TP804P Knightswood Single Wooden Swing Frame
TP802P Knightswood Double Wooden Swing Frame
TP803P Knightswood Triple Wooden Swing Frame
TP825P Knightswood Double Wooden Swing Frame
& Extension
TP881P Eagle Wooden Swing Set
Instructions for assembly, maintenance and safe use.
Please retain for future reference.
TP803
WARNING!
THIS PRODUCT CONTAINS SMALL PARTS AND IS NOT SUITABLE FOR CHILDREN UNDER 36 MONTHS.
CONTAINS SMALL PARTS. CHOKING HAZARD.
ONLY FOR DOMESTIC USE. FOR OUTDOOR USE.
TOY MUST BE ASSEMBLED BY AN ADULT BEFORE USE.
ADULT SUPERVISION IS REQUIRED
CHILDREN MUST NOT USE THE EQUIPMENT UNTIL PROPERLY INSTALLED.
REMOVE ALL PACKAGING BEFORE GIVING TO YOUR CHILDREN.
THIS PRODUCT IS INTENDED FOR USE BY CHILDREN FROM AGES 3 TO 12 YEARS.
ANCHORS THAT ARE SUPPLIED WITH THIS PRODUCT MUST BE FITTED BEFORE USE.
SINGLE SWING FRAME - MAXIMUM COMBINED USER WEIGHT 100KGS
DOUBLE & TRIPLE SWING FRAMES - MAXIMUM COMBINED USER WEIGHT 200KGS
TP802 803 804 825 881 Roundwood Swings New In8047-B 23.03.18 Option 2.indd 1
TP802
2 Hrs
Build Time
x2
Robovision Ltd t/a TP Toys
Unit 11, Enterprise Way, Flitwick, Bedfordshire, MK45 5BX England
www.tptoys.com
TP825
TP804 / TP881
23/03/2018 16:17
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for active fun Knightswood TP804P
Summary of Contents for active fun Knightswood TP804P
- Page 1 TP804P Knightswood Single Wooden Swing Frame TP802P Knightswood Double Wooden Swing Frame TP803P Knightswood Triple Wooden Swing Frame TP825P Knightswood Double Wooden Swing Frame & Extension TP881P Eagle Wooden Swing Set Instructions for assembly, maintenance and safe use. Please retain for future reference. TP802 TP825 TP803...
- Page 2 Important advice for assembly, maintenance and safe use Toys must be assembled by an adult before use exactly in accordance with the instructions. Check all parts are present before you start to assemble the product. Place small parts on a tray or similar, to ensure they are not lost. If any parts are missing do not use the product until the replacement parts are fitted.
- Page 3 Know Your TP Round Wood. Timber is a very popular choice for active outdoor toys. For reasons of affordability and the environment, all wood playset manufacturers use softwood rather than hardwood. Each piece of timber is unique, bearing its own knots, cracks and variations in colour.
- Page 4 Contents - Please check TP804P Knightswood Single Wooden Swing Frame TP881P Eagle Wooden Swing Set MW0200 2700mm MW0202 900mm 804 - 1 / 881 - 1 MW1500 MW0200 2700mm 800S Please note: There may be some fixings left over after the assembly build. Fixings - SP0075 FB6051 PR5069...
- Page 5 TP804P Knightswood Single Wooden Swing Frame TP881P Eagle Wooden Swing Set ASSEMBLY TIP MW1500 PR7757 Make sure you thread TP804 x2 the metal TP881 x2 collars (PR7757) onto your top bar before the securing the brackets to each end of FB6038 the wood MW0204...
- Page 6 Contents - Please check TP802 Knightswood Double Wooden Swing Frame MW0200 2700mm MW0202 900mm 802 - 1 MW0203 2250mm MW0200 2700mm 800D Please note: There may be some fixings left over after the assembly build. Fixings - SP0075 FB6051 PR5069 PM1968 M8 x25mm 40mm FA8380...
- Page 7 TP802 Knightswood Double Wooden Swing Frame MW0203 2250mm PR7757 TP802 x4 FB6038 ASSEMBLY TIP Make sure you thread the metal collars (PR7757) onto your top bar before the securing the brackets to each end of the wood MW0203 M8 x25mm FA8440 70mm FA8439 15mm...
- Page 8 Contents - Please check TP803 Knightswood Triple Wooden Swing Frame MW0200 2700mm MW0202 900mm 803 - 1 MW0201 3000mm MW0200 2700mm 800T Please note: There may be some fixings left over after the assembly build. Fixings - SP0075 FB6051 PR5069 PM1968 M8 x25mm 40mm FA8380...
