Cucina 100mm Kitchen Fan
To ensure correct function and safety, please read all instructions before using the product and keep all instructions for future reference.
SPECIFICATIONS
Duct
Fan
(mm)
Speed
High
100
Medium
Compliance:
AS/NZS60335-2.80:2016
DIMENSIONS
A
B
A
B
C
231
261
137
TECHNICAL
Supply
Max. Operating Temp
220-240V AC, 50Hz
Installation Instructions
enquiry@manrose.co.nz | www.manrose.co.nz
Thank you for purchasing this quality kitchen fan.
When using electrical appliances, basic safety precautions should always
be followed to reduce the risk of fi re, electrical shock and personal injury.
Max.
Fan Watts
Fan Pressure
(W)
60
41
C
E
F
D
E
Ø F
79
58
98
IP Rating
40°C
IPX4
Specifi cations are subject to change without notice
Mounting
Wall, Panel or Ceiling
This powerful centrifugal fan, designed for easy installation and low
running noise, features kitchen and laundry installation boost levels
as well as a low speed option for long term trickle. The fan also
features a washable grease fi lter.
For best results, Simx recommend this product for either kitchen or
laundry applications.
Following these installation instructions, this product will comply with
the G4 Building Code for kitchens and bathrooms once installed.
The Healthy Homes Standard requirement for bathroom or kitchen
installation in a rental property is also met.
Max.
Free Air Fan Performance
(Pa)
(l/s)
236
73
140
39
D
Switching
Pull Cord
Specific
Fan Power
(W/l/s)
(m
3
/hr)
263
0.82
140
1.05
Distributed by Simx Limited
Order Code
FAN7201
Sound
dB(A)
52
38
Page 1
