period of TWO (2) YEAR from the date of original retail purchase. If a defect exists, European Home will, at its option, either (1) provide needed components using new or refurbished replacement parts or (2) exchange the product with one which is new or which has been manufactured from new or serviceable used parts and is at least functionally equivalent to the original product.
- Page 23 NOTES f i r e - p a r t s . c o m...
- Page 24 EUROPEAN HOME f i r e - p a r t s . c o m a division of Europa Ja, Inc. 30 Log Bridge Road Building 300 - Suite 303 Middleton, MA 01949 www.europeanhome.com IGEPVSIOOM-170816 EuropeanHome.com External Roof-mounted Power Vent System...
