Bernecker + Rainer Automation PC 820 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Automation PC 820
User's Manual
Version: 1.20
(August 2010)
Model number: MAAPC820-ENG
We reserve the right to change the contents of this manual without warning. The information
contained herein is believed to be accurate as of the date of publication; however, Bernecker +
Rainer Industrie-Elektronik Ges.m.b.H. makes no warranty, expressed or implied, with regards
to the products or the documentation contained within this book. In addition, Bernecker + Rainer
Industrie-Elektronik Ges.m.b.H. shall not be liable in the event of incidental or consequential
damages in connection with or resulting from the furnishing, performance, or use of these
products. The software names, hardware names, and trademarks used in this document are
registered by the respective companies.
Automation PC 820 User's Manual V 1.20
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Automation PC 820 and is the answer not in the manual?

Questions and answers

Summary of Contents for Bernecker + Rainer Automation PC 820

  • Page 1 Bernecker + Rainer Industrie-Elektronik Ges.m.b.H. makes no warranty, expressed or implied, with regards to the products or the documentation contained within this book. In addition, Bernecker + Rainer Industrie-Elektronik Ges.m.b.H. shall not be liable in the event of incidental or consequential damages in connection with or resulting from the furnishing, performance, or use of these products.
  • Page 2 Automation PC 820 User's Manual V 1.20...
  • Page 3 Chapter 1: General information Chapter 2: Technical data Chapter 3: Commissioning Chapter 4: Software Chapter 5: Standards and certifications Chapter 6: Accessories Automation PC 820 User's Manual V 1.20...
  • Page 4 Automation PC 820 User's Manual V 1.20...
  • Page 5 Chapter 7: Maintenance / Servicing Appendix A Figure index Table index Model number index Index Automation PC 820 User's Manual V 1.20...
  • Page 6 Automation PC 820 User's Manual V 1.20...

  • Page 7: Table Of Contents

    2.2.1 Maximum ambient temperature with a fan kit ............41 2.2.2 Temperature sensor position .................. 42 2.2.3 Temperature monitoring - Fan control ..............43 2.3 Humidity specifications ....................44 2.4 Power management ...................... 45 Automation PC 820 User's Manual V 1.20...
  • Page 8 1.2.3 Wall mounting ......................83 1.3 Spacing for air circulation....................84 1.4 Swivel range of the front cover ..................85 1.5 Mounting the APC820 ....................86 1.6 Installation guidelines Mounting orientation ..............88 Automation PC 820 User's Manual V 1.20...
  • Page 9 1.4 Main ..........................112 1.5 Advanced ........................113 1.5.1 ACPI configuration ....................115 1.5.2 PCI Configuration ....................117 1.5.3 PCI express configuration ..................121 1.5.4 Graphics configuration ..................123 1.5.5 CPU configuration ....................127 Automation PC 820 User's Manual V 1.20...
  • Page 10 2.5 Creating a bootable CompactFlash card for B&R upgrade files ........191 2.5.1 Requirements ......................191 2.5.2 Procedure ......................191 2.5.3 Where do I get MS-DOS? ..................192 2.6 Upgrade problems ....................... 192 Automation PC 820 User's Manual V 1.20...
  • Page 11 5.3 Installation ........................199 5.4 Drivers ......................... 199 5.4.1 Touch screen driver ....................199 6. Automation PC 820 with Windows Embedded Standard 2009 ......... 200 6.1 General information ..................... 200 6.2 Features with WES2009 (Windows Embedded Standard 2009) ......... 201 6.3 Installation ........................
  • Page 12 7. USB flash drive ......................... 242 7.1 General information ..................... 242 7.2 Order data ........................242 7.3 Technical data - 5MMUSB.2048-00 ................243 7.3.1 Temperature humidity diagram - Operation and storage ........244 Automation PC 820 User's Manual V 1.20...
  • Page 13 8.6 RS232 cable 9A0014.xx ....................269 8.6.1 Order data ......................269 8.6.2 Technical data ....................... 269 8.6.3 Contents of delivery ....................269 8.6.4 Cable specifications ....................270 8.7 USB cable 5CAUSB.00xx-00 ..................271 8.7.1 Order data ......................271 Automation PC 820 User's Manual V 1.20...
  • Page 14 2. Changing the fan ......................276 Appendix A: .................. 277 1. Maintenance Controller Extended (MTCX) ............... 277 2. B&R Key Editor information ....................279 3. B&R Automation Device Interface (ADI) development kit ..........281 4. Glossary ..........................283 Automation PC 820 User's Manual V 1.20...

  • Page 15: Chapter 1: General Information

    - L2 cache of CPU board 5PC800.B945-00 corrected to 2 MB. - Section 5.5 "Plug-in cards", on page 23 in chapter 2 "Technical data" added. - Figure 14 "Block diagram - Automation PC 820", on page 47 updated. - Interface descriptions added for revision A1 and later.
  • Page 16 2010-08-20 - Chapter 5 "Standards and certifications", on page 207 updated. - Section 6 "Automation PC 820 with Windows Embedded Standard 2009", on page 200 added - B&R ID codes for system units added. - B&R USB flash drive added to the chapter 6 "Accessories" on page 245.

  • Page 17: Safety Notices

    Components can only be touched on the small sides or on the front plate. • Components should always be stored in a suitable medium (ESD packaging, conductive foam, etc.). Metallic surfaces are not suitable storage surfaces! Automation PC 820 User's Manual V 1.20...

  • Page 18: Policy And Procedures

    2.4 Transport and storage During transport and storage, devices must be protected from excessive stress (mechanical load, temperature, humidity, aggressive atmospheres, etc.). Automation PC 820 User's Manual V 1.20...

  • Page 19: Installation

    Automation Panel or Power Panel are protected on the front side. The rear side of all devices must be protected from dust and humidity and must be cleaned at suitable intervals. Automation PC 820 User's Manual V 1.20...

  • Page 20: Programs, Viruses, And Dangerous Programs

    Operating and monitoring devices Uninterruptible power supply Cables Cardboard box / paper packaging Paper / cardboard recycling Plastic packaging Plastic recycling Table 2: Environmentally-friendly separation of materials Disposal must comply with the respective legal regulations. Automation PC 820 User's Manual V 1.20...

  • Page 21: Organization Of Safety Notices

    Disregarding the safety regulations and guidelines can result in injury or damage to material. Information: Important information for preventing errors. Table 3: Organization of safety notices 4. Directives European dimension standards apply to all dimensions (e.g. dimension diagrams, etc.). Automation PC 820 User's Manual V 1.20...

  • Page 22: Model Numbers

    Power supply with heat sink APC820 power supply with heat sink for CPU boards with Dual Core processors L2400, See page 72 L7400, U7500 and Celeron® M 423. Table 6: Model numbers - Heat sinks Automation PC 820 User's Manual V 1.20...

  • Page 23: Main Memory

    Lithium batteries, 4 pcs., 3 V / 950 mAh, button cell 4A0006.00-000 Lithium battery, 1 pc. See page 231 Lithium battery, 1 pc., 3 V / 950 mAh, button cell Table 10: Model numbers - Accessories Automation PC 820 User's Manual V 1.20...
  • Page 24 SDL cable for fixed type of layout with one-sided 45° plug; length: 1.8 m 5CASDL.0018-03 1.8 m flex SDL cable See page 259 SDL cable for fixed and flexible type of layout; length: 1.8 m Table 10: Model numbers - Accessories (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 25 RS232 extension cable for remote operation of a display unit with touch screen, length 5 m. 9A0014.10 RS232 cable DB9/f:DB9/m 10 m See page 269 RS232 extension cable for remote operation of a display unit with touch screen, length 10 m. Table 10: Model numbers - Accessories (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 26: Software

    CompactFlash separately (at least 1 GB). Page 200 A CompactFlash card is required for operation. This is not included in delivery and must be ordered separately. Table 11: Model numbers - Software Automation PC 820 User's Manual V 1.20...

  • Page 27: Chapter 2: Technical Data

    ACOPOSmulti so easy to use. The Automation PC 820 was developed for the ACOPOSmulti system and is equipped on the machine for rough environmental conditions. Because the APC820 can be completely integrated into the ACOPOSmulti system, the space otherwise needed for the PC is no longer occupied in the switching cabinet.

  • Page 28: Features

    Power supply with heat sink (already part of the system unit, heat sink depends on the CPU board being used) • Fan (already part of the system unit) • Main memory • CompactFlash card for the operating system • Operating system Automation PC 820 User's Manual V 1.20...

  • Page 29: Configuration - Basic System

    1) The desired number of slots must be specified in the model number by nnnn (e.g. 0160 equals 16 slots). Additional information can be found in the ACOPOSmulti user's manual, which can be downloaded for free from the B&R homepage. 2) The number of slots must be a multiple of 4. Figure 1: Configuration - Basic system Automation PC 820 User's Manual V 1.20...

  • Page 30: Configuration Software, Accessories

    5SWWXP.0500-ENG (XP Pro SP2c English) 5SWWXP.0600-GER (XP Pro Sp3 German 5SWWXP.0500-MUL (XP Pro SP2c Multilanguage) 5SWWXP.0600-ENG (XP Pro SP3 English) 5SWWXP.0428-ENG (XPe FP2007 APC820 B945GME) 5SWWXP.0600-MUL (XP Pro SP3 Multilanguage) Figure 2: Configuration software, accessories Automation PC 820 User's Manual V 1.20...

  • Page 31: Entire Device

    Run LED CAN LED Ethernet ETH2 LED POWERLINK LED USB5 (max. 1A) Dongle CompactFlash Slot 2 CompactFlash Slot 1 Battery Power button Reset button Figure 3: APC820 interface overview - Front side ≤ A0 Automation PC 820 User's Manual V 1.20...
  • Page 32 (behind front cover) Reset button (behind front cover) Voltage supply via ACOPOSmulti mounting plate Dongle USB5 (max. 1A) Battery CompactFlash slot 2 CompactFlash slot 1 Figure 4: APC820 interface overview - Front side A1 Automation PC 820 User's Manual V 1.20...
  • Page 33 Technical data • Entire device Node switch CAN Node switch POWERLINK Power LED IF-Slot LEDs CompactFlash LED Link LED Run LED CAN LED POWERLINK LED Figure 5: APC820 LED description - Front side A1 Automation PC 820 User's Manual V 1.20...
  • Page 34 COM1 RS232 POWERLINK CAN LED CAN terminating switch CAN interface Monitor/Panel SDL (Smart Display Link) / DVI Supply voltage via ACOPOSmulti mounting plate Figure 6: APC820 interface overview - Top side ≤ A0 Automation PC 820 User's Manual V 1.20...
  • Page 35 USB4 (max. 500 mA) POWERLINK USB1 (max. 1 A) CAN terminating switch USB3 (max. 1 A) CAN LED CAN interface Monitor/Panel SDL (Smart Display Link) / DVI Figure 7: APC820 interface overview - Top side A1 Automation PC 820 User's Manual V 1.20...

