Xirlink IBM PC & Net Camera Manual page 8

F. Settings
Depending on your camera model, the Settings dialog box consists of 3-4
tabs to adjust video and image options – Capture, Video, Mail Agent, and
VGA Snapshot (IBM Net Camera and Net Camera Pro only). To access
options, click the Settings button:
1 . C a p t u r e
a. Maximum Video Size: Dependent on available hard
drive space. Most e-mail applications have disk space
limitations when receiving e-mail. (2MB is the default value)
b. Snapshot Delay: When snapshot delay is enabled, select
the number of seconds to delay snapshot.
c. Enable Audio: This allows you to record audio with video.
Adjust the volume by moving the slider across the slide bar.
d. Snapshot Image Format: Select BMP for uncompressed
snapshots or select JPEG for compressed snapshots.
2. Video*
*Depending on the
IBM PC or Net
Camera model, not
all Video options
are available.
7
