- Page 1 BIK-01AM Broadband Radio Signal Indicator OPERATION MANUAL © TS-Market...
- Page 2 Overlook Broadband indicator of radio signals BIK 01AM (hereinafter - the product) is designed to detect and determine the location of different signal sources (GSM, DECT, BT, WF, WM, etc.), distinguishing between continuous and pulsed signals, and to roughly estimate their radiation power. The product is equipped with a built-in economy LED flashlight.
- Page 3 • Dimensions: 48 x 32 x 12 mm • Weight (with battery): 18g Operating the Device Power Voltage Testing and Battery Replacement At each powering the device check power supply status (CR2032 lithium battery) which is displayed on the indicator within 2 seconds. With a battery fully charged there are 5 LEDs on, and while discharging their number decreases.
- Page 4 Signal Detection Mode The product provides three display modes when it detects a signal: • silent - red LED is flashing: single pulses of 256 ms and pulse repetition cycle of 512ms when receiving continuous signals and double pulses with total duration of 256ms and repetition cycle of 512ms when taking the pulse signals;...
- Page 5 Searching for Radio Signal Source To set the mode of searching for radio signal source, double-click the button briefly. In this case, left green LED will be flashing without any signal. When the source of signal appears and as approaching it, the number of LEDs will increase, with each signal light flashing and then staying on all the time.
- Page 6 Use of LED flashlight To activate flashlight, press and hold the button until white LED light is on the end of the case and the subsequent double increase in brightness every 2s. Release the button at the desired brightness. To avoid wasting battery capacity it is recommended to set minimum light intensity.
- Page 7 Warranty The warranty period for the product is 1 year from the date of sale. Claims under the warranty will not be accepted in case of: - No signature and seal on the document; - Incompleteness of the product; - Damage to the case, printed circuit board and elements on it.
- Page 8 BIK-01AM Broadband Radio Signal Indicator Number: ________________________________ QC:____________________________________ Selling date: _____________________________ Seller: __________________________________ Address: Market Ltd. Building 10/1 Sosnovaya Alleya, Zelenograd, Moscow, The Russian Federation, 124489 Tel: +7 (495) 638-8800; +7 (495) 651-91-51 (Cell) +7(903) 530-10-01, +7 (909) 638-88-00 Fax: +7 (495) 535-0491 E-mail: support@ts-market.com...