  • Page 36: Technical Data

    For more information, see page 57 Amount Transfer rate Max. 500 kBit/s Node switch Terminating resistor Yes, can be activated using a switch Terminating LED Status LED Table 12: Technical data - APC820 Automation PC 820 User's Manual V 1.20...
  • Page 37 Component-dependent - see section 2.3 "Humidity specifications", on page 44 Bearings Component-dependent - see section 2.3 "Humidity specifications", on page 44 Transport Component-dependent - see section 2.3 "Humidity specifications", on page 44 Table 12: Technical data - APC820 (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 38 Only valid for components in original packaging. 6) Only valid for components in original packaging. 7) Derating the maximum ambient temperature - typically 1°C per 1000 m, from 500 m above sea level or higher. Automation PC 820 User's Manual V 1.20...

  • Page 39: Dimensions - Cold-Plate Mounting (5Pc820.Sx01-00)

    ± 0,2 mm ± 0,3 mm over 30 to 120 mm over 120 to 400 ± 0,5 mm ± 0,8 mm over 400 to 1000 All dimensions in mm. Figure 8: Dimensions - Cold-plate mounting Automation PC 820 User's Manual V 1.20...

  • Page 40: Dimensions - Wall Mounting (5Pc820.Sx01-01)

    30 to 120 mm ± 0.3 mm ± 0.5 mm over 120 to 400 ± 0.8 mm over 400 to 1000 66.5 All dimensions in mm. Figure 9: Dimensions - wall mounting Automation PC 820 User's Manual V 1.20...

  • Page 41: Temperature Specifications

    What else can be operated at max, ambient temperature, or are there limitations? 5MMDDR.0512-01 Main memory 5MMDDR.1024-01 5MMDDR.2048-01 5PC820.SX01-00 System unit 5PC820.SX01-01 5ACPCC.ETH0-00 Add. Plug-in cards PCIec card slot 5ACPCC.MPL0-00 Figure 10: Ambient conditions with a fan kit Automation PC 820 User's Manual V 1.20...

  • Page 42: Temperature Sensor Position

    1) The measured temperature is a guideline for the immediate ambient temperature, but can be influenced by neighboring components. 2) The B&R Control Center - ADI driver - can be downloaded for free from the download area on the B&R homepage (www.br- automation.com). Automation PC 820 User's Manual V 1.20...

  • Page 43: Temperature Monitoring - Fan Control

    Table 14: Temperature limits of the fan (MTCX PX32 V0.05). The fans are only switched off again when the evaluated temperature remains 6°C below the start-up temperature for a time span of 30 minutes (=lag-time). Automation PC 820 User's Manual V 1.20...

  • Page 44: Humidity Specifications

    The listed specifications correspond to the humidity at an ambient temperature of 30°C. More detailed information about the specific temperature-dependent humidity values can be found in the technical data for the individual components. Automation PC 820 User's Manual V 1.20...

  • Page 45: Power Management

    V feed further DC/DC converters, which generate the remaining voltages. After the system is turned on (e.g. using the power button), the voltages 3V3 and 5 V are placed on the bus. An additional DC/DC converter generates +12 V. Automation PC 820 User's Manual V 1.20...

  • Page 46: Power Calculation

    Power required by PCIec card max. 4W å Devices 3V3 å Devices Figure 13: Power calculation - Automation PC 820 Information: The PCIec card must not consume more than a total of 4 W (12V/5V/3V3)! Automation PC 820 User's Manual V 1.20...

  • Page 47: Block Diagram

    Hex switch Cmos profile ? DC/DC + 5V Switching DC/DC + 3.3V Switching Interface fed toward outside DC/DC + 12V Switching Interface optional or internal Figure 14: Block diagram - Automation PC 820 Automation PC 820 User's Manual V 1.20...

  • Page 48: Device Interfaces

    CPU board Video signals 5PC800.B945-00 RGB, DVI, SDL 5PC800.B945-01 RGB, DVI, SDL 5PC800.B945-02 RGB, DVI, SDL 5PC800.B945-03 RGB, DVI, SDL 5PC800.B945-04 RGB, DVI, SDL Table 16: Monitor / Panel connection - RGB, DVI, SDL Automation PC 820 User's Manual V 1.20...

  • Page 49: Usb Interfaces

    USB1 USB2 USB4 USB3 Table 17: USB1, USB2, USB3, USB4 connection 1) For safety, every USB port is equipped with a maintenance free "USB current-limiting circuit breaker" (max. 500 mA or 1 A). Automation PC 820 User's Manual V 1.20...
  • Page 50 Max. 1 A Maximum 5 m (without hub) Cable length Table 18: USB5 connection 1) For safety, every USB port is equipped with a maintenance free "USB current-limiting circuit breaker" (max. 1 A) Automation PC 820 User's Manual V 1.20...

  • Page 51: Serial Interface Com1

    Paired shield with aluminum foil Grounding line Cable cross section 1 x 0.34 mm² (22AWG/19), tinned Cu wire Wire insulation ≤ 59 Ω / km Conductor resistance Table 21: RS232 - Cable requirements Automation PC 820 User's Manual V 1.20...
  • Page 52 Technical data • Entire device RS232 cable Property Outer sheathing Item PUR mixture Characteristics Halogen free Entire shielding From tinned cu wires Table 21: RS232 - Cable requirements Automation PC 820 User's Manual V 1.20...

  • Page 53: Serial Interface Com2

    The maximum transfer rate of 115 kBit/s depends on the cable type being used. Extension Transfer rate ≤ 15 m typ. 64 kBit/s ≤ 10 m typ. 115 kBit/s ≤ 5 m typ. 115 kBit/s Table 24: RS232 - Bus length and transfer rate Automation PC 820 User's Manual V 1.20...
  • Page 54 1 x 0.34 mm² (22AWG/19), tinned Cu wire Wire insulation ≤ 59 Ω / km Conductor resistance Outer sheathing Item PUR mixture Characteristics Halogen free Entire shielding From tinned cu wires Table 27: RS422 - Cable requirements Automation PC 820 User's Manual V 1.20...
  • Page 55 Cable cross section 4 x 0.25 mm² (24AWG/19), tinned Cu wire Wire insulation ≤ 82 Ω/km Conductor resistance Stranding Wires stranded in pairs Shield Paired shield with aluminum foil Table 29: RS485 - Cable requirements Automation PC 820 User's Manual V 1.20...
  • Page 56 1 x 0.34 mm² (22AWG/19), tinned Cu wire Wire insulation ≤ 59 Ω/km Conductor resistance Outer sheathing Item PUR mixture Characteristics Halogen free Entire shielding From tinned cu wires Table 29: RS485 - Cable requirements (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 57: Can

    The node switch is located behind the front cover. The front cover must first be slid down to change the node switch. Switch position Description 0 ... F 0 ... F Table 31: CAN node switch (x1, x16) Automation PC 820 User's Manual V 1.20...
  • Page 58 Table 32: CAN terminating switch / LED Status LED CAN Status LED CAN Yellow LED for Sends data Receives data Table 33: Status LED CAN Automation PC 820 User's Manual V 1.20...

  • Page 59: Powerlink

    Controlled Node (CN) The CN waits until it receives an SoC frame and then switches to PRE_OPERATIONAL_2 status (double flash). Table 36: Status/Error LED as status LED - POWERLINK operating mode Automation PC 820 User's Manual V 1.20...
  • Page 60 Switch position Description Operation as managing node 0 ... D 1 ... F station number Operation as controlled node Reserved Reserved Table 37: POWERLINK node switch (x1, x16) Automation PC 820 User's Manual V 1.20...

  • Page 61: Ethernet 1 (Eth1)

    A special driver is necessary for operating the Realtek Ethernet controllers RTL8111B/C. The necessary software can be downloaded from the download area on the B&R homepage (www.br-automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 820 User's Manual V 1.20...

  • Page 62: Ethernet 2 (Eth2)

    A special driver is necessary for operating the Intel Ethernet controller 82574. The necessary drivers can be downloaded from the download area on the B&R homepage (www.br- automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 820 User's Manual V 1.20...

  • Page 63: Status Leds

    Green Application running Service mode Yellow User LED Table 40: Data - status LEDs The light for the Status LEDs is fed to the front cover via fiber optic lines. Automation PC 820 User's Manual V 1.20...

  • Page 64: Cmos Profile Switch

    The position of the CMOS profile switch is is displayed in the BIOS setup pages and in the B&R ADI Control Center, among other places. Automation PC 820 User's Manual V 1.20...

  • Page 65: Power Button

    The APC820 is restarted (cold restart). The MTCX processor is not reset when the reset button is pressed. Table 43: Reset button Warning! A system reset can cause data to be lost! Automation PC 820 User's Manual V 1.20...

  • Page 66: Battery

    Data buffering is guaranteed Data buffering is guaranteed for approx. another 500 hours from the point in time that the battery capacity is determined to be BAD (insufficient). Table 45: Meaning of battery status Automation PC 820 User's Manual V 1.20...

  • Page 67: Hardware Security Key (Dongle)

    Hardware Security Key A hardware security key (dongle) can be inserted behind the black cover. Dongle Battery Table 46: Hardware Security Key Warning! Turn off power before removing or adding the hardware security key. Automation PC 820 User's Manual V 1.20...

  • Page 68: Compactflash Slot 1

    CompactFlash 1024 MB SSI 5CFCRD.2048-03 CompactFlash 2048 MB SSI 5CFCRD.4096-03 CompactFlash 4096 MB SSI 5CFCRD.8192-03 CompactFlash 8192 MB SSI Table 47: CompactFlash slot (CF1) Warning! Turn off power before inserting or removing the CompactFlash card! Automation PC 820 User's Manual V 1.20...

