Summary of Contents for Green Feathers NC701G
- Page 1 Wireless Bird Box Camera Kit Quick Start Guide Please read me before you start!
-
Page 3: Table Of Contents
1. Camera setup Congratulations! You are now the proud 2. Connect to your TV owner of a Green Feathers Bird Box Camera. 3. Physical installation For years we have been a leading provider of wildlife cameras and our bird box 4. -
Page 4: Camera Setup
1. Camera Setup Antenna Before installing the camera in your nest Lens box, wire it up inside the house first to Bracket make sure everything is working as it IR LEDs should. Power in The first thing to do is to remove the lens cap and power up the camera using the mains power supply. - Page 5 Wireless Channel Sticker 1 2 3 4 Channel Selector Switch To TV/Recorder Television/Recorde...
-
Page 6: Connect To Your Tv
2. Connect to your TV Make sure you can get an image on your TV before mounting the camera outside. A. Direct Connection If your TV has RCA (phono) connections, you can connect the AV cable directly to your TV. Simply plug in the yellow and white plug into corresponding ports on your TV. - Page 7 B. Connection via HDMI Most modern TVs do not have RCA inputs Need a converter? Search on our website for RCATOHDMI and instead have HDMI as an industry search standard. Use one of our converters to upscale the video output from the receiver to your HDTV.
-
Page 8: Physical Installation
3. Physical Installation Now you are ready to mount the camera into your nest box. What you will need Check Wireless Distances M Camera with bracket (included) Check the distance between the camera Broadcas M 5M screw (included) and receiver before you install the camera M Nest box (optional) into the bird box. - Page 9 Mount the Camera in Nest Box Inside Box Rear of Installing in one of our bird boxes: Pass the 5M screw provided through the pre- drilled hole in the back of the box, screwing into the nut on the easy mount bracket. Our innovative anti-slip bracket design will hold the camera in place against the wood.
- Page 10 Where to place your bird box Diff erent birds have diff erent needs when it For sparrows, starlings, tits and spotted comes to choosing where to place your bird fl ycatchers you should place your bird box 2 box. Generally you should look to place your to 4 metres high and slightly covered with a box in a quiet spot in the garden amongst clear entrance.
- Page 11 5 metres Woodpeckers, Owls 3 metres Sparrows, Tits, Starlings 2 metres Robins, Wrens 11 11...
-
Page 12: Accessories
4. Accessories Now it’s time to install your accessories (sold separately). Connect to your PC or Mac If you’re using one of our USB Capture To learn more about using your USB Capture Devices to view and record your camera on Device, please visit our Help website. - Page 13 Boost the Light in your Nest Box Your camera’s night vision helps to improve the picture at night but you can also benefit from adding an extra light source to improve daytime images. Use one of our Lamp energy-efficient LED lamps to help with this. Our daylight lamps automatically switch Not used off at night to ensure the birds are not...
-
Page 14: Troubleshooting
Please be mindful Find more help online. that thick materials and windows can signifcantly reduce signal strength. Can this Go to Mouse-Po green-feathers.co.uk/help be improved by moving your receiver or and search NC701G. camera’s location? - Page 15 Changing the Wireless Channel of your Camera Changing the wireless channel of your Broadcas camera is useful when adding additional cameras or troubleshooting wireless interference. Locate and remove the black rubber bung on the back of your camera as shown to the right.
- Page 16 If you require more assistance setting up your bird box camera or you need further support then please head to our Help website where you’ll be able to find all our support guides and videos. Find more help online. Mouse-Po green-feathers.co.uk/help Go to and search NC701G.
- Page 17 Dear Customer, We, Open 24 Seven Ltd., hereby declare that the product: Green Feathers Wireless Bird Box Camera Conforms to the appropriate standards to achieve CE. To fi nd out more information on the conformity of this product please visit our website and search for your product code or use the link below.
- Page 18 Something fun for a Saturday afternoon to attract wildlife into your garden. Great in winter when food is scarce. Productive, enjoyable and most of all cheap! Types of Container Ingredients Equipment Yoghurt pots Lard or suet Mixing bowl Coconut shells Bird seed Saucepan Small plant pots...
- Page 19 Method Melt the lard/suet into the saucepan, don’t let it burn Once melted, put all dry ingredients into a mixing bowl and then add the lard/suet. If you are going to mix everything together using your hands then make sure that the fat has cooled down enough before you get your hands stuck in! Preparing the containers.
- Page 20 For more help visit: green-feathers.co.uk/help Ver: 2008NC7...