- Page 9 TP803 Knightswood Triple Wooden Swing Frame MW0201 3000mm PR7757 TP803 x6 FB6038 ASSEMBLY TIP Make sure you thread the metal collars (PR7757) onto your top bar before the securing the brackets to each end of the wood MW0201 M8 x25mm FA8440 70mm FA8439 15mm...
- Page 10 Contents - TP825 Knightswood Double Wooden Swing Frame & Extension Please check MW0200 2700mm MW0202 900mm 803 - 1 MW0201 3000mm MW0200 2700mm 825-3 Please note: There may be some fixings left over after the assembly build. Fixings - SP0075 FB6051 PR5069 PM1968...
- Page 11 TP825 Knightswood Double Wooden Swing Frame & Extension PR7757 MW0201 3000mm TP825 x5 FB6038 ASSEMBLY TIP Make sure you thread the metal collars (PR7757) onto your top bar before the securing the brackets to each end of the wood MW0201 M8 x25mm FA8440 70mm FA8439...
- Page 12 SWING FRAME CONFIGURATIONS Fixing postions using Collars (PR7757) or Duo Ride Brackets 445mm 445mm Swing Seat Position Swing Seat Position IMPORTANT ASSEMBLY TIP Using Using 2 collar fixings 2 collar fixings When attaching a swing 2 Duo Ride Brackets 2 Duo Ride Brackets accessory that requires Duo Ride Brackets 2 Duo Ride Brackets...
- Page 13 TP802 Knightswood Double Wooden Swing Frame 40mm With 2 single swing seats FA8380 2250mm TP804 x4 385mm 445mm 450mm 445mm 385mm Swing Seat Position Swing Seat Position With 1 glide ride and 1 single swing seat 2250mm 550mm 612mm 445mm 573mm Swing Seat Position Bracket for rigid...
- Page 14 TP803 Knightswood Triple Wooden Swing Frame 40mm FA8380 TP803 x6 With three single swing seats 3000mm 277mm 445mm 450mm 450mm 445mm 277mm Swing position Swing position Swing position With 1 glide ride, 1 single swing and 1 single roped accessory 3000mm 550mm 693mm...
- Page 15 TP825 Knightswood Double Wooden Swing Frame & Extension 40mm FA8380 TP825 x5 With 2 single swing seats and 1 single roped accessory 3000mm 750mm 385mm 445mm 450mm 445mm 385mm 100mm Swing Seat Position Swing Seat Position Single Roped Seat With 1 Nest swing seat and 1 single roped accessory 3000mm 750mm 385mm...
- Page 16 TP804 / TP802 / TP803 / TP825 / TP881 MW0200 2700mm M8 x25mm FA8440 70mm FA8439 ASSEMBLY TIP Generic view of Top Bar only. Actual Top Bar will vary depending on product purchased. MW0200 2700mm M8 x25mm FA8440 70mm FA8439 ASSEMBLY TIP Step ladders...
- Page 17 MW0202 900mm M8 x25mm FA8440 70mm FA8439 ASSEMBLY TIP Generic view of Top Bar only. Actual Top Bar will vary depending on product purchased. ASSEMBLY TIP Make sure that the fixing points are centred on the legs. Attaching Swing Accessories IMPORTANT ASSEMBLY TIP TP940...
- Page 18 Swing seat height adjustment 350mm PM1968 PM1007 4 x 16mm FA4527 Equal spacing TP802 803 804 825 & 881 TP802 803 804 825 881 Roundwood Swings New In8047-B 23.03.18 Option 2.indd 18 23/03/2018 16:17...
- Page 19 M8 x25mm FA8440 70mm FA8439 PR5069 45° TP814 300mm 300mm Dig holes: 300mm x 300mm 300mm x Mark leg/hole position. 300mm deep. Ensure the stakes are positioned into the setting Post-Mix concrete. Warning: Never set the legs of the Supplied. playset in concrete.
- Page 20 Thank you Thank you for purchasing this product. Please register your new product on line at tptoys.com www.tptoys.com/customer/productregistration Find out about the guarantee for this product, visit www.tptoys.com/customer/pages/guaranteeinformation For customer services and help with your product, visit www.tptoys.com/customer/help Your TP Guarantee Number/Product Batch No is TP802 803 804 825 881 Roundwood Swings New In8047-B 23.03.18 Option 2.indd 20 23/03/2018 16:17...
