S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E
SP 300/ 575 SQ U EEG EE/ D UA L
SPR AY M AC H IN E
S e r v i c e M a n u a l A u g u s t 2 0 1 9

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SealMaster SP 300 and is the answer not in the manual?

Questions and answers

Summary of Contents for ThorWorks Industries SealMaster SP 300

  • Page 1 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E SP 300/ 575 SQ U EEG EE/ D UA L SPR AY M AC H IN E S e r v i c e M a n u a l A u g u s t 2 0 1 9...

  • Page 2: Contact Information

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Contact Information HEADQUARTERS: 2520 South Campbell Street Sandusky, Ohio 44870 Phone: 1-800-326-1994 Fax: 419-626-5477...

  • Page 3: Parts Ordering

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Parts Ordering INFORMATION Please provide as much of the following if available: CONTACT INFORMATION: •...

  • Page 4: Parts Warranty

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Parts Warranty Wear Items • Wear items are not covered ThorWorks warrants parts under ThorWorks limited purchased through ThorWorks...

  • Page 5: Return Authorization

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Return Authorization • If a part fails to function within the first year of purchase, a RETURN AUTHORIZATION number must be obtained.

  • Page 6: Return Parts

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Return Parts • The same procedure should be followed if a customer has purchased a part but it is no longer needed.

  • Page 7: Technical Assistance

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Technical Assistance Contact Information: 2520 South Campbell Street Sandusky, Ohio 44870 Phone: 1-800-326-1994 Fax: 419-626-5477...

  • Page 8: Warranty Information

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Warranty Information • Limited Warranty • Product Registration •...

  • Page 9: Where To Find Product Information

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Where to find product information: • Owner’s Manual •...
  • Page 10 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Questions?
  • Page 11 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E • A manual is furnished with each new SP 300/575 Squeegee/Dual Spray Machine •...
  • Page 12 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Your SP 300/575 Squeegee/Dual Spray Machine is designed to give excellent service and save maintenance expenses.
  • Page 13 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Tank Depth Chart...

  • Page 14: Operation

    S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation...
  • Page 15 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation...
  • Page 16 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation...
  • Page 17 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation...
  • Page 18 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation SandPumper II Pump Operation...
  • Page 19 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation Spray Wand Application...
  • Page 20 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation Spray Wand Application...
  • Page 21 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Operation SandPumper II Pump Operation...
  • Page 22 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Tattletale Switch For models up through year 2017 Located in Appendix...
  • Page 23 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Diesel Engine Starts but Doesn’t Stay running when the Red Push Button is Released •...
  • Page 24 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines No Power, Cannot Load on Trailer •...
  • Page 25 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines The Machine Jumps or Suddenly Takes off When the Shift Lever is Engaged •...
  • Page 26 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Squeegee Assembly Doesn’t Lift or Lifts Very Slowly •...
  • Page 27 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Agitator Doesn’t Turn •...
  • Page 28 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Suddenly Stopped •...
  • Page 29 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Suddenly Stopped The rod coming out of one of the chambers has two round collars on it.
  • Page 30 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Suddenly Stopped Loosen the Allen Head screw that holds the swingarm to the limit switch and raise it till it clears the collars.
  • Page 31 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Suddenly Stopped If you don’t hear a click in each direction, this means one side of the return spring has come off the mechanism.
  • Page 32 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Suddenly Stopped Should you have power and the above steps are not the issue, then make certain there is poser at the black solenoid coil.
  • Page 33 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material Pump Doesn’t Build Pressure Another cause is the pressure compensator located on the main hydraulic pump.
  • Page 34 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Troubleshooting Guide – Squeegee/Spray Machines Material is Coming Out of a Hole in the Diaphragm Chamber This means the diaphragm is torn and needs to be replaced.
  • Page 35 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E Questions?
  • Page 36 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E...
  • Page 37 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E...
  • Page 38 S P 3 0 0 / 5 7 5 S Q U E E G E E / D U A L S P R AY M A C H I N E...
