ISO 9001 : 2015
NL/PRO 238239125
van 't Hoffstraat 12
2665 JL Bleiswijk, The Netherlands
T. 31 (0) 10 522 43 73
tcc-ic-man.docx Rev 2.0 UK 1017
USER-MANUAL
Tamson Cool Cube
Immersion Cooler
Tamson Instruments bv
www.tamson.com
info@tamson.com
VAT: NL 80 66 34 984 B01
Bank account no.:
NL28 INGB 0007 350 370
NL95 RABO 0160100046
Chamber of commerce 27 16 95 41
Page 1/14
Advertisement
Table of Contents
Summary of Contents for PMT Tamson Cool Cube
- Page 1 USER-MANUAL Tamson Cool Cube Immersion Cooler Tamson Instruments bv ISO 9001 : 2015 NL/PRO 238239125 VAT: NL 80 66 34 984 B01 Bank account no.: NL28 INGB 0007 350 370 van 't Hoffstraat 12 NL95 RABO 0160100046 2665 JL Bleiswijk, The Netherlands Chamber of commerce 27 16 95 41 www.tamson.com...
-
Page 2: Table Of Contents
SAFETY AND WARNINGS ..........................3 WARRANTY ..............................3 DISCLAIMER ..............................3 PRECAUTIONS AND HAZARDS ........................4 INSTALLATION ............................... 4 ..............................4 MPORTANT USE .................................. 5 WHAT IS WHAT .............................. 6 ................................ 7 TART ............................8 IR CIRCULATION SPARE PARTS LIST AND PRODUCT CODE ....................9 WIRING ................................ -
Page 3: Safety And Warnings
SAFETY AND WARNINGS Make sure before installing or operating the equipment to read and understand all instructions and safety precautions listed in this manual. If there are any questions concerning the operation of the equipment or about the information given in this manual, please contact your local dealer or our sales department first. Performance of installation, operation, or maintenance other than those described in this manual may result in a hazardous situation and may void the manufacturer's warranty. -
Page 4: Precautions And Hazards
PRECAUTIONS AND HAZARDS Before attempting to operate the TCC - IC read all parts of this manual carefully to insure smooth operation and avoid damage to the equipment or its accessories. If a malfunction occurs, consult section "Trouble shooting”, READ page 11. -
Page 5: Use
KEEP AIR FLOW FREE Put the unit in its proper place. Leave enough room around the cryostat for sufficient air circulation. Place the unit in a clean working environment and keep away from dust. When air can not circulate well the cryostat will overheat itself resulting in irreversible and severe mechanical damage. -
Page 6: What Is What
What is what Indicator on / off On / off switch Pressure valve open System error High pressure Pressostat stage 2 Pressostat stage 1 Compressor stage 2 running Compressor stage 1 running Not used Tamson Instruments bv ISO 9001 : 2015 NL/PRO 238239125 VAT: NL 80 66 34 984 B01 Bank account no.:... -
Page 7: Start
7.1 Start Place the probe [1] in the viscometer bath TLV25 Switch on the apparatus [2] After approximately 30 seconds the compressor starts indicated by the green LED [3] After approximately 300 seconds the compressor of the second stage starts indicated by the green LED [3] After a few seconds the probe starts to cool. -
Page 8: Air Circulation
7.2 Air circulation The system transfers heat from the probe to the ambient. It KEEP AIR FLOW FREE therefore uses airflow. In order to work properly free airflow should be available. The system must be kept free 10 cm from all sides. -
Page 9: Spare Parts List And Product Code
Spare parts list and product code Product code Ordering Description code Tamson Cool Cube – Immersion Cooler 230V / 50Hz 00T0300 Tamson Cool Cube – Immersion Cooler 230V / 60Hz 00T0301 Tamson Cool Cube – Immersion Cooler 115V / 60Hz... -
Page 10: Wiring
Wiring C1 = Compressor stage 1 Valve C2 = Compressor stage 2 Switched Mode Power Supply 24T0029 24Vx1,1A Fuse 2A - T Mains in P1 = Compressor stage 1 P2 = Compressor stage 2 P1 P2 P3 P3 = Valve Tamson Instruments bv ISO 9001 : 2015 NL/PRO 238239125... -
Page 11: Dimensions
10 Dimensions Dimensions Probe Remark Diameter [mm] Length probe [mm] Length hose + probe 2200 [mm] Dimensions Casing Height + display [mm] Height casing (without display) [mm] Width [mm] Depth (casing) [mm] Do not operate backside directly to the wall Depth with distance spacers [mm] Enabling airflow at backside... - Page 12 : Compressor (C1 or C2) do not run : Check apparatus for dust. ☺: Remove all dust using a vacuum cleaner. Do not use pressurised air. : Fan makes noise : Check fans inside for blocking ☺: Remove dust or litter sucked in. : Ice forming on probe :...
-
Page 13: Ce Declaration Of Conformity
12 CE DECLARATION OF CONFORMITY Following equipment is in complience with EMC Directive 2014/30/EU: Product: Thermostatic bath and circulator Model: TCC - IC TCC - B Serial code: Effective from 17Txxx Manufacturer: Tamson Instruments bv van 't Hoffstraat 12 2665 JL Bleiswijk The Netherlands The products are in conformity with the following specifications: Item... - Page 14 not applicable were: Conducted discontinuous emissions (Clicks) Radiated emission (OATS) Magnetic field immunity The equipment conforms with all the specifications and norms in this regard. The equipment conforms without any further notice. Entity responsible for marking this declaration : Manufacturer, Tamson Instruments bv, van 't Hoffstraat 12, Bleiswijk The Netherlands, Name R.C.
