Pro-Elec RCD-1UK Quick Start Manual

Plug In RCD

Specification:

Standard(s) BS7071, BS1363-3
Rating 13A, 250V ~ 50Hz
Service Conditions An ambient temperature range of -5°C to +40°C with an average value not exceeding
+35°C measured over any 24h period
An altitude not exceeding 2000m above sea level
Product Dimensions:
50mm × 120mm × 67mm
173g
Plug the RCD directly into a fixed socket and then plug the appliance into the RCD to allow it to be protected

Operating instructions:

Please read these operating instructions prior to use and always observe the test procedure below before each application to
ensure safe use.
1. Insert the RCD safety adaptor into a 13A mains socket and switch on
2. Press the RESET button and wait for the orange indicator to appear
3. Press the TEST button and the orange indicator will disappear from the CLEAR window
Important: Do Not Use If The Indicator Remains
4. Press the RESET button. The RCD has now been set for safe use provided the ORANGE indicator shows in the
CLEAR window

Safety Warning:

DO: Unplug from the mains before any inspection of the appliance
DO: Keep children away from sockets and electrical appliances
DO: Seek expert advice if you experience difficulties when setting up your adaptor or if it repeatedly trips when in use
DO: Store and use your adaptor between -5°C and +40°C
DON'T: Use your adaptor as a substitute for carrying out normal precautions when using your mains electrical power
