Summary of Contents for EASTMAN NEVERCOLD 70601
- Page 1 FROM INSTALLS UNDE -SINK- USER MANUAL...
-
Page 2: How It Works
HOW IT WORKS SHOWER SINK CIRCULATOR WITH BUILT IN THERMOSTAT AND TIMER (INSTALLED FURTHEST POINT FROM HEAT SOURCE) Get hot water comfort at every faucet • Save time, no more waiting for hot water • Save hot water, up to 12,000 gallons a year •... - Page 3 70601 APPLICATION The NEVERCOLD™ circulators are designed to deliver hot water instantly at the point of use (under sink). Water savings can be as great as 12,000 – 15,000 gallons per year with 4-5 taps in a home. NEVERCOLD™ circulator is designed to be user friendly, reliable and to produce a professional installation.
- Page 4 REQUIRED TOOLS (2) - Pipe wrenches which open to at least 1-1/2" (1) - Adjustable wrench which opens to at least 1" (Figure 1) Cold Undersink Installation Instructions Hot Water Cold Water Supply Supply Pump Red Marking Cold Warning: Red mark on tting must be attached to Union Union the side of the pump with the red mark!
- Page 5 INSTRUCTIONS for NEVERCOLD™ Undersink Mount (see Fig. 1) 1. Locate the hot and cold shut off valves typically located near the faucet(s) under the counter. This faucet should be the furthest point from This faucet should be the furthest point from the heat source.
- Page 6 5. Attach the unions (gaskets, nuts and tail pieces) to the pump casing. The gaskets must be located between pump casing and tail piece. MAKE SURE MAKE SURE THE TAIL PIECE MARKED RED IS MATCHED UP WITH THE RED MARKING ON THE TAIL PIECE MARKED RED IS MATCHED UP WITH THE RED MARKING ON THE INLET SIDE (THAT IS OPPOSITE DIRECTION OF ARROW) OF THE PUMP.
- Page 7 7. Install the flex hoses by attaching one end to the remaining port of the Tee and the other end to the pump. MAKE SURE THE HOSE ATTACHED TO MAKE SURE THE HOSE ATTACHED TO THE HOT VALVE IS CONNECTED TO THE INLET SIDE (THAT IS THE OPPOSITE THE HOT VALVE IS CONNECTED TO THE INLET SIDE (THAT IS THE OPPOSITE DIRECTION OF THE ARROW) OF THE PUMP.
- Page 8 MECHANICAL TIMER OPERATION The timer will turn the circulator on and off based on the times when hot water is needed. This may only be in the mornings and evenings depending on the schedules of the residence. SETTING INSTRUCTIONS 1. To set the current time, rotate the outer ring until the arrow head lines up with the correct time.
- Page 9 REPLACEMENT CARTRIDGE INSTRUCTIONS CLEANING CARTRIDGE ASSEMBLY CLEANING CARTRIDGE ASSEMBLY NEVERCOLD™ NEVERCOLD™ pumps are specifically designed to prevent solid particles from entering the bearing / rotor chamber of the cartridge. However, in systems heavily contaminated by dirt, construction debris, etc., particles may enter the chamber on initial filling of the system and on rare occasions cause rotor blockage.
-
Page 10: Limited Warranty
US DESIGN, US BUILT, PATENTED. US: PAT. 8,183,500, PAT. 8,303,184, PAT. 9,328,736, PAT. 9,863,647, PAT. D834,145 CAN: PAT. 2,935,949, PAT. 2,883,495 LIMITED WARRANTY NEVERCOLD™ warrants its products to the original user against defects in material and NEVERCOLD™ warrants its products to the original user against defects in material and workmanship for a period of one (1) year from the date of consumer purchase. -
Page 11: Hot Water System
THANK YOU FOR PURCHASING A NEW NEVERCOLD™ HOT WATER SYSTEM! SAVE ENERGY EASY INSTALLATION INSTANT HOT WATER Can be installed in less than 30 Built-in timer only runs pump when Save time. No more waiting for hot it is set to run minutes water at every faucet SAVE WATER...
Need help?
Do you have a question about the NEVERCOLD 70601 and is the answer not in the manual?
Questions and answers
how to set up timer
To set up the timer on the EASTMAN NEVERCOLD 70601:
1. Rotate the outer ring of the timer until the arrow head lines up with the current time. (The timer uses a 24-hour clock: 1–12 = 1AM–Noon, 13–24 = 1PM–Midnight.)
2. To set the pump operating time, move all the tabs outward for the desired time range.
Example: For ON at 7:00 AM and OFF at 10:00 AM, move all tabs between 7 and 10 outward.
3. To set multiple on-off cycles, repeat step 2 for each desired time range.
4. Set the override switch:
- “I” = pump runs continuously.
- Clock symbol = pump follows timer settings.
- “O” = pump is off.
This answer is automatically generated
how to set timer
To set the timer on the EASTMAN NEVERCOLD 70601:
1. Rotate the outer ring until the arrow head aligns with the current time (24-hour format; 1–12 = AM, 13–24 = PM).
2. Move all tabs outward for the desired pump operating times. For example, to run from 7:00 AM to 10:00 AM, move all tabs between 7 and 10 outward.
3. Repeat step 2 to set multiple on-off cycles.
4. Use the override switch:
- "I" = Pump runs continuously.
- Clock symbol = Pump follows timer settings.
- "O" = Pump is off.
This answer is automatically generated
I **** missing the union fittings for a never cold 70601 circulation pump. Where can I get these?
The union fittings for the EASTMAN NEVERCOLD 70601 circulation pump are attached to the pump casing. They include gaskets, nuts, and tail pieces, with the gaskets positioned between the pump casing and the tail piece. Ensure the tail piece marked red matches the red marking on the inlet side of the pump.
This answer is automatically generated
