- Page 1 2200 LBS Utility Wagon With High Speed Hub OWNER’S MANUAL WARNING: Carefully read and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item# ATV-2200HSH 03052020...
- Page 2 Thank you very much for choosing this product! For future reference, please complete the owner’s record below: Model: _______ATV-2200HSH______ Purchase Date: _______________ Save the receipt, the warranty, and these instructions. It is important that you read the entire manual to become familiar with this product before you begin using it. This product is designed for certain applications only.
- Page 3 WORK AREA • Keep work area clean, free of clutter, and well lit. Cluttered and dark work areas can cause accidents. • Keep children and bystanders away while operating a utility wagon. Distractions can cause you to lose control, so visitors should remain at a safe distance from the work area. •...
- Page 4 ASSEMBLY Do not tighten bolts and nuts until assembly is complete. Step 1: Remove Tongue Bolt (#12), Lock Nut (#4), Tongue Washers (#10), and Spacer (#11) from the center of the Front Axle (#5). Align hole in center of the Front Axle (#5) with hole in center of the Tongue (#2).
- Page 5 Step 4: Position both Front Axle Assembly and Back Axle Assembly as shown below and insert Frame Adapter (#4) into ends of both Axles. Slide in until you align holes of Frame Adapter (#4) with the holes of the Axles. Secure in place using 12x70mm Bolt (#15), Washer (#10), and Lock Nut (#14).
- Page 6 OPERATION WARNING: DO NOT load the wagon with more than 2200 lbs, with a balanced load. DO NOT allow children to use the wagon. This wagon is NOT a toy. DO NOT over inflate the tires. Maximum speed is 15 mph. MAINTENANCE •...
- Page 7 DIAGRAM & PARTS LIST Page of 8...
- Page 8 Part# Description Qty. Part# Description Qty. Wheel Tongue Bolt M16xM12x125mm Tongue Bolt 12x80mm Back Axle Lock Nut M12x9mm Frame Adaptor Bolt 12x70mm Front Axle Left Axle Assembly Large Washer M20mm Right Axle Assembly Hub Bearing (4 are Cotter Pin M2.5x35mm pre-assembled) R-Pin M3mm Hub Washer...
