Recycling LED Lamp
The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather additional teaching and
learning material for educational purposes. This craft pack may only be constructed by children and ado-
lescents under the guidance and supervision of experienced adults. Not suitable for children under 36 months.
Parts List
Plywood
Battery Holder
LED
Push Switch
Clothes Peg
Chandelier Clamp Insert with Screws
Wooden Strip
Bolt
Bolt
1
'Pety - Four-Seasons'
Quantity
1
1
1
1
2
1
1
2
2
117.673
Tools Required:
Sandpaper
Scissors
PET Plastic
Bottle & Lid
Please Note!
Choking hazard!
Size (mm)
200x200x5
ø 10
100x20x10
ø3x25
Connecting LED's Switch Battery Holder
ø3x13
ø2
Drill
Wood Glue & All
Purpose Glue
Philips
Slot
Screwdriver
Screwdriver
Double &
Fretsaw
Single Sided
Adhesive Tape
Description
Individual Parts
Battery Holder
Lighting
On-Off Switch
Hands
LED Fixture
Mounting Arms
Mounting Arms
Ruler
Pencil & Colou-
red Pencils
Hot Glue Gun
Part No.
1
2
3
4
5
6
7
8
9
Advertisement
Summary of Contents for Opitec Pety Four Seasons
- Page 1 Adhesive Tape Please Note! The OPITEC handicraft packs are not toys in a typical off-the-shelf sense, but rather additional teaching and learning material for educational purposes. This craft pack may only be constructed by children and ado- lescents under the guidance and supervision of experienced adults. Not suitable for children under 36 months.
- Page 2 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' ø2 Transfer the template for the individual parts (page 5) to the plywood Cut the wood strip (7) to size, drill through ø2mm and clean saw cuts. plate (1). Drill holes ø 2mm, saw all parts with the jigsaw and clean saw cuts.
- Page 3 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Glue the bottle cap as shown on the underside of the part (1a). Let the Secure the pressure switch (4) as shown with a screw (8). Screw the glue dry. second screw (8) into the free bore. Screw both screws through the bottle cap.
- Page 4 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Place the bottle with the upper part in the stand. Glue the parts (1e-1i) on the marked line on part (1j) as shown. Please Note: Marking depends on the diameter of the bottle! Affix the figure with double-sided adhesive tape as shown or clamp it Cut out any desired template (page 7-10) with the scissors.
- Page 5 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Template Single Parts S 1:1...
- Page 7 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Template Pumpkin S 1:1...
- Page 8 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Template Snowman S 1:1...
- Page 9 Instructions 117673 Recycling LED Lamp 'Pety - Four-Seasons' Template Scarecrow S 1:1...