  • Page 69: Compactflash Slot 2

    CompactFlash 1024 MB SSI 5CFCRD.2048-03 CompactFlash 2048 MB SSI 5CFCRD.4096-03 CompactFlash 4096 MB SSI 5CFCRD.8192-03 CompactFlash 8192 MB SSI Table 48: CompactFlash slot (CF2) Warning! Turn off power before inserting or removing the CompactFlash card! Automation PC 820 User's Manual V 1.20...

  • Page 70: Individual Components

    Power management ACPI 2.0, S3 Support (suspend to RAM) Table 49: Technical data - CPU boards 1) At max. specified ambient temperature: typically 58 ppm (5 seconds) - worst-case 220 ppm (19 seconds). Automation PC 820 User's Manual V 1.20...

  • Page 71: Main Memory

    200 Pin SO-DIMM Organization 64M x 64-bit 128M x 64-bit 256M x 64-bit Table 50: Technical data - Main memory Information: A main memory module can only be replaced at the B&R plant. Automation PC 820 User's Manual V 1.20...

  • Page 72: Power Supply With Heat Sink

    Aluminum (heat sink) Weight 900 g 900 g Table 51: Technical data - Power supply with heat sink Information: The power supply with heat sink can only be replaced at the B&R plant. Automation PC 820 User's Manual V 1.20...

  • Page 73: Replacement Fan

    8BXF001.0000-00 Fan type Width 50 mm Length 50 mm Height 15 mm Revolution speed 5500 rpm ±10% Noise level 36.5 dB Lifespan 65,000 hours at 40°C Table 52: Technical data - Replacement fan Automation PC 820 User's Manual V 1.20...

  • Page 74: Plug-In Cards

    11.65 All values in mm. 64.9 Figure 20: Dimensions - PCIec cards Information: Only B&R PCIec cards that were specially designed for the Automation PC 820 and Panel PC 800 can be used. Automation PC 820 User's Manual V 1.20...

  • Page 75: Ethernet Card 10/100/1000 - 5Acpcc.eth0-00

    The following characteristics, features, and limit values only apply to this individual component and can deviate from those specified for the entire device. For the entire device in which this individual component is used, refer to the data given specifically for the entire device. Automation PC 820 User's Manual V 1.20...
  • Page 76 A special driver is necessary for operating the Intel Ethernet controller 82574. The necessary drivers can be downloaded from the download area on the B&R homepage (www.br- automation.com). Information: Required drivers can only be downloaded from the B&R homepage, not from manufacturers' pages. Automation PC 820 User's Manual V 1.20...

  • Page 77: Powerlink Card 2-Port - 5Acpcc.mpl0-00

    (orange) (green / orange) Green / red see Status / Error LED Link LED Blinking Yellow Link Activity (blinking) (POWERLINK (Data transfer in network progress) connection available) Table 54: POWERLINK card 2-port connection Automation PC 820 User's Manual V 1.20...
  • Page 78 No output data is produced and no input data is received. Only the appropriate command from the manager can enter or leave this state. Table 56: Status / Error LED as status LED - POWERLINK card 2-port operating mode Automation PC 820 User's Manual V 1.20...
  • Page 79 The one-digit card number ($1 – $F) is configured using the card number switch. This number is used to identify the module. Card number switch Figure 23: POWERLINK card 2-port node number switch Automation PC 820 User's Manual V 1.20...
  • Page 80 Technical data • Individual components Automation PC 820 User's Manual V 1.20...

  • Page 81: Chapter 3: Commissioning

    When connecting certain cable types (DVI, SDL, USB, etc.), keep the flex radius of the cable in mind (see section 2 "Cable connections", on page 89). • Make sure that sufficient space is provided for air circulation. Automation PC 820 User's Manual V 1.20...

  • Page 82: Mounting Plates

    B&R homepage (www.br- automation.com). The distances that must be used for mounting and ventilation of the Automation PC 820 and ACOPOSmulti modules can be found in the dimension diagrams for the individual modules.

  • Page 83: Cold-Plate Installation

    The distances that must be used for mounting and ventilation of the Automation PC 820 and ACOPOSmulti modules can be found in the dimension diagrams for the individual modules.

  • Page 84: Spacing For Air Circulation

    To ensure that the fan modules in the mounting plate can be exchanged easily, at least 250 mm has to be left free below the module. These defined intervals apply to all mounting methods for APC820. Automation PC 820 User's Manual V 1.20...

  • Page 85: Swivel Range Of The

    Keep the swivel range of the front cover on the front side of the APC820 free when installed to prevent problems connecting peripheral devices to the APC820. A..Swivel range of the front cover Figure 26: Swivel range of the front cover Automation PC 820 User's Manual V 1.20...

  • Page 86: Mounting The Apc820

    The APC820 must be thoroughly attached, so that it rests straight in the backplane module in order for the module contacts to function properly. • Tighten all M6 mounting screws (2 screws per module width) on the APC820 with a torque of max. 5 Nm. Automation PC 820 User's Manual V 1.20...
  • Page 87 Commissioning • Installation Figure 28: Tightening the fastening screws Automation PC 820 User's Manual V 1.20...

  • Page 88: Installation Guidelines Mounting Orientation

    Commissioning • Installation 1.6 Installation guidelines Mounting orientation The following diagrams illustrate the mounting orientations permitted by B&R. These are valid for cold-plate, feed-through and wall mounting. Figure 29: Permitted mounting orientations Automation PC 820 User's Manual V 1.20...

  • Page 89: Cable Connections

    Figure 30: Flex radius - Cable connection Information: The specified flex radius can be found in the Automation Panel 800 or Automation Panel 900 user's manual, which can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 820 User's Manual V 1.20...

  • Page 90: Connection Examples

    AP800 device. Automation Panel 800 Automation Panel 900 5AP820.1505-00 5AP920.1505-01 5AP951.1505-01 5AP980.1505-01 5AP981.1505-01 5AP880.1505-00 5AP920.1505-01 5AP951.1505-01 5AP980.1505-01 5AP981.1505-01 Table 58: Selecting the display units Automation PC 820 User's Manual V 1.20...

  • Page 91: One Automation Panel 900 Via Dvi

    Max. SXGA ✓ ✓ 5PC800.B945-02 / -12 Max. SXGA ✓ ✓ 5PC800.B945-03 / -13 Max. SXGA ✓ ✓ 5PC800.B945-04 / -14 Max. SXGA Table 59: Possible combinations of system unit and CPU board Automation PC 820 User's Manual V 1.20...

  • Page 92: Link Modules

    5 m / 10 m ✓ 5AP920.1706-01 17.0“ SXGA 5 m / 10 m ✓ 5AP920.1906-01 19.0“ SXGA 5 m / 10 m Table 62: Possible Automation Panel units, resolutions und segment lengths Automation PC 820 User's Manual V 1.20...

  • Page 93: Bios Settings

    1) USB support is not possible on the Automation Panel 900 because USB is limited to 5 m. Information: The DVI transfer mode does not allow reading statistical values on Automation Panel 900 units. 3.2.5 BIOS settings No special BIOS settings are necessary for operation. Automation PC 820 User's Manual V 1.20...

  • Page 94: One Automation Panel 900 Via Sdl

    Connection for SDL in, transfer of display data, touch screen, USB 1.1, matrix keys, and service data, 24 VDC (screw clamp 0TB103.9 or cage clamp 0TB103.91 sold separately). Table 64: Link module for the configuration - One Automation Panel 900 via SDL Automation PC 820 User's Manual V 1.20...

  • Page 95: Cables

    Table 65: Cables for SDL configurations Information: Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 820 User's Manual V 1.20...

  • Page 96: Bios Settings

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 820 User's Manual V 1.20...

  • Page 97: One Automation Panel 800 Via Sdl

    SDL cable for fixed and flexible type of layout 5CASDL.0100-20 SDL cable for fixed and flexible type of layout 10 m 5CASDL.0150-20 SDL cable for fixed and flexible type of layout 15 m Table 68: Cables for SDL configurations Automation PC 820 User's Manual V 1.20...

  • Page 98: Bios Settings

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 820 User's Manual V 1.20...

  • Page 99: One Ap900 And One Ap800 Via Sdl

    Max. UXGA ✓ ✓ 5PC800.B945-02 / -12 Max. UXGA ✓ ✓ 5PC800.B945-03 / -13 Max. UXGA ✓ ✓ 5PC800.B945-04 / -14 Max. UXGA Table 70: Possible combinations of system unit and CPU board Automation PC 820 User's Manual V 1.20...

  • Page 100: Link Modules

    The COM C must be enabled in BIOS in order to operate the connected panel touch screen on the monitor / panel connection (found in the BIOS menu under "Advanced - Main board / Panel Features - Legacy Devices"). Automation PC 820 User's Manual V 1.20...

  • Page 101: Four Automation Panel 900 Units Via Sdl

    Max. UXGA ✓ ✓ 5PC800.B945-02 / -12 Max. UXGA ✓ ✓ 5PC800.B945-03 / -13 Max. UXGA ✓ ✓ 5PC800.B945-04 / -14 Max. UXGA Table 72: Possible combinations of system unit and CPU board Automation PC 820 User's Manual V 1.20...

  • Page 102: Link Modules

    Table 74: Cables for SDL configurations Information: Detailed technical data about the cables can be found in the Automation Panel 900 User's Manual. This can be downloaded as a .pdf file from the B&R homepage www.br-automation.com. Automation PC 820 User's Manual V 1.20...

  • Page 103: Bios Settings

    Peripheral USB devices can be connected to the USB interfaces. Due to the vast number of USB devices available on the market, B&R cannot guarantee their performance. B&R does ensure the performance of all USB devices that they provide. Automation PC 820 User's Manual V 1.20...

  • Page 104: Local On The Apc820

    USB memory media e.g. flash drive USB drives e.g. CD ROM drive USB input devices USB display devices e.g. keyboard e.g. mouse Figure 36: Local connection of USB peripheral devices on the APC820 Automation PC 820 User's Manual V 1.20...

  • Page 105: Remote Connection To Automation Panel 900 Via Dvi

    USB memory media e.g. flash drive USB input devices USB drives USB display devices e.g. keyboard e.g. CD ROM drive e.g. mouse Figure 37: Remote connection of USB peripheral devices to the APC900 via DVI Automation PC 820 User's Manual V 1.20...

