Summary of Contents for SAW TRAX Scoop Dolly
- Page 1 4-Position Scoop Dolly INSTRUCTION MANUAL Watch an instructional video of picking up and moving a load at: https://vimeo.com/332051838...
- Page 2 PARTS OF THE SCOOP DOLLY Support Arms Handle E-Strap Slots Saddle Post Storage / Sight Holes Saddle Posts Scoop Dolly Body Lip of Scoop Support Holes Saddle Post Hat Brackets Page 2...
- Page 3 ● (with the optional leverage step, pg. 8) bureaus, furniture and appliances over 3 feet tall The Scoop Dolly operates like a pivoting hand truck on a dolly. Unlike standard hand trucks, the object can be moved in any direction, making long objects easier to move.
- Page 4 SUGGESTIONS FOR SAFEST AND EASIEST USE Plan and prepare for the job before attempting to load the dolly • Be sure the Scoop Dolly can handle your load's weight and size (base model: 800 lbs. max); do not overload dolly •...
- Page 5 OPERATING THE SCOOP DOLLY 1. ADJUST THE SADDLE POSTS (A) FOR THE LOAD. The Scoop Dolly has saddle posts that can be adjusted to vary the angle of the load, to safely keep the center of gravity (CG) over the dolly. When unsure where to set the saddle posts initially, a good place to start is the third support hole from the scoop.
-
Page 6: Helpful Features
32" TILT THE LOAD BACK ONTO THE SCOOP DOLLY. Using the Scoop Dolly handle (E), tilt the scoop back and tilt the load back onto the support arms. If the load will not stay back, set the load down and move the saddle posts back one or two positions. -
Page 7: Optional Upgrades
HELPFUL FEATURES (Continued) E-STRAP FITTING (G) Additional E-Strap slots are manufactured into the Scoop Dolly support arms, allowing strapping in of larger loads for secure transport. OPTIONAL UPGRADES Call us or visit https://www.sawtrax.com/product/scoopdolly/ for more information DOCK TRANSITION WHEELS For transitioning on uneven surfaces. Adds 4 wheels ... -
Page 8: Directional Wheel
OPTIONAL UPGRADES (Continued) Call us or visit https://www.sawtrax.com/product/scoopdolly/ for more information LEVERAGE STEP Allows for easier tilting of large or heavy loads back onto the dolly. The built- in step allows you to use your body weight to instantly create leverage, resulting in minimal pulling or physical strain. - Page 9 For directional assistance capabilities when carrying shorter loads that have a lower center of gravity, additional wheels are added to the front edge of the scoop dolly body, behind the scoop lip plate. TRANSPORT / STORAGE OPTIONS For folding and rolling the scoop, allowing for less transport and storage space ...
- Page 10 Kennesaw, GA www.SAWTRAX.com For Technical Support, Call 770-974-0021 888-SAWTRAX (888-729-8729) Revised 12/09/2019. For information on the compatibility of the Scoop Dolly with any products introduced after this date, contact Saw Trax. Scoop Dolly Instruction Manual © SAW TRAX MFG. 2019...
