Summary of Contents for legate Smart Doorbell Standard Wired
- Page 1 Legate Smart Doorbell Standard Wired ORIGINALITY DESIGN SMART - AND BEAUTIFUL QUICK GUIDE...
-
Page 2: What's In The Box
What’s in the box? Please consult this checklist for all parts. Chime kit Bell 5C Bracket A x 2 B x 2 C x 1 Screw(3 kinds) Angle Wall Mount Screwdriver... - Page 3 Camera External power port Microphone Status Light Button Reset Speaker SD card slot Mini USB Description Power Port AC 12V~24V Doorbell button Press the button to activate the doorbell Red light solid on: the camera network is abnormal Status light Red light blinking: awaiting WiFi connection, or currently connecting (faster blinking) Blue light solid on: camera running correctly...
- Page 4 Install Mode 1 Doorbell General Installation 1.Mark screws position 2.Nail expansion screw 3.Fix bracket AC 12V~24V 4.Install the doorbell into the bracket Mode 2 Angle Wall Mount + bracket + doorbell installation 1.Mark screws position 2.Nail expansion screw 3.Fit the mounting bracket to the Angle Wall Mount AC 12V~24V 4.Fix bracket...
- Page 5 Connect 功能介绍 Download Legate Smart Home is available for both iOS and Android OS. Rearch the name “Legate Smart Home” in App Store or Google Play, or scan upper QR-Code to download the App. ·Support Android Dowoload App (IOS & Android) Set up router This device only supports 2.4GHz frequency band router, does not support 5GHz...
- Page 6 Registration Process Step 1 Open the Legate Smart Home App, click “Register”, read the “Privacy Policy” and click “Agree”. Step 2 input a legal and valid Mobile number or Email address and click “Continue”. Input Verification Code, then log in the app.
- Page 7 QR Code Configuration Open the Legate Smart Home App, click "Create family", and you can customize the Family name and related settings . Continue to click "Security & Sensor" >> "Smart Camera",and then choose "Add Device" or "+",ready to add camera.
- Page 8 In "Add Device" this interface,continue to click "next step",and then you should input your WiFi's passwords. Note: 1) Camera only supports 2.4GHz WiFi network. 2) The number of bits in the ssid and passwords of the router should not exceed 24 digits.
- Page 9 In this interface,you should scan the QR code in your phone with the camera,when the camera comes out "dong dong dong". And you can complete the configuration about 30s.
- Page 10 When connecting,you should make sure your router,mobile,and camera are as close as possible.When camera added successffully,click " " you could also DIY the camera's name.
- Page 11 Settings In "Smart Camera" interface,click " ",you can set the camera common functions.
- Page 12 Functions Full-duplex audio When the visitor push the doorbell button, you will get a call. You can see and hear the vistor in your App from the doorbell if you answer. Motion detection Motion sensors will notify you when movement is detected. Shared device The doorbell device can be shared with friends, and friends can also preview online.
- Page 13 Q: In the network process, the process bar is always not 100%, add failure? A: This camera only supports 2.4GHz WiFi router, please make sure you are using a 2.4GHz WiFi router.And confirm the WiFi password again. Q: Repeated additions are failures? A: After adding a failure, it is recommended to restart the device or power off, and then try to add again.