  • Page 106: Remote Connection To Automation Panel 800/900 Via Sdl

    USB memory media e.g. flash drive USB input devices USB drives USB display devices e.g. keyboard e.g. CD ROM drive e.g. mouse Figure 38: Remote connection of USB peripheral devices to the APC800/900 via SDL Automation PC 820 User's Manual V 1.20...

  • Page 107: Known Problems / Issues

    The functionality of the touch system is not affected by this. This can be avoided by setting a panel locking time of 50 ms. The panel locking time can be configured with the B&R Key Editor. Automation PC 820 User's Manual V 1.20...
  • Page 108 Commissioning • Known problems / issues Automation PC 820 User's Manual V 1.20...

  • Page 109: Chapter 4: Software

    1.1 General information BIOS stands for "Basic Input Output System". It is the most basic standardized communication between the user and the system (hardware). The BIOS system used in the Automation PC 820 system is produced by American Megatrends Inc.

  • Page 110: Bios Setup Keys

    The key signals from the USB keyboard are only registered after the USB controller has been initialized. Keys Function Enters the BIOS setup menu. Using the F12 key, you can boot from the network. Table 76: 945GME - Bios-relevant keys at POST Automation PC 820 User's Manual V 1.20...
  • Page 111 The colors of the BIOS Setup are switched. Changes are reset. These settings are loaded for all BIOS configurations. Save and close. Exits the submenu. Table 77: 945GME - Bios-relevant keys in the BIOS menu Automation PC 820 User's Manual V 1.20...

  • Page 112: Main

    Serial Number Displays the CPU board serial number. None BC Firmware Rev. Displays the CPU board controller None firmware revision. MAC Address Displays the MAC addresses assigned for None (ETH1) the ETH1 interface. Automation PC 820 User's Manual V 1.20...

  • Page 113: Advanced

    Opens the submenu See "CPU configuration", on page 127. Chipset Configures the chipset functions. Enter Opens the submenu configuration See "Chipset configuration", on page 129. Table 78: 945GME - Advanced Menu - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 114 Main Board/Panel Displays device specific information and Enter Opens the submenu Features setup of device specific values. See "Main Board/Panel Features", on page 149. Table 78: 945GME - Advanced Menu - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 115: Acpi Configuration

    Enables this function. from S3/S4 on a connected USB device to wake the Disabled Disables the function system up from the S3/S4 standby mode. Table 79: 945GME - Advanced ACPI configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 116 Temperature setting for the critical trip point. set at which the operating system 100°C, 105°C, 110°C Can be set in 5 degree increments. automatically shuts itself down. Table 79: 945GME - Advanced ACPI configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 117: Pci Configuration

    See "PCI IRQ Resource Exclusion", on page 118 PCI Interrupt Configures PCI interrupt routing Enter Opens the submenu Routing See "PCI Interrupt Routing", on page 119 Table 80: 945GME - Advanced PCI configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 118 Allocated by the system - cannot be used. devices. Available Available - can be used. Reserved Reserved - cannot be used. Table 81: 945GME - Advanced PCI IRQ Resource Exclusion - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 119 PIRQ E Option for setting the PIRQ E. Auto Automatic assignment by the BIOS and operating (INTD, PATA, system. UHCI3) 5,6,7,9,10.12 Manual assignment. Table 82: 945GME - Advanced PCI Interrupt Routing - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 120 Assigns the PIRQ as 3rd exclusive PCI IRQ. exclusively (no IRQ sharing). Information: Only displayed when three PIRQs are set manually. Table 82: 945GME - Advanced PCI Interrupt Routing - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 121: Pci Express Configuration

    Enables this function. Information: Disabled Disables this function. If you are not using any PCI Express devices, this option should be deactivated. Table 83: 945GME - Advanced PCI Express Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 122 Interrupt Controller) on the PCIE port 0. The IRQ resources available to the system are expanded when the APIC mode is enabled. Table 83: 945GME - Advanced PCI Express Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 123: Graphics Configuration

    SDVO Port C Device [None] Change Option General Help SDVO/DVI Hotplug Support [Enabled] Save and Exit Display Mode Persistence [Enabled] Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 47: 945GME - Advanced Graphics Configuration Automation PC 820 User's Manual V 1.20...
  • Page 124 Boot Display Device option is set to SDVO-C SDVO-B LFP Serial Digital Video C output - Serial Digital Video "Auto". B output - Local Flat Panel. Table 84: 945GME - Advanced Graphics Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 125 Video signal output is optimized for a LVDS- compatible video device. DVI-Analog Video signal output is optimized for an analog DVI-compatible video device. Table 84: 945GME - Advanced Graphics Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 126 DVI monitors are reconnected, even if only one of them was connected and activated during a previous boot. Table 84: 945GME - Advanced Graphics Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 127: Cpu Configuration

    Both cores are used in a Dual Core processor. Processing option can be used to disable a core. Disabled Only one core is used in a Dual Core processor. Table 85: 945GME - Advanced CPU Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 128 C4 Config Power Management in the Intel Core Duo Standard Standard C4 support. processors. Enhanced Enhanced C4 support. Disabled Disabled C4 support. Table 85: 945GME - Advanced CPU Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 129: Chipset Configuration

    Disabled Disables this function. (Graphics and Memory Controller Hub) Enabled Enables this function. supports TS (Thermal Sensor) in the Thermal Management Algorithm of the DIMM module. Table 86: 945GME Advanced Chipset setting options Automation PC 820 User's Manual V 1.20...

  • Page 130: I/O Interface Configuration

    I/O Interface Configuration Options Onboard Audio Controller [AC97] AC97 Disabled Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 50: 945GME Advanced I/O Interface Configuration Automation PC 820 User's Manual V 1.20...

  • Page 131: Clock Configuration

    Setting options Effect Spread spectrum With this option, the cycle frequency can Enabled Enables this function. be modulated by reducing Disabled Disables this function. electromagnetic disturbances. Table 88: 945GME Advanced Clock Configuration setting options Automation PC 820 User's Manual V 1.20...

  • Page 132: Ide Configuration

    The drive in the system that is connected Enter Opens the submenu Master to the IDE secondary master port is See "Secondary IDE Master", on page 138 configured here. Table 89: 945GME Advanced IDE Configuration setting options Automation PC 820 User's Manual V 1.20...
  • Page 133 IDE controller motherboard used. Information: Device IDE disk drive controller used. This option is not available on the APC820 CPU board. Therefore this setting is not relevant. Table 89: 945GME Advanced IDE Configuration setting options Automation PC 820 User's Manual V 1.20...
  • Page 134 Automatic enabling of this function when enabled, the number of blocks per request supported by the system. from the configuration sector of the hard drive is read. Table 90: 945GME - Primary IDE Master - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 135 Enabled Enables this function. 32 Bit Data Transfer This function enables 32-bit data transfer. Disabled Disables this function. Enabled Enables this function. Table 90: 945GME - Primary IDE Master - Setting options (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 136 Automatic enabling of this function when enabled, the number of blocks per request supported by the system. from the configuration sector of the hard drive is read. Table 91: 945GME - Primary IDE Slave - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 137 Enabled Enables this function. 32 Bit Data Transfer This function enables 32-bit data transfer. Disabled Disables this function. Enabled Enables this function. Table 91: 945GME - Primary IDE Slave - Setting options (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 138 Automatic enabling of this function when enabled, the number of blocks per request supported by the system. from the configuration sector of the hard drive is read. Table 92: 945GME - Secondary IDE Master - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 139 Enabled Enables this function. 32 Bit Data Transfer This function enables 32-bit data transfer. Disabled Disables this function. Enabled Enables this function. Table 92: 945GME - Secondary IDE Master - Setting options (cont.) Automation PC 820 User's Manual V 1.20...
  • Page 140 Automatic enabling of this function when enabled, the number of blocks per request supported by the system. from the configuration sector of the hard drive is read. Table 93: 945GME - Secondary IDE Slave - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 141 Enabled Enables this function. 32 Bit Data Transfer This function enables 32-bit data transfer. Disabled Disables this function. Enabled Enables this function. Table 93: 945GME - Secondary IDE Slave - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 142: Usb Configuration

    USB is supported again after the Auto Automatic enabling. operating system has started. A USB keyboard is still recognized during the POST. Table 94: 945GME - Advanced USB Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 143 Information: The message "No USB mass storage device detected" is displayed if no USB memory device has been installed. Table 94: 945GME - Advanced USB Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 144: Keyboard/Mouse Configuration

    NumLock key when booting. are enabled. Numeric keypad is enabled. Typematic rate The key repeat function is set here. Slow Slow key repeat. Fast Fast key repeat. Table 95: 945GME Advanced Keyboard/Mouse Configuration setting options Automation PC 820 User's Manual V 1.20...

  • Page 145: Remote Access Configuration

    Value set manually. here, as long as disabled is not entered in 57600 8,n,1 the remote access field. 38400 8,n,1 19200 8,n,1 09600 8,n,1 Table 96: 945GME - Advanced Remote Access Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 146 Enabled Enables this function. processor. Information: If this option is disabled, the boot time is reduced. Table 96: 945GME - Advanced Remote Access Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 147: Cpu Board Monitor

    Celsius and Fahrenheit). Top DIMM Displays the temperature of the first None Environment Temp. DRAM module in degrees Celsius and Fahrenheit. Table 97: 945GME - Advanced Remote Access Configuration - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 148 None supply. +12Vin Displays the current voltage of the 12 volt None supply. VRTC Displays the battery voltage (in volts). None Table 97: 945GME - Advanced Remote Access Configuration - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 149: Main Board/Panel Features

    Displays the version of the device within None the same B&R device code. This ID is needed for Automation Runtime. Serial Number Displays the B&R serial number. None Table 98: 945GME - Advanced Baseboard/Panel Features - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 150 For setting the brightness (in %) of the selected panel. 40%, 50%, 60%, 70%, panel. Changes take effect after saving and 80%, 90%, 100% restarting the system (e.g. by pressing <F10>). Table 99: 945GME - Panel Control - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 151 None of the baseboard in degrees Celsius and Fahrenheit. Baseboard Center Displays the temperature in the center of None the baseboard in degrees Celsius and Fahrenheit. Table 100: 945GME Baseboard Monitor setting options Automation PC 820 User's Manual V 1.20...
  • Page 152 Case 4 Displays the fan speed of housing fan 4. None Information: The APC820 only has 2 housing fans, which means this value is not relevant. Table 100: 945GME Baseboard Monitor setting options Automation PC 820 User's Manual V 1.20...
  • Page 153 Base I/O address Selection of the base I/O address for the 238, 2E8, 2F8, 328, 338, Selected base I/O address is assigned. COM port. 3E8, 3F8 Table 101: 945GME - Legacy Devices - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 154 Disabled Disables the controller. (ETH2) on and off. Enabled Enables the controller. ETH2 MAC Address Displays the Ethernet 2 controller MAC None address. Table 101: 945GME - Legacy Devices - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 155: Boot

    The boot sequence of a device type list can be changed. Device types that are not connected can also be entered to this list. Table 102: 945GME - Boot Menu - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 156 Determines if the system is on/off Remain Off Remains off. following power loss. Turn On Powers on. Last State Enables the previous state. Table 102: 945GME - Boot Menu - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 157: Security

    The hard disk security user password can Enter Opens the submenu User Passwords be created here. See "Hard disk security user password", on page 158 Table 103: 945GME - Security Menu - Setting options Automation PC 820 User's Manual V 1.20...

