Walk Through Metal Detector
User Manual
MD-WT-ADV-24
Aventura Technologies 48 Mall Drive Commack, NY USA 11725 Tel: 1-631-3900-4000 Fax: 1-631-434-7000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD-WT-ADV-24 and is the answer not in the manual?

Questions and answers

Related Manuals for Aventura MD-WT-ADV-24

Summary of Contents for Aventura MD-WT-ADV-24

  • Page 1 Walk Through Metal Detector User Manual MD-WT-ADV-24 Aventura Technologies 48 Mall Drive Commack, NY USA 11725 Tel: 1-631-3900-4000 Fax: 1-631-434-7000...

  • Page 2: Table Of Contents

    Frequency Adjustment ........................ 22 Alarm Definition .......................... 22 Date/Time Setting ........................23 Language Setting ......................... 24 Password Setting ......................... 24 Alarm Query ............................ 24 Query Search ..........................24 Query Results ..........................25 Page | 1 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 3 More Menu Settings ........................25 Display Brightness ........................25 Signal Outputs ..........................26 Software Version ......................... 26 Application Type ......................... 26 Maintenance and resolution of problems ..................27 Appendix ............................29 Page | 2 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 4: General And Regulatory Information

    ！ Notes: Thank you for purchasing this Aventura walk-through metal detector. The following important material is intended to advise you how to instal and operate this product safely and correctly. Please read it carefully make sure you understand these points before you move on to other parts of the manual.
  • Page 5 Deviations from these instructions should only be made to comply with local laws, regulations and government requirements. 9. The Manufacturer reserves the right to change the structure, software or accessories of the equipment, or the contents of this manual without notice. Page | 4 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 6 European Union. For proper recycling, return this product to your local supplier upon the purchase of equivalent new equipment, or dispose of it at designated collection points. For more information, see www.recyclethis.info. Page | 5 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 7: Product Description

    These walk-through metal detectors can be employed in high-security loss prevention applications involving precious metals such as in industrial and mining enterprises, and in banks as well as other Page | 6 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 8: Features

    Frequency: 100 selectable frequency bands, with frequency auto self-selection during boot up. • Screen: 7"color screen, 800X480 resolution. • Backup power (optional): operates on battery power 8 hours or more (battery: 17.5V 16.8Ah). • Page | 7 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 9: Operating Modes

    False Alarm An alarm caused by reasons other than metal objects, such as electronic interference. An alarm caused by metal objects (harmless or useful) is not considered a false alarm. Page | 8 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 10 WTMD. Key Test Objects Objects used in a set of testing equipment that requires the highest detection sensitivity and are the most difficult to detect. Page | 9 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 11: Principles Of Operation And Design Criteria

    It is essential to minimize any effects on the operation of the WTMD produced by different interference sources. Page | 10 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 12 (Rx) is farther away from the interference source than the transmit panel. The distance between WTMD and interference sources is sufficient if, when the device is ready, the indicator in the display area shows no more than 1-2 bars. Page | 11 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 13: Installation Considerations

    Consider the following suggestions when designing the checkpoints: Arrange the queues waiting to enter the detectors to ensure that only one person passes through the WTMD at a time; Page | 12 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 14: Parallel Operation

    F1, F2, and F3. The separation distance during parallel operation depends on the sensitivity level and the frequency combination. The minimum operation distance is decided by the conditions of the installation site. Page | 13 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 15: Assembling The Unit

    WTMD on the same frequencies. Figure 4 SSEMBLING THE Properly trained contractors shall perform equipment installation and calibration. Carefully open the packaged boxes and remove the panels from the boxes Figure 5 Page | 14 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 16 Remove the main chassis from the box and lay the main chassis and panels as shown Figure 7 Figure 8 Assemble the panels to the main chassis. Use a hex tool to tighten the bolts. Page | 15 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 17: Site Selection Considerations

    If multiple detectors are used close to each other, they should be spaced at least 30–50cm apart and the frequency of operation of each should be adjusted to reduce mutual interference. Page | 16 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 18: Controls, Indicators, And Settings

    5 seconds will power the machine off. When the screen is in Options Menu, pressing the Power button will revert to the previous options menu (or will exit return the user to the normal operation screen). Page | 17 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 19: Remote Control Unit

    After system turn on the systems enters the self-check interface (Figure 15), displays an image of the walkthrough metal detector, and self-checks the voltage and zones, then enters standby mode. Page | 18 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 20: Programming And Adjusting Settings

    000000. A short press on the Power button will return to the previous menu; a long press with turn the power off/on. Figure 17 Page | 19 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 21: Sensitivity Adjustment

    999. SENSITIVITY IS ADJUSTABLE BETWEEN RESS THE NTER BUTTON TO SAVE THE SETTINGS AND MOVE TO THE NEXT ZONE RESS THE POWER BUTTON TO RETURN THE PREVIOUS MENU Figure 21 Page | 20 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 22 Model Number MD-WT-ADV-24 User Guide Zone schematic diagram for 6 and 18 zones: Figure 22 Page | 21 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 23: Frequency Adjustment

    Press the Enter button to save the settings and return to the previous menu Figure 25 LARM EFINITION There are three available settings for Alarm Definition: Ring, LED and Zone (Figure 26) Figure 26 Page | 22 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 24: Date/Time Setting

    Press the Enter button to save the settings and return to the previous menu. Figure 29 Page | 23 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 25: Language Setting

    Year/Month/Day items. The “0” at the bottom of the figure refers to the number of matching alarm records found. Figure 32 Page | 24 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 26: Query Results

    (Figure 35) to set the display screen brightness. Use the left and right buttons to adjust the brightness. Press the Enter button to save the settings and return to the previous menu. Figure 35 Page | 25 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 27: Signal Outputs

    (Figure 39), use the up, down, left and right buttons to select a situation that approximates your application. Press the Enter button to save the settings and return to the previous menu. Figure 38 Page | 26 ©2018 Aventura Technologies, Inc. All rights reserved.

  • Page 28: Maintenance And Resolution Of Problems

    No count door. It will emit a glowing red dot, component 0001 or 0000, which means the infrared emission is or no count normal. If not, the infrared is broken. Page | 27 ©2018 Aventura Technologies, Inc. All rights reserved.
  • Page 29 Normally it is because the sensitivity alarm when is too low. Try to increase the Debug capture card people pass sensitivity of each zone with metals For additional Troubleshooting and Support, please contact Aventura Technologies Inc.: Tel: +1.631.300.4000 Fax: +1.631.434.7000 Email: techsupport@aventurasecurity.com Page | 28 ©2018 Aventura Technologies, Inc.

  • Page 30: Appendix

    Model Number MD-WT-ADV-24 User Guide 8.0 A PPENDIX Page | 29 ©2018 Aventura Technologies, Inc. All rights reserved.
