Summary of Contents for Numatic NVB170-12
- Page 1 NVB170-12 Lithium-Ion Battery Powered Kit AS29E Original Instructions - Original Instructions - www.numatic.com CAUTION. Read instructions before using the machine. CAUTION. Read instructions before using the machine.
- Page 2 Kit AS29E Assembly...
-
Page 3: Using Your Machine
Operating your machine for the first time Your Battery will arrive in transportation mode. It is not possible to operate your machine, until the battery is first placed on the charger. It is recommended that a battery is fully charged before first use. Using your machine 2 Speed Switch CLICK... - Page 4 Using your machine Wand docking Tool Tidy...
- Page 5 Cleaning...
- Page 6 Fitting the Face Removing the Face...
-
Page 7: About Your Machine
Vacuum cleaners that are no longer suitable for use must be separately collected and sent for recovery in an environmentally - friendly manner. Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the Numatic Technical helpline +44 (0)1460 269268 Daily Keep the machine clean, including hoses and tubes. - Page 8 If the vacuum cleaner stops working, remove the battery from the appliance before investigating where the fault lies. Failure to rectify the problem or in the event of a breakdown contact your Numatic dealer or the Numatic Technical helpline +44 (0)1460 269268.
- Page 9 Important Warnings – Batteries Read all the warnings before using the battery. This cleaner uses Numatic Lithium-Ion batteries. Used batteries should be disposed of safely and placed in a sealed plastic bag and then handled according to all locally approved precautions and environmental regulations.
- Page 10 • If on checking the battery is found to be operational then a single recharge cycle under observation can be attempted with the appropriate Numatic charger. • If the battery recharges correctly on this single recharge cycle then it can be deemed a good battery.
-
Page 11: Charging The Battery
Charging the battery CLICK Brand Name: Numatic Type: Charger 903227 Charger Status Indications The charger is equiped with a double colour LED’s to indicate the status of the charger and battery. CHARGE INDICATOR STATUS Green Continuously On Charge Complete Green Flashing Without Pause... - Page 12 The battery included in this product must only be charged by the Numatic Charger supplied with the product under NO circumstances should an alternative non Numatic charger be used as there is risk severe damage and fire could result. Only use genuine Numatic parts. Instructions for Use – Charging Batteries The charger is intended for use only on flat surfaces, place horizontally on floor or work suface.
-
Page 13: First Aid Measures
First Aid Measures If exposed to any of the Chemicals mentioned in the Hazards section please follow the procedures below: Eyes. Flush eyes with plenty of water for at least 15 minutes, occasionally lifting the upper and lower eyelid. Seek medical attention. Skin. - Page 15 Lithium - Ion Battery Warranty. Numatic International will guarantee your Numatic Lithium - Ion battery for 500 recharging cycles, providing the cycles have been car- ried out to the manufacturer’s specifications and requirements. Failure to use the correct Numatic charger will void your warranty.
-
Page 16: Schematic Diagram
NVB170-12 Schematic Diagram Distributed by:- Numatic International Limited, UNITED KINGDOM: www.numatic.co.uk GERMANY: www.numatic.de Chard, Somerset, TA20 2GB SWITZERLAND: www.numatic.ch FRANCE: www.numatic.fr Telephone: 01460 68600 NETHERLANDS: www.numatic.nl PORTUGAL: www.numatic.pt Fax: 01460 68458 SOUTH AFRICA: www.numatic.co.za Subject to change without prior notice.