  • Page 158: Hard Disk Security User Password

    A user password allows the user to edit only certain BIOS settings. Table 104: 945GME Hard disk security user password Automation PC 820 User's Manual V 1.20...

  • Page 159: Hard Disk Security Master Password

    This function makes it possible to use the Enter Enter password. Master Password user password to change or configure each hard drive without having to reboot the device. Table 105: 945GME Hard Disk Security Master Password Automation PC 820 User's Manual V 1.20...

  • Page 160: Power

    Keyboard or PS/2 mouse activities return the Mouse saving mode is determined here. system to its normal state from a particular energy saving mode. IGNORE Activities are ignored. Table 106: 945GME - Power Menu - Setting options Automation PC 820 User's Manual V 1.20...
  • Page 161 Power Button Mode This function determines the function of On/Off Power button switches on/off. the power button. Suspend Suppresses the function. Table 106: 945GME - Power Menu - Setting options (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 162: Exit

    Table 107: 945GME - Exit Menu - Setting options 1.10 BIOS default settings The various positions of the CMOS profile hex switch (see figure "CMOS profile switch", on page 64) can be used to load pre-defined BIOS profile settings. Automation PC 820 User's Manual V 1.20...

  • Page 163: Main

    Settings highlighted in yellow are variations from the BIOS default profile (=profile 0). 1.10.1 Main Setting / View Profile 0 Profile 3 My setting System Time Table 109: 945GME Main profile setting overview Automation PC 820 User's Manual V 1.20...

  • Page 164: Advanced

    USB Device Wakeup from Disabled Disabled S3/S4 Active Cooling Trip Point Disabled Disabled Passive Cooling Trip Point Disabled Disabled Critical Trip Point 105°C 105°C Table 110: 945GME Advanced - ACPI configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 165 Auto PIRQ G (INTB, CAN, Timer) Auto PIRQ H (INTC, UHCI0, EHCI) Auto Auto 1st Exclusive PCI 2nd Exclusive PCI 3rd Exclusive PCI Table 111: 945GME Advanced - PCI configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 166 Table 113: 945GME Advanced - Graphics configuration profile setting overview CPU configuration Setting / View Profile 0 Profile 3 My setting MPS Revision Table 114: 945GME Advanced - CPU configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 167 Table 116: 945GME Advanced - I/O Interface Configuration profile setting overview Clock Configuration Setting / View Profile 0 Profile 3 My setting Spread spectrum Disabled Disabled Table 117: 945GME Advanced - Clock configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 168 DMA Mode Auto S.M.A.R.T. Auto 32Bit data transfer Enabled Secondary IDE slave Type Auto LBA/Large Mode Auto Block (Multi-Sector Transfer) Auto PIO Mode Auto Table 118: 945GME Advanced - IDE configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 169 Remote access configuration Setting / View Profile 0 Profile 3 My setting Remote access Disabled Disabled Serial port BIOS update Disabled Disabled Table 121: 945GME Advanced - Remote Access Configuration profile setting overview Automation PC 820 User's Manual V 1.20...
  • Page 170 Enabled Base I/O address Interrupt IRQ3 IRQ3 COM C Enabled Disabled Base I/O address Interrupt IRQ11 Disabled Disabled Hardware Security Key Enabled Enabled Table 123: 945GME Advanced - Baseboard/Panel Features profile setting overview Automation PC 820 User's Manual V 1.20...

  • Page 171: Boot

    Profile 0 Profile 3 My setting Supervisor Password User Password Boot Sector Virus Protection Disabled Disabled Hard disk security user password Hard disk security master password Table 125: 945GME Security profile setting overview Automation PC 820 User's Manual V 1.20...

  • Page 172: Power

    Secondary Slave IDE MONITOR MONITOR Resume On Ring Disabled Disabled Resume on PME# Disabled Disabled Resume On RTC Alarm Disabled Disabled Power Button Mode On/Off On/Off Table 126: 945GME Power profile setting overview Automation PC 820 User's Manual V 1.20...

  • Page 173: Bios Error Signals (Beep Codes)

    Software • BIOS options 1.11 BIOS Error signals (beep codes) While the Automation PC 820 is booting, the following messages and errors can occur with BIOS. These errors are signaled by different beeping codes. 1.11.1 BIOS 945GME Beeping code Meaning...

  • Page 174: Distribution Of Resources

    1) TOM - Top of memory: max. installed DRAM 2) Only if ACPI Aware OS is set to "YES" in the setup. 3) The VGA frame buffer can be reduced to 1 MB in the setup. Automation PC 820 User's Manual V 1.20...

  • Page 175: I/O Address Assignment

    Table 129: I/O address assignment 1) The BIOS assigns the PCI and PCI Express Bus I/O resources from FFF0h downward. Devices that are not compatible with PnP/PCI/PCI Express cannot use the I/O resources in this area. Automation PC 820 User's Manual V 1.20...

  • Page 176: Interrupt Assignments In Pci Mode

    ❍ ❍ ❍ ❍ ❍ ❍ ❍ ● B&R (COM C) Table 130: IRQ interrupt assignments in PCI mode 1) Advanced Configuration and Power Interface. ● ... Default setting ❍ ... Optional setting Automation PC 820 User's Manual V 1.20...

  • Page 177: Interrupt Assignments In Apci Mode

    6) PIRQ E: PCI bus INTD, PATA in native mode, UHCI host controller 3 7) PIRQ F: PCI bus INTA, POWERLINK 8) PIRQ G: PCI bus INTB, CAN, timer 9) PIRQ H: PCI bus INTC, UHCI host controller 0, EHCI host controller Automation PC 820 User's Manual V 1.20...

  • Page 178: Interrupt Routing For Bios Up To V1.12

    Figure 72: Interrupt routing for BIOS up to V1.12 Information: The PIRQ C must be set to exclusive for an exclusive interrupt in the BIOS. In this case, devices cannot be connected to the USB interfaces (USB2 and USB4). Automation PC 820 User's Manual V 1.20...

  • Page 179: Interrupt Routing For Bios Starting With V1.14

    TIMER PIRQ G APIC IRQ22 PIRQ H UHCI 0 EHCI B0:D29:F0 B0:D29:F7 APIC IRQ23 IF slot B&R PCI Express compact slot PCI-EX Slot 2 Figure 73: Interrupt routing for BIOS starting with V1.14 Automation PC 820 User's Manual V 1.20...

  • Page 180: Upgrade Information

    BIOS setup (information about changes can be found in the Readme files of the BIOS upgrade). 2.1.1 What information do I need? Information: Individually saved BIOS settings are deleted when upgrading the BIOS. Before you begin the upgrade, it helps to determine the various software versions. Automation PC 820 User's Manual V 1.20...
  • Page 181 Select Item Serial Number: A3C70168427 Enter Go to Sub Screen Product Name: 5PC820.SX01-00 General Help User Serial ID: 00000000h Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 74: Software version Automation PC 820 User's Manual V 1.20...
  • Page 182 Select Screen Select Item Change Option General Help Save and Exit Exit v02.59 (C)Copyright 1985-2005, American Megatrends, Inc. Figure 75: Firmware version of the AP Link SDL transmitter Automation PC 820 User's Manual V 1.20...

  • Page 183: Bios Upgrade For 945Gme Com Express

    B945" is automatically carried out and the APC820 is automatically updated. • The system must be rebooted after a successful upgrade. • Reboot and press "Del" to enter the BIOS setup menu and load the setup defaults, then select "Save Changes and Exit". Automation PC 820 User's Manual V 1.20...

  • Page 184: Firmware Upgrade

    The following boot menu options including descriptions are based on Version 1.01 of the APC820 upgrade (MTCX, SDLR, SDLT, UPSI) disk. In some cases, these descriptions might not match the version you are currently using. Automation PC 820 User's Manual V 1.20...
  • Page 185 Monitor/Panel (default after 5 sec). 2.6 Return to main menu Returns to the main menu. Concerning point 3: Returns to the shell (MS-DOS). Information: The system must be powered off and on again after a successful upgrade. Automation PC 820 User's Manual V 1.20...

  • Page 186: Possible Upgrade Problems And Software Dependencies (For V1.01)

    Power button (to put the system in Standby mode), before executing the required power off/on. If not, the firmware upgrade will not work because the UPS buffers the system. Automation PC 820 User's Manual V 1.20...

  • Page 187: Creating An Ms-Dos Boot Diskette In Windows Xp

    Then select the checkbox "Create an MS-DOS startup disk", press "Start" and acknowledge the warning message with "OK". Figure 77: Creating a bootable diskette in Windows XP - step 2 Figure 78: Creating a bootable diskette in Windows XP - step 3 Automation PC 820 User's Manual V 1.20...
  • Page 188 Figure 79: Creating a bootable diskette in Windows XP - step 4 Figure 80: Creating a bootable diskette in Windows XP - step 5 Now all files (marked) except Command.com, IO.sys and MSDOS.sys can be deleted. Automation PC 820 User's Manual V 1.20...

  • Page 189: Creating A Bootable Usb Flash Drive For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Automation PC 820 User's Manual V 1.20...

