Summary of Contents for Wassermann Dental-Maschinen SIDOMIX
- Page 1 Mixing and dosing unit SIDOMIX USER MANUAL...
- Page 2 Keep this instruction manual in a safe place where it can be referred to as required at any time. Company address: Wassermann Dental-Maschinen GmbH Rudorffweg 15-17 D-21031 Hamburg, Germany Tel. : +49 (0)40 / 730 926 – 0 Fax.: +49 (0)40 / 730 37 24 E-mail: info@wassermann-dental.com...
-
Page 3: Table Of Contents
Index 1 Features .......................... 4 2 Safety guidelines ......................4 2.1 Safety symbols used in this manual ................4 2.2 Safety guidelines ....................... 5 3 Application ........................5 4 Before starting ......................... 6 4.1 Transport........................6 4.2 Installation........................6 4.3 Storage........................6 5 Start-up / Installation ....................... -
Page 4: Features
Features Mixing and dosing of addition-vulcanazing 1:1 two-component silicones. For even dosage of both components, both must have similar viscosity. Advantages: • Mixing head with separate output openings – mixing of A and B components while mounting or dismounting the mixing cannula is impossible •... -
Page 5: Safety Guidelines
Safety guidelines Always keep the two silicone components separated – never mix up the connections! The mixing of components would cause the silicone within the device to harden, making extensive repairs of the device in the Hamburg plant necessary. Drill a ventilation hole using a drill or similar tool at the upper side edge of the 1 litre bottle or 6 kg or 25 kg can. -
Page 6: Before Starting
Check the included accessories. Install the device on a stable, level surface. Do not install the SIDOMIX outdoors or in places without proper ventilation. Before start-up, be sure the device reaches room temperature. Install the device in a place where it will not block the working area and the functionality (take the dimensions into account). -
Page 7: Start-Up / Installation
Start-up / Installation Connect the power cord. Remove the closing plugs from the connections and dosage head. When using 2 litre material containers (included): Fill the material container with the relevant component. Warning: Insert the container filled with coloured silicone compound – component B –... - Page 8 When using 25 kg bulks: Note that while using bulk containers, the cans must be positioned at a height higher than the device. Optional pad stands are available on request. Remove the closings from the cans filled with two component silicone and screw connection hoses onto the cans.
-
Page 9: Operation
Operation Switch on the device; the toggle switch lights green. To clean the pipes and dosage pump, perform the following upon first start-up as well as when replacing the bottles: Position a container under the mixing head without the mixing cannula, press the red button and hold it until both components run evenly and without bubbles from the mixing cannula adaptors. -
Page 10: Troubleshooting
Troubleshooting Problem Cause Remedy No silicone output. Hardened material Mount a new mixing cannula. within the old cannula. No silicone output. Mixing head clogged. Clean mixing head carefully. Warning: Silicone components must not get in contact with each other! No silicone output. A and B component The device needs to be disassembled and was mixed up;... -
Page 11: Care And Maintenance
Always keep the mixing cannula adaptor and the quick closings clean. Servicing The SIDOMIX does not require any servicing. Just make sure that the device is kept clean. Warranty The warranty period for our equipment is 12 months. If faults occur within the warranty period, contact your dental depot or get in touch directly with our Service department. -
Page 12: Scope Of Delivery / Accessories
Scope of delivery / Accessories Included parts: Part no. Material container set with quick coupling, 2x2 litres 172640 Mixing cannula, pink 100 pieces 622022 Accessories: Part no. Mixing cannula, pink 100 pieces 622022 Foot switch 174175 Retrofitting set for foot switch 172630 Material container set with quick coupling, 2x2 litres 172640... -
Page 13: Technical Data
Technical data Mixing and dosing unit SIDOMIX, 1:1 – item no. 172984 Dimensions: width: 290 mm, height: 310 mm, depth: 450 mm Weight: 11.5 kg Voltage*: 220-240 V / 50/60 Hz – 115 V / 50/60 Hz Output: 260 Watt Power consumption: 1.6 A... -
Page 14: Ec Conformity Certificate
Product description: Mixing and dosing Dental-Maschinen GmbH unit, 1:1, for Rudorffweg 15 - 17 dental D-21031 Hamburg applications Model: SIDOMIX Item-no. 172984 Aapplicable DIN EN 61010-1:2004 standards: DIN EN 61000-6-3:2005 DIN EN 61000-6-1:2002 DIN 45635-1:1984 DIN EN 60335-1:2007 Hiermit wird bestätigt, dass die oben bezeichnete Maschine den genannten EG-Richtlinien entspricht. - Page 15 Notes:...
