Alfer combitech Manual

17
18 21
19
20
combitech
®

forcing bed cover

Shopping list

combitech
® profiles
Product name Dimension Item no.
angle bracket, untreated aluminium 11.5 × 1.5 mm 25564
angle bracket, untreated aluminium 7.5 × 1.0 mm 25562
flat bar, untreated aluminium 15.5 × 2.0 mm 25806
tube, 1 short side piece, untreated aluminium M 5 26062
tube, 2 side pieces 90°, untreated aluminium M 8 26304
tube, 2 side pieces 180°, untreated aluminium M 8 26224
thread rod, PA natural M 5 30042
square tube 1 side pc., untreated aluminium 7.5 × 14.0 × 1.0 mm 25882
combitech
® small parts
Product name Dimension Item no.
tube, 1 short side piece, finished aluminium M 5 26042
hexagonal nut, PA natural M 5 30092
blind rivets 5 × 10 mm
glass

Notes

Pre-cut parts list

Important advice!

Assembly instructions

Total quantity Quantity Pre-cut part
All parts must be original alfer
8 m 4 982 mm
4 390 mm not be used. Basic technical knowledge is required for assem-
2 700 mm bly.
In case of technical difficulties, advice can in some circum-
2 m 4 383 mm
2 m 2 150 mm stances be sought from staff at the hardware store or possibly
from alfer
2 m 2 668 mm ® itself. If difficulties arise during assembly, an enquiry
should always be put to alfer
4 150 mm
3 m 4 300 mm not deviate from the assembly instructions. Changes to materi-
1 1000 mm als or deviations from the assembly instructions can cause
1 m 2 495 mm safety defects, which in case of damage may well be attributed
to such a deviation. In case of damage arising from such devi-
3 m 2 985 mm
ations, alfer
2 50 mm ® accepts no liability.
4 m 4 1000 mm

Instructions for use

Total quantity Quantity Pre-cut part The permitted loading capacity must not be exceeded.
2 bags 4 Inappropriate use will result in the right to compensation being
excluded.
2 bags 8
48
2 365 × 1000 mm
2 980 × 295 mm Wutöschingen June 2002
4 340 × 490 mm
alfer
® aluminium Gesellschaft mbH
Horheim, Industriestraße 7 · D-79793 Wutöschingen
tel.: +49 (0) 77 46 / 92 01-0 · fax: 92 01-92
email: info.eng@alfer.com
You can find more ideas on the Internet!
Important advice!

Technical data:

combitech
® forcing bed cover dimensions:
length 100.0 cm
width 75.0 cm
height 50.0 cm
All dimensions are reference values. Subject to technical
changes.
very demanding
demanding
simple
easy
alfer
®
combitech
® parts. Damaged parts should
®

construction plan

forcing bed cover
® before changing components. Do
English
4-5 hrs