  • Page 190: Where Do I Get Ms-Dos

    Information concerning creating an MS-DOS boot diskette can be found in section 2.3 "Creating an MS-DOS boot diskette in Windows XP", on page 187. Then the files from the diskette are to be copied to your hard drive. Automation PC 820 User's Manual V 1.20...

  • Page 191: Creating A Bootable Compactflash Card For B&R Upgrade Files

    In the B&R Upgrade text box, it's also possible to enter the path to the ZIP file for the B&R Upgrade Disk and select the file. • Click on the Start action button in the toolbar. Automation PC 820 User's Manual V 1.20...

  • Page 192: Where Do I Get Ms-Dos

    MS-DOS boot diskette in Windows XP", on page 187. Then the files from the diskette are to be copied to your hard drive. 2.6 Upgrade problems Potential upgrade problems are listed in the Liesmich.txt or Readme.txt files on the upgrade disks. Automation PC 820 User's Manual V 1.20...

  • Page 193: Automation Pc 820 With Ms-Dos

    Software • Automation PC 820 with MS-DOS 3. Automation PC 820 with MS-DOS DOS622 Deutsch Diskette 1- Setup Perfection in Automation Recovery Diskette Darf nur für Backup oder Archivierungszwecke für B&R Automatisierungsgeräte verwendet werden! www.br-automation.com ©1983-2000 Microsoft Corporation. Alle Rechte vorbehalten.
  • Page 194 Software • Automation PC 820 with MS-DOS The following table shows the tested resolutions and color depths on the Monitor / Panel connector with 945GME CPU boards. Color depth Resolutions for DVI 8-bit 16-bit 24-bit ✓ ✓ ✓ 640 x 480 ✓...

  • Page 195: Automation Pc 820 With Windows Xp Professional

    Software • Automation PC 820 with Windows XP Professional 4. Automation PC 820 with Windows XP Professional Figure 84: Windows XP Professional Logo Model number Short description Note 5SWWXP.0600-GER WinXP Professional with SP3, GER Microsoft OEM Windows XP Professional Service Pack 3, CD, German. Only available with a new device.

  • Page 196: Installation

    Software • Automation PC 820 with Windows XP Professional 4.1 Installation Upon request, the required Windows XP Professional version can be pre-installed at B&R Austria on a CompactFlash card. All of the drivers required for operation (graphics, network, etc.) are also installed when doing so.

  • Page 197: Automation Pc 820 With Windows Xp Embedded

    Software • Automation PC 820 with Windows XP embedded 5. Automation PC 820 with Windows XP embedded Figure 85: Windows XP Embedded Logo Model number Short description Note 5SWWXP.0428-ENG WinXPe FP2007 APC820 B945GME Microsoft OEM Windows XP Embedded Feature Pack 2007, English; for APC820 with 945GME chipset;...

  • Page 198: Features With Fp2007 (Feature Pack 2007)

    Software • Automation PC 820 with Windows XP embedded 5.2 Features with FP2007 (Feature Pack 2007) The feature list shows the most important device functions in Windows XP Embedded with Feature Pack 2007 (FP2007). Function Present ✓ Enhanced write filter (EWF) ✓...

  • Page 199: Installation

    Software • Automation PC 820 with Windows XP embedded 5.3 Installation Upon request, Windows XP Embedded can be preinstalled at B&R Austria on a suitable CompactFlash card (min. 512MB). The APC820 system is then automatically configured after it has been switched on for the first time. This procedure takes approximately 30 minutes, and the device will be rebooted a number of times.

  • Page 200: Automation Pc 820 With Windows Embedded Standard 2009

    Software • Automation PC 820 with Windows Embedded Standard 2009 6. Automation PC 820 with Windows Embedded Standard 2009 Figure 86: Windows Embedded Standard 2009 Logo Model number Short description Note 5SWWXP.0728-ENG Windows Embedded Standard 2009 APC820 945GME Microsoft OEM Windows Embedded, Standard 2009, English; for APC820 with 945GME chipset;...

  • Page 201: Features With Wes2009 (Windows Embedded Standard 2009)

    Software • Automation PC 820 with Windows Embedded Standard 2009 6.2 Features with WES2009 (Windows Embedded Standard 2009) The feature list shows the most important device functions in Windows Embedded Standard 2009. Function Present ✓ Enhanced write filter (EWF) ✓...

  • Page 202: Installation

    Software • Automation PC 820 with Windows Embedded Standard 2009 6.3 Installation Upon request, Windows Embedded Standard 2009 can be preinstalled at B&R Austria on a suitable CompactFlash card (min. 1GB). The APC820 system is then automatically configured after it has been switched on for the first time. This procedure takes approximately 30 minutes, and the device will be rebooted a number of times.

  • Page 203: B&R Automation Device Interface (Adi) - Control Center

    These cannot be used to draw any conclusions about any hardware alarms or error conditions. The hardware components used have automatic diagnostics functions that can be applied in the event of error. Automation PC 820 User's Manual V 1.20...

  • Page 204: Functions

    Content of B&R Windows XP Embedded image Panel PC 700 Windows Embedded Standard 2009 Content of B&R Windows Embedded Standard 2009 image Windows CE Content of B&R Windows CE image Table 139: System support - ADI driver Automation PC 820 User's Manual V 1.20...

  • Page 205: Installation

    1 . Download and unzip the ZIP archive 2 . Close all applications 3 . Run BrSetup.exe (e.g. double-click on it in Explorer). - or - Right click on BrSetup.inf in explorer and select "Install". Automation PC 820 User's Manual V 1.20...

  • Page 206: Sdl Equalizer Setting

    The value is optimally defined for the cable length when using the "Automatic setting". The equalizer value can only be changed if the function is supported by Automation Panel 900 (starting with Panel Firmware version 1.04 or higher). Automation PC 820 User's Manual V 1.20...

  • Page 207: Chapter 5: Standards And Certifications

    Low-voltage directive 2006/95/EG • Machine guidelines 98/37/EG beginning 12/29/2009: 2006/42/EG 2. Overview of standards The Automation PC 820 as an entire device meets the following standards: Standard Description EN 55011 Electromagnetic compatibility (EMC), radio disturbance product standard, industrial, scientific, and Class A medical high-frequency devices (ISM devices), limit values and measurement procedure;...
  • Page 208 "Adjustable speed electric drives – Part 3: EMC requirements including specific test methods UL 508 Industrial control equipment (UL = Underwriters Laboratories) 47 CFR Federal Communications Commission (FCC), 47 CFR Part 15 Subpart B Class A Table 140: Overview of standards (cont.) Automation PC 820 User's Manual V 1.20...

  • Page 209: Emission Requirements (Emission)

    ≤ 75 A per phase and subject to conditional low-voltage supply systems, equipment with rated current ≤ 75 connection, class A/D A per phase, and subject to conditional connection. Table 141: Overview of limits and testing guidelines for emissions Automation PC 820 User's Manual V 1.20...

  • Page 210: Network-Related Emissions

    79 dB (µV) 79 dB (µV) 150 kHz - 500 kHz Quasi-peak value Quasi-peak value 66 dB (µV) 66 dB (µV) Average Average Table 142: Test requirements - Network-related emissions for industrial areas Automation PC 820 User's Manual V 1.20...

  • Page 211: Emissions, Electromagnetic Emissions

    10 m Quasi-peak value > 960 MHz < 300 dB (µV/m) measured at a distance of 10 m Quasi-peak value Table 143: : Test requirements - Electromagnetic emissions for industrial areas Automation PC 820 User's Manual V 1.20...

  • Page 212: Requirements For Immunity To Disturbances (Immunity)

    The operating equipment must continue to work as directed after the test. There should be no interference in the operating behavior and no system failures below a minimum operating quality as defined by the manufacturer. Automation PC 820 User's Manual V 1.20...

  • Page 213: Electrostatic Discharge (Esd)

    3 seconds, criteria A 80 MHz - 1 GHz, 10 V/m, criteria A 80% amplitude modulation at 1 kHz, duration 3 seconds, criteria A Table 146: Test requirements - High-frequency electromagnetic fields (HF field) Automation PC 820 User's Manual V 1.20...

  • Page 214: High-Speed Transient Electrical Disturbances (Burst)

    ±0.5 kV, criteria B DC power outputs, L to PE ±1 kV, criteria B ±1 kV, criteria B Signal connections >30 m ±1 kV, criteria B All shielded cables Table 148: Test requirements - Surge voltages Automation PC 820 User's Manual V 1.20...

  • Page 215: Conducted Disturbances

    AC power inputs Voltage interruptions < 5% (> 95% reduction), 250 periods, criteria C AC power inputs 20 interruptions, 0.5 periods, criteria A Table 151: Test requirements - Voltage dips, fluctuations, and short-term interruptions Automation PC 820 User's Manual V 1.20...

  • Page 216: Damped Vibration

    2 m, criteria B ±2.5 kV, 1 MHz, repeat rate Power I/O, L to PE 400/seconds, length 2 seconds, connection lengths 2 m, criteria B Table 152: Test requirements - Damped vibration Automation PC 820 User's Manual V 1.20...

  • Page 217: Mechanical Conditions

    3 axes (x, y, z) 2 - 9 Hz Amplitude 3.5 mm 9 - 200 Hz Acceleration 1 g 200 - 500 Hz Acceleration 1.5 g Table 155: Test requirements - Vibration during transport (packaged) Automation PC 820 User's Manual V 1.20...

  • Page 218: Toppling

    Test carried out according to Limits according to EN 61800-2 IEC 60721-3-2, class 2M1 Free fall Devices with delivery packaging Weight Height < 100 kg 0.25 m Table 157: Test requirements - Free fall Automation PC 820 User's Manual V 1.20...

  • Page 219: Climate Conditions

    Limits according to EN 60068-2-1 EN 61131-2 Dry cold 16 hours at -40°C for 1 cycle, then 1 hour acclimatization and function testing, duration approximately 17 hours Table 161: Test requirements - Dry cold Automation PC 820 User's Manual V 1.20...

  • Page 220: Large Temperature Fluctuations

    EN 60068-2-3 EN 61131-2 Humid heat, constant (storage) 48 hours at +40°C and 92.5% RH, then insulation test within 3 hours, duration approximately 49 hours Table 165: Test requirements - Humid heat, constant (storage) Automation PC 820 User's Manual V 1.20...

