Summary of Contents for Sapa ALUMAX 1040 Series
- Page 1 INSTALLATION INSTRUCTIONS 1040 & 1050 SERIES HEAVY FRAMELESS BYPASS BATH ENCLOSURE www.alumaxshowerdoor.com Copyright © Alumax Bath Enclosures 2014. All rights reserved. G03711095 11-4-14...
- Page 2 !WARNINGS! INSTALLATION WARNINGS Alumax Bath Enclosures by Sapa are intended to be installed by an experienced installer. If you need assistance with locating an experienced installer, contact us at 1.800.643.1514 or go to our website www.alumaxshowerdoor.com to access our “dealer locator”. If a dealer is not listed in your area, call or send us an e-mail and we will find one for you.
- Page 3 G03711095 Page 3 of 8 11-4-14...
- Page 4 Measure the wall-to-wall opening along the center of the tub rim. Cut the tub track [A] 1/16” short of this dimension. An inexpensive miter box available at your local hardware store will help you get clean square cuts. If the vinyl silencer [V] is separate from the tub track [A] slide the silencer into the slot in the tub track and trim to the same length.
- Page 5 Replace one wall jamb [A] and attach it to the wall with three #8 x 1 1/2” truss head screws [D]. The top and bottom screws should go through a Jamb Bumper [E]. Check the jamb for plumb and tighten the screws. Repeat for the other wall jamb.
- Page 6 Attach the four one inch roller bearings [K] to the door hanger brackets [G] as shown, using #8-32 x 3/8” hex head screws [L]. The rollers should be in approxi- mately the top quarter of the diagonal slots in the bracket fins.
- Page 7 Locate the four, large hole, plastic washers [M] and place them over the threads and flush with the four end caps [N]. Next, place the four glass inserts [O] onto the four end caps [N] and flush with the plastic washers [M].
- Page 8 Neatly caulk each end of the tub track [A] where it meets the wall jambs [B] and along the interior edge of the wall jambs as shown. Run a bead of caulking along the interior edge of the tub track. NOTE: The caulking should be allowed to cure for twenty- four hours before using your new bath enclosure.
