  • Page 1 ’ ’ J3 Seires...

  • Page 2: Preface

    This document is written to customer service personnel or the end users, who install, configure and commission the repeater system in a cellular network. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 3: Table Of Contents

    3.1 Downlink Output Power ....................... 13 3.2 Repeater Configuration ......................13 3.2.1 Start-up the Repeater ........................13 3.2.2 Repeater Settings ..........................14 Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
  • Page 4 4.2 Troubleshooting ........................22 4.3 Replacement........................... 23 5. APPENDIX ......................24 5.1 Abbreviations ......................... 24 Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...

  • Page 5: Introduction

    Repeater is easy, simply just plug and play. With the control panel in front of the repeater, the repeater status can be seen during installation. Figure 1 LED Indicators Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 6: General Installation Layout

    Notify that the users can’t adjust by manual setting when smart function is initiated. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...
  • Page 7 Device LED gain display panel will display device is reduced after the equipment current gain state, which has the advantages of convenient construction, but also to protect the base station equipment, and does not generate interference. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 8: Installation

    Choose frequency 920MHz to do the test. For DCS1800, uplink is 1710~1785MHz and downlink is 1805~1880MHz. Choose frequency 1795MHz to do the test. For WCDMA2100, system uplink is 1920~1980MHz and downlink is 2110~2170MHz. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 9: Precautions And Preparation

    The repeater is designed for indoor application. Ensure the location of the repeater is dry and ventilative. Ensure there are adequate resources to handle the weight of the repeater. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 10: Donor Antenna Installation

    The Rxlev of the signal, at the input to the BTS port of the repeater is suggested to be in the range of -55dBm to -70dBm The RxQuality index ranging from 0 to 2 is required. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 11: Server Antenna Installation

    It is suggested to install the repeater at least 2m above the floor for the best coverage. The server antenna should not be installed to close to the donor antenna to avoid issues with isolation. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 12: Repeater Installation

    Figure 3 Mark the holes ➢ Fasten the holder on the wall by screws. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
  • Page 13 ◼ Plug the power cable to the repeater first before plugging in the power cable to the mains socket. Use the power cable that comes with the package. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 14: Commissioning

    Make sure power supply cable is connected to the repeater properly, and the voltage is within repeater’s voltage working range: 110/220V ± 20%  Plug the power cord into the proper socket. Once the repeater is on, it requires Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...

  • Page 15: Repeater Settings

    Press the button to select between either uplink (UL) or Select UL or downlink (DL) for the band, the indicator represents either UL or DL you are at and intending to operate. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...
  • Page 16 The LED monitor is composed by 2 digits which displays the current gain value, when LED is blinking, the system is in the mode of setting the attenuation. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...
  • Page 17 Indicator indicates the Smart Function is ON Silent Function This indicator lights, uplink sleep function. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
  • Page 18 When the indicator is green, it is in normal status. Alarm2 Indicator When the indicator is red, it means the output power of system 2 is Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com...
  • Page 19 Step 2：Press STORE and LED monitor starts blinking. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
  • Page 20 Step 4：Press STORE to set the value and the LED stop blinking and showing the gain value at the moment, the process is done. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...

  • Page 21: Maintenance

    The power of PA is not stable DC is not stable, an UPS with square wave is recommended. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
  • Page 22 Please return the unit to place of purchase for repair. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...

  • Page 23: Troubleshooting

    ≧than 1 BCCH neighbor BCCH Consult the operator’s RF engineer. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...

  • Page 24: Replacement

    ➢ Lift the repeater off the wall If another repeater is not replaced immediately, protect the open-ended cables due to water hazard. Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...

  • Page 25: Appendix

    Temperature Uplink VSWR Voltage Standard Wave Ratio Signalwing Corporation Tel.: +86 0755 3323 3600 Fax: +86 0755 3323 3511 Email :info@signalwing.com Add. : 4F, No. 41A Bld, Huaide Cuigang No. 5 Industrial Park, Fuyong Street, Bao'an District, Shenzhen ,China 518103...