  • Page 221: Safety

    1.0 mm² 3.3 V 1.5 mm² 2.6 V 2.5 mm² 1.9 V 4.0 mm² 1.4 V > 6.0 mm² 1.0 V Table 167: Test requirements - Ground resistance Automation PC 820 User's Manual V 1.20...

  • Page 222: Insulation Resistance

    < 60 V after 5 sec (active parts) < 60 V after 5 sec (active parts) < 60 V after 1 sec (plug pins) < 60 V after 1 sec (plug pins) Table 170: Test requirements - Residual voltage Automation PC 820 User's Manual V 1.20...

  • Page 223: Leakage Current

    48 VDC +20% 125 VDC 24 VAC 48 VAC 100 VAC 110 VAC - 15% 120 VAC +10% 200 VAC 230 VAC 240 VAC 400 VAC Table 174: Test requirements - Voltage range Automation PC 820 User's Manual V 1.20...

  • Page 224: Other Tests

    Protection against large solid foreign bodies 12.5 mm diameter Protection of personnel IP2. Protection against touching dangerous parts with fingers Protection against water IP.0 permeation with damaging Not protected consequences Table 176: Test requirements - Protection Automation PC 820 User's Manual V 1.20...

  • Page 225: International Certifications

    This mark is valid for the USA and Canada and simplifies certification of your machines and systems in these areas. Europe All harmonized EN standards for the applicable directives are met. Table 177: International Certifications Automation PC 820 User's Manual V 1.20...
  • Page 226 Standards and certifications • International certifications Automation PC 820 User's Manual V 1.20...

  • Page 227: Chapter 6: Accessories

    CompactFlash card with 1024 MB SLC NAND flash and IDE/ATA interface 5CFCRD.2048-03 CompactFlash 2048 MB SSI CompactFlash card with 2048 MB SLC NAND flash and IDE/ATA interface 5CFCRD.4096-03 CompactFlash 4096 MB SSI CompactFlash card with 4096 MB SLC NAND flash and IDE/ATA interface Automation PC 820 User's Manual V 1.20...
  • Page 228 SDL cable 30 m SDL cable for a fixed type of layout; length: 30 m 5CASDL.0300-03 SDL flex cable 30 m SDL cable for fixed and flexible type of layout; length: 30 m Automation PC 820 User's Manual V 1.20...
  • Page 229 RS232 extension cable for remote operation of a display unit with touch screen, length 5 m. 9A0014.10 RS232 cable DB9/f:DB9/m 10 m RS232 extension cable for remote operation of a display unit with touch screen, length 10 m. Automation PC 820 User's Manual V 1.20...

  • Page 230: Can Plug (4-Pin)

    Name 0TB704.9 0TB704.91 Number of pins Type of terminal Screw clamps Cage clamps Table 179: Technical data - TB103 supply plug Automation PC 820 User's Manual V 1.20...

  • Page 231: Replacement Cmos Batteries

    Self discharge at 23°C < 1% per year Storage time Max. 3 years at 30° C Environmental characteristics Storage temperature -20 to +60°C Relative humidity 0 to 95% (non-condensing) Table 181: Technical data - Lithium batteries Automation PC 820 User's Manual V 1.20...

  • Page 232: Dvi - Monitor Adapter 5Ac900.1000-00

    Model number Description Figure 5AC900.1000-00 Adapter DVI-A/m to CRT DB15HD/f Adapter DVI (plug) to CRT (socket), for connecting a standard monitor to a DVI-I interface. Table 182: Order data - DVI - CRT adapter Automation PC 820 User's Manual V 1.20...

  • Page 233: Compactflash Cards 5Cfcrd.xxxx-04

    5CFCRD.2048-04 2048 MB B&R CompactFlash card 5CFCRD.4096-04 4096 MB B&R CompactFlash card 5CFCRD.8192-04 8192 MB B&R CompactFlash card 5CFCRD.016G-04 16 GB B&R CompactFlash card CompactFlash card Table 183: Order data - CompactFlash cards Automation PC 820 User's Manual V 1.20...

  • Page 234: Technical Data

    438.36 GB/day 876.72 GB/day Clear/write cycles Guaranteed 100,000 Typical 2,000,000 SLC flash Wear leveling Static Endurance 5CFCRD.0512- 5CFCRD.1024- 5CFCRD.2048- 5CFCRD.4096- 5CFCRD.8192- 5CFCRD.016G Error Correction Coding (ECC) Table 184: Technical data - CompactFlash cards 5CFCRD.xxxx-04 Automation PC 820 User's Manual V 1.20...
  • Page 235 2) The file is written/read sequentially in True IDE mode with the DOS program Thruput.exe. 3) Endurance of B&R CF cards (linear written block size with 128 kB) 4) Depending on the average file size. 5) Not supported by B&R Embedded OS installer. Automation PC 820 User's Manual V 1.20...

  • Page 236: Temperature Humidity Diagram - Operation And Storage

    Figure 89: Temperature humidity diagram - CompactFlash cards 5CFCRD.xxxx-04 5.4 Dimensions 1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 90: Dimensions - CompactFlash card Type I Automation PC 820 User's Manual V 1.20...

  • Page 237: Benchmark

    5CFCRD.0512-04 5CFCRD.4096-04 5CFCRD.016G-04 5CFCRD.0512-03 5CFCRD.4096-03 Figure 91: ATTO disk benchmark v2.34 comparison (reading) 1024 2048 4096 8192 Transfer size [kb] 5CFCRD.0512-04 5CFCRD.4096-04 5CFCRD.016G-04 5CFCRD.0512-03 5CFCRD.4096-03 Figure 92: ATTO disk benchmark v2.34 comparison (writing) Automation PC 820 User's Manual V 1.20...

  • Page 238: Compactflash Cards - 5Cfcrd.xxxx-03

    CompactFlash 512 MB SSI 5CFCRD.1024-03 CompactFlash 1024 MB SSI 5CFCRD.2048-03 CompactFlash 2048 MB SSI 5CFCRD.4096-03 CompactFlash 4096 MB SSI 5CFCRD.8192-03 CompactFlash 8192 MB SSI CompactFlash card Table 185: Order data - CompactFlash cards Automation PC 820 User's Manual V 1.20...

  • Page 239: Technical Data

    MP100/200, PP100/200, PP300/400, PPC300, PPC700, PPC725, PPC800, Provit 2000, Provit 5000, APC620, APC680, APC810, APC820 Windows XP Professional Windows XP Embedded Windows Embedded Standard 2009 Windows CE 6.0 Table 186: Technical data - CompactFlash cards 5CFCRD.xxxx-03 Automation PC 820 User's Manual V 1.20...
  • Page 240 Max. 1000 g (9810 m/s 0-peak) Storage/Transport Max. 3000 g (29430 m/s 0-peak) Altitude max. 80,000 feet (24,383 m) Table 186: Technical data - CompactFlash cards 5CFCRD.xxxx-03 (cont.) 1) Not supported by B&R Embedded OS installer. Automation PC 820 User's Manual V 1.20...

  • Page 241: Temperature Humidity Diagram - Operation And Storage

    Figure 93: Temperature humidity diagram - CompactFlash cards 5CFCRD.xxxx-03 6.4 Dimensions 1.01 ±0.07 1.01 ±0.07 3.30 ±0.1 CompactFlash type I 2.44 ±0.07 1.65 0.63 ±0.07 41.66 ±0.13 4 x R0.5 ±0.1 42.8 ±0.1 Figure 94: Dimensions - CompactFlash card Type I Automation PC 820 User's Manual V 1.20...

  • Page 242: Usb Flash Drive

    Model number Description Figure 5MMUSB.2048-00 USB flash drive 2 GB SanDisk Cruzer Micro 5MMUSB.2048-01 USB flash drive 2 GB B&R USB 2.0 flash drive 2 GB Table 187: Order data - USB flash drives Automation PC 820 User's Manual V 1.20...

  • Page 243: Technical Data - 5Mmusb.2048-00

    0-peak) and 11 ms length Bearings Max. 80 g (784 m/s 0-peak) and 11 ms length Transport Max. 80 g (784 m/s 0-peak) and 11 ms length Table 188: Technical data - USB flash drive 5MMUSB.2048-00 Automation PC 820 User's Manual V 1.20...

  • Page 244: Temperature Humidity Diagram - Operation And Storage

    Figure 95: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-00 Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 820 User's Manual V 1.20...

  • Page 245: Technical Data - 5Mmusb.2048-01

    At 20 - 2000 Hz: 20 g (peak) Shock Operation max. 1500 g (peak) Bearings max. 1500 g (peak) Transport max. 1500 g (peak) Table 189: Technical data - USB flash drive 5MMUSB.2048-01 Automation PC 820 User's Manual V 1.20...

  • Page 246: Temperature Humidity Diagram

    Figure 96: Temperature humidity diagram - USB flash drive - 5MMUSB.2048-01 Temperature data is for operation at 500 meters. Derating the max. ambient temperature - typically 1°C per 1000 meters (from 500 meters above sea level). Automation PC 820 User's Manual V 1.20...

  • Page 247: Cables

    Single cable, DVI-D/m:DVI-D/m; length: 1.8 m 5CADVI.0050-00 DVI-D cable 5 m Single cable, DVI-D/m:DVI-D/m; length: 5 m 5CADVI.0100-00 DVI-D cable 10 m Single cable, DVI-D/m:DVI-D/m; length: 10 m Table 190: Model numbers - DVI cable 5CADVI.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 248: Technical Data

    Table 191: Technical data - DVI cable 5CADVI.0xxx-00 8.1.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 98: Flex radius specification Automation PC 820 User's Manual V 1.20...

  • Page 249: Dimensions

    Figure 99: Dimensions - DVI cable 5CADVI.0xxx-00 8.1.5 Contents of delivery Amount Component DVI cable in desired length, plug covers are attached at the cable ends. Table 192: Contents of delivery - DVI cable 5CADVI.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 250: Cable Specifications

    DVI cables provided by B&R are guaranteed to function properly. DVI-D (24+1), male DVI-D (24+1), male Pin assignments DVI-D (24+1), male DVI-D (24+1), male Shield Shield Figure 100: Pin assignments - DVI cable 5CADVI.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 251: Sdl Cable 5Casdl.0Xxx-00

    SDL cable for a fixed type of layout; length: 25 m 5CASDL.0300-00 SDL cable 30 m SDL cable for a fixed type of layout; length: 30 m Table 193: Model numbers - SDL cable 5CASDL.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 252: Technical Data

    Table 194: Technical data - SDL cables 5CASDL.0xxx-00 8.2.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 102: Flex radius specification Automation PC 820 User's Manual V 1.20...

