Summary of Contents for DIY BBQ DIY-BBQ-6FP
- Page 1 Easy-to-Follow Instruction Manual 6-Foot Firepit Module assembly...
-
Page 2: Copyright Notice
Copyright Notice This instruction manual is protected under Copyright Law of the United States of America. This copy of the instruction manual is for the sole use of the original purchaser. A license to use the information contained herein is granted to the original purchaser by the author. -
Page 3: Required Tools For Assembly
Required Tools for Assembly Cordless Drill Tape Measure Vise Clamps Carpenter Square Pick Hammer Spring Clamps Professional Tips Proper Safety equipment is extremely important. Always wear safety glasses and gloves when assembling your modules. Using proper tools will make the project much easier to do and will help you obtain a properly built project. This list is of the basic tools you’ll need to build your modules. -
Page 4: What's In The Box
What’s in the box Cross Channel CC Walls Front & Back Perimeter Walls Tracks Outer Studs Inner Studs Firepit Cutout Screws Catch Tracks Countertop Studs Check List 4 Perimeter Wall Tracks 10 Inner Perimeter Wall Studs 4 Catch Tracks 4 Cross Channel (CC) Tracks 4 Outer Cross Channel (CC) Studs 2 Countertop Studs 8 Outer Perimeter Wall Studs... - Page 5 Perimeter Wall Assembly Step Spread out the pieces to form a loose framework of one of the Perimeter walls prior to attaching anything. Note: Make sure that the outside edge studs have web holes and the inside edge studs have the large holes (as seen below).
- Page 6 Professional Tip - Flush Corners Professional Tip - Uneven Holes The pre-drilled holes in two pieces may not always align perfectly. If this is the case, simply angle the screw into the opening of both holes and then twist up while drilling. When placing two corners together, the pieces may not always appear completely flush.
- Page 7 Cross Channel (CC) Wall Assembly Step Step Spread out the pieces to form a Slide each stud into the bottom loose framework of the wall prior to track. Make sure that each of the attaching anything. precut holes line up. Note: Make sure the open ends of the outer studs face inward toward the center stud.
- Page 8 Step Drill screws in all six (6) pre-drilled holes on the top and bottom tracks. When complete, flip the wall over and drill six (6) additional screws into the opposite side. You should now have a completed Cross Channel (CC) wall. Step Repeat steps 1-5 on pages 7-8.
- Page 9 Complete Module Assembly Step Make sure you have all of your assembled pieces. Front and Back Perimeter Walls Cross Channel (CC) Walls Step Slide the left Cross Channel (CC) wall so that it aligns perpendicular to the edge of the left side of the back Perimeter wall.
- Page 10 Step Attach the CC wall to the back Perimeter wall by drilling at least two (2) screws through the pre-drilled web holes found on the inner side of the CC wall. Note: The web holes located on the outer studs of the CC walls align with the pre-drilled holes in the perimeter wall. Use the center web hole in each row to drill the perimeter wall to the CC wall.
- Page 11 Step Clamp the Catch Tracks to the back and front Perimeter wall tracks of your module with Vice Clamps so that the center of each Catch Track aligns with the center of the 1st inner stud on each side of the wall. Make sure that the top of the Catch Tracks is flush with the top of the Perimeter wall tracks.
- Page 12 Step Measure the length of the Countertop Studs to make sure it matches the length of the firepit that will be placed within this area. If the size is incorrect, slide one or both of the Countertop Studs left or right along the Catch Tracks until the size between the Countertop Studs matches the width of the firepit.
- Page 13 Step Drill Screws into the center of each of the Catch Tracks (for a total of four (4) screws) to secure the Catch Tracks to the Perimeter wall tracks of your module. Professional Tip - Placement of Screws If your Catch Tracks are near a Perimeter wall stud, avoid drilling a screw into the screws already placed in your...
- Page 14 @2020 DIYBBQ. All Rights Reserved.
