Summary of Contents for Netio PowerBOX 3PE

  • Page 1 PowerBOX 3PE PowerBOX 3PF PowerBOX 3PG QIG (Quick Installation Guide) QIG (Stručný průvodce instalací)
  • Page 3: Quick Installation Guide (Qig)

    Quick Installation Guide (QIG) Thank you for purchasing a product of NETIO products a.s. Before using your product for the first time, please read this short guide to avoid problems with incorrect installation or use. For more information, please see the User's Manual available at http://netio-products.com.
  • Page 4: Package Contents

    Package contents:  NETIO PowerBOX 3Px device  Quick Installation Guide (QIG) Status / control indication 1) 1x RJ45 LAN connector 2) RJ45 LEDs – device states (yellow and green) 3) Multifunction “SETUP” button LED and button functions OUTPUT LEDs RJ45 –...
  • Page 5: Before The First Use

    1) Connect your NETIO device to a LAN with a network cable (RJ45). 2) Connect the NETIO device to a mains electrical outlet with the power cable. 3) Wait about 1 minute until the device starts and receive IP address from DHCP server.
  • Page 6: Web Interface

    WEB interface The default username / password combination is admin / admin.
  • Page 7: Specifications

    90-240 V; 50/60 Hz; 16 A - PowerBOX 3PF 90-240 V; 50/60 Hz; 13 A - PowerBOX 3PG 16 A in total / 16 A each output - PowerBOX 3PE Switched outputs 16 A in total / 16 A each output - PowerBOX 3PF...
  • Page 8: Declaration Of Conformity

    DECLARATION OF CONFORMITY Manufacturer/Importer: NETIO products a.s. U Pily 3/103 Address: 143 00 Praha 4, Czech Republic NETIO PowerBOX 3PE NETIO PowerBOX 3PF Product: NETIO PowerBOX 3PG RTTED: The product mentioned above to which this declaration relates is in conformity with the essential requirements and other relevant requirements of the R&TTE Directive...
  • Page 10: Bezpečnostní Upozornění

    Stručný průvodce instalací (QIG) Děkujeme, že jste zakoupili výrobek společnosti NETIO products a.s. Před jeho prvním použitím si prosím pečlivě přečtěte tento krátký návod. Předejdete tak chybné instalaci či nesprávnému používání zařízení. Pro další informace použijte Uživatelský manuál, který naleznete na http://netio-products.com.
  • Page 11 V balení naleznete:  NETIO PowerBOX 3Px  Stručný průvodce instalací (QIG) Indikace stavu/ovládání: 1) 1x LAN Konektor RJ45 (počítačová sít). 2) RJ45 LED – stavy zařízení (žlutá a zelená) 3) Multifunkční tlačítko „SETUP“ Indikační LED diody RJ45 - zelená...
  • Page 12 3) Vyčkejte cca 1 minutu, než zařízení nastartuje a získá IP adresu od DHCP serveru. NETIO Discover 1) Najděte na našich stránkách NETIO Discover (MS Windows) a nainstalujte jej. 2) NETIO Discover najde všechna NETIO zařízení na síti a zobrazí je. Klikněte na IP adresu a otevřete webové rozhraní.
  • Page 13 WEB rozhraní Výchozí uživatelské jméno / heslo je admin / admin.
  • Page 14 90-240 V; 50/60 Hz; 16 A - PowerBOX 3PF 90-240 V; 50/60 Hz; 13 A - PowerBOX 3PG 16 A celkem / 16 A každý výstup - PowerBOX 3PE Spínané výstupy 16 A celkem / 16 A každý výstup - PowerBOX 3PF 13 A celkem / 13 A každý...
  • Page 15: Es Prohlášení O Shodě

    ES PROHLÁŠENÍ O SHODĚ Výrobce/Dovozce: NETIO products a.s. Adresa: U Pily 3/103, 143 00 Praha 4, Czech Republic NETIO PowerBOX 3PE NETIO PowerBOX 3PF Výrobek: NETIO PowerBOX 3PG RTTED: Prohlašujeme, že výše uvedené výrobky jsou ve shodě se základními požadavky nařízení...
  • Page 16 To find device on the LAN network Install NETIO Discover. On our website you can find – NETIO Discover for MS Windows – Discover in NETIO Mobile 2 app for Android Network mode Default LAN Cable DHCP client Default Web password Username: “admin”, password: “admin”...

This manual is also suitable for:

Powerbox 3pfPowerbox 3pg
