Alfa Romeo Giulietta 2.0 JTDM Manual

191 - Giulietta 2.0 JTDM INTRODUCTION - RADIO NAVIGATOR WITH MAPS
RADIO NAVIGATOR WITH MAPS
The radio navigator module, located in the middle of the dashboard, includes:
- radio module with dual aerial and dual tuner;
- Audio CD and CD MP3 player;
- SD card reader;
- GPS module;
- independent navigation module with maps;
- "flap display" TFT 6.9", motor-driven, on the top middle part of the dashboard;
- interface with the controls on the steering wheel.
The RADIONAV system described below comes in two versions:
- matched with the "basic" radio: there is no telephone management: the navigation functions are managed by the RADIONAV and shown by
maps on the display.
- combined with the "Blue&Me": in this case the RADIONAV manages navigation and Blue&Me manages the Media Player and Bluetooth
mobile functions.
Example of main MENU screen:
Audio module
General specifications:
- 5 predefined band graphic equalizer;
- easily operated menu for adjusting radio settings or any outside interfaces (Media Player);
- remote control from the steering wheel;
- speed-dependent volume control.
Radio tuner specifications:
- RDS
- RDS - TMC (Traffic Message Channel)
- EON (Enhanced Other Network)
- TA (Traffic Announcements)
Tuning of the following bands: USW (87.5-108 MHz) (FM); MW (153-279 kHz) (AM); LW (531-1602 kHz) (AM);
Possibility of storing:
- 18 FM stations (6 of which can be memorised through autostore);
- 12 FM stations (6 of which can be memorised through autostore);
2 scan modes (brief playback of one station and automatic scan to the next):
- scan on the frequency band used and stations memorised.
- possibility of selecting programmes via PTY (on FM bands only).
(RadioNAV)