  • Page 253: Dimensions

    Figure 103: Dimensions - SDL cable 5CASDL.0xxx-00 8.2.5 Contents of delivery Amount Component SDL cable in desired length, plug covers are attached at the cable ends. Table 195: Contents of delivery - SDL cable 5CASDL.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 254: Cable Specifications

    SDL cables provided by B&R are guaranteed to function properly. DVI (24+1), male DVI (24+1), male Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 104: Pin assignments - SDL cable 5CASDL.0xxx-00 Automation PC 820 User's Manual V 1.20...

  • Page 255: Sdl Cable With 45° Plug 5Casdl.0Xxx-01

    SDL cable for fixed type of layout with one-sided 45° plug; length: 10 m 5CASDL.0150-01 SDL cable 15 m 45° SDL cable for fixed type of layout with one-sided 45° plug; length: 15 m Table 196: Model numbers - SDL cable with 45° plug 5CASDL.0xxx-01 Automation PC 820 User's Manual V 1.20...

  • Page 256: Technical Data

    Table 197: Technical data - SDL cable with 45° plug 5CASDL.0xxx-01 8.3.3 Flex radius specification Ferrite magnet Plug Flex radius Flex radius Plug - Ferrite Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 106: Flex radius specification Automation PC 820 User's Manual V 1.20...

  • Page 257: Dimensions

    8.3.5 Contents of delivery Amount Component SDL cable with 45° plug in desired length, plug covers are attached at the cable ends. Table 198: Contents of delivery - SDL cable with 45° plug 5CASDL.0xxx-01 Automation PC 820 User's Manual V 1.20...

  • Page 258: Cable Specifications

    SDL cables provided by B&R are guaranteed to function properly. DVI (24+1), male DVI (24+1), male Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 108: Pin assignments - SDL cable with 45° plug 5CASDL.0xxx-01 Automation PC 820 User's Manual V 1.20...

  • Page 259: Sdl Flex Cable 5Casdl.0Xxx-03

    SDL cable for fixed and flexible type of layout; length: 25 m 30 m flex SDL cable 5CASDL.0300-03 SDL cable for fixed and flexible type of layout; length: 30 m Table 199: Model numbers - SDL flex cable 5CASDL.0xxx-03 Automation PC 820 User's Manual V 1.20...

  • Page 260: Technical Data

    Fixed installation -20 to +80°C Moving -5 to +60°C Bearings -20 to +80°C Fire resistance Fire resistant according to UL758 (cable vertical flame test) Table 200: Technical data - SDL flex cable 5CASDL.0xxx-03 Automation PC 820 User's Manual V 1.20...

  • Page 261: Flex Radius Specification

    Plug - Ferrite Ferrite - Ferrite Ferrite Ferrite magnet magnet Figure 110: Flex radius specification 8.4.4 Dimensions 36.5 37.5 ±2.5 110 ±10 Length All values in mm Figure 111: Dimensions - SDL flex cable 5CASDL.0xxx-03 Automation PC 820 User's Manual V 1.20...

  • Page 262: Contents Of Delivery

    24 AWG - Hot Plug Detect DDC data 24 AWG XUSB0 +5 V 24 AWG Schematic display mass 24 AWG Hot Plug detect 24 AWG Table 202: Structure - SDL flex cable 5CASDL.0xxx-03 Automation PC 820 User's Manual V 1.20...

  • Page 263: Cable Specifications

    TMDS DATA 2/SDL Shield TMDS DATA 2/SDL Shield TMDS Data 2+ TMDS Data 2+ TMDS Data 2- TMDS Data 2- Cable shielding Cable shielding Figure 112: Pin assignments - SDL flex cable 5CASDL.0xxx-03 Automation PC 820 User's Manual V 1.20...

  • Page 264: Sdl Flex Cable With Extender 5Casdl.0Xx0-13

    5CASDL.0430-13 43 m SDL flex cable with extender SDL cable with extender for fixed and flexible type of layout; length: 43 m Table 203: Model numbers - SDL flex cable with extender 5CASDL.0xx0-13 Automation PC 820 User's Manual V 1.20...

  • Page 265: Technical Data

    100 ±10 Ω Wave impedance Test voltage Wire / wire 1 kV Wire / shield 0.5 kV ≤ 30 V Operating voltage Environmental characteristics Table 204: Technical data - SDL flex cable with extender 5CASDL.0xx0-13 Automation PC 820 User's Manual V 1.20...

  • Page 266: Flex Radius Specification

    Ferrite - Extender Ferrite Extender magnet Figure 114: Flex radius specification 8.5.4 Dimensions 36.5 110 ±10 37.5 ±2.5 Length All values in mm Figure 115: Dimensions - SDL flex cable with extender 5CASDL.0xx0-13 Automation PC 820 User's Manual V 1.20...

  • Page 267: Contents Of Delivery

    SDL OUT SDL IN Panel OUT Panel IN Automation Panel 900 Automation Panel 900 Automation Panel Link 5DLSDL.1000-01 Automation PC 820 Figure 117: Example of signal direction display - SDL flex cable with extender Automation PC 820 User's Manual V 1.20...

  • Page 268: Cable Specifications

    Only B&R SDL flex cables with extender can be used. DVI (24+1), male DVI (24+1), male Extender Unit Black Box Pin assignments DVI (24+1), male DVI (24+1), male Shield Shield Figure 118: Pin assignments - SDL flex cable with extender 5CASDL.0xx0-13 Automation PC 820 User's Manual V 1.20...

  • Page 269: Rs232 Cable 9A0014.Xx

    Flex radius Min. 70 mm Table 207: Technical data - RS232 cables 9A0014.xx 8.6.3 Contents of delivery Amount Component RS232 cable in desired length Table 208: Contents of delivery - RS232 cables 9A0014.xx Automation PC 820 User's Manual V 1.20...

  • Page 270: Cable Specifications

    RS232 cables provided by B&R are guaranteed to function properly. DSUB (9-pin), male DSUB (9-pin), female Pin assignments DSUB (9-pin), male DSUB (9-pin), female Shield Shield Figure 120: Pin assignments - RS232 cables 9A0014.xx Automation PC 820 User's Manual V 1.20...

  • Page 271: Usb Cable 5Causb.00Xx-00

    Flexibility Flexible Flex radius Min. 100 mm Table 210: Technical data - USB cables 8.7.3 Contents of delivery Amount Component USB cable in desired length Table 211: Contents of delivery - USB cable Automation PC 820 User's Manual V 1.20...

  • Page 272: Cable Specifications

    If a self-built cable is used, B&R cannot guarantee that it will function properly. The USB cables provided by B&R are guaranteed to function properly. Pin assignments USB Type A, male USB Type B, male Shield Shield Figure 122: Pin assignments - USB cable Automation PC 820 User's Manual V 1.20...

  • Page 273: Chapter 7: Maintenance / Servicing

    • The battery should only be changed by qualified personnel. The following replacement lithium batteries are available: 4A0006.00-000 (1 pc.) and 0AC201.91 (4 pcs.). Automation PC 820 User's Manual V 1.20...

  • Page 274: Procedure

    Maintenance / Servicing • Changing the battery 1.1 Procedure • Cut off power supply to the Automation PC 820 (disconnect from the ACOPOSmulti rail). • Touch the housing or ground connection (not the power supply!) in order to discharge any electrostatic charge from your body.
  • Page 275 Reconnect the APC820 to the ACOPOSmulti rail and press the power button. • Date and time might need to be reset in BIOS. Warning! Lithium batteries are considered hazardous waste. Used batteries should be disposed of according to local requirements. Automation PC 820 User's Manual V 1.20...

  • Page 276: Changing The Fan

    Maintenance / Servicing • Changing the fan 2. Changing the fan • Cut off power supply to the Automation PC 820 (disconnect from the ACOPOSmulti rail). • Touch the housing or ground connection (not the power supply!) in order to discharge any electrostatic charge from your body.

  • Page 277: Maintenance Controller Extended (Mtcx)

    Statistical data recording (power cycles - each power on, power on and fan hours are recorded - every full hour is counted e.g. 50 minutes no increase) • SDL data transfer (display, matrix keyboard, touch screen, service data, USB) Automation PC 820 User's Manual V 1.20...
  • Page 278 The functions of the MTCX can be expanded via Firmware upgrade . The version can be read in BIOS or in Microsoft Windows XP/embedded, using B&R Control Center. 1) Can be downloaded from the download area on the B&R homepage (www.br-automation.com). Automation PC 820 User's Manual V 1.20...

  • Page 279: B&R Key Editor Information

    4 assignments per key possible (using layer function) • Configuration of panel locking time when multiple Automation Panel 900 devices are connected to Automation PC 620, Automation PC 810, Automation PC 820 and Panel PC 700 devices. Automation PC 820 User's Manual V 1.20...
  • Page 280 The B&R Key Editor can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Additionally, it can also be found on the B&R HMI Drivers & Utilities DVD (model number 5SWHMI.0000-00). Automation PC 820 User's Manual V 1.20...

  • Page 281: B&R Automation Device Interface (Adi) Development Kit

    ADI DLL (for testing the applications, if no ADI drive is installed). Supports following systems (Version 2.40 and higher): • Automation PC 620 • Automation PC 810 • Automation PC 820 • Mobile Panel 40/50 Automation PC 820 User's Manual V 1.20...
  • Page 282 ADI functions can be found in the integrated online help. The B&R Automation Device Interface (ADI) development kit can be downloaded for free from the download area on the B&R homepage (www.br-automation.com). Automation PC 820 User's Manual V 1.20...

  • Page 283: Glossary

    Although BIOS is used to configure a system's performance, the user does not usually come into contact with it. Automation PC 820 User's Manual V 1.20...
  • Page 284 It indicates that the individual or corporate body who has performed or attached the label assures that the product conforms to all EU guidelines for complete harmonization. It also indicates that all mandatory conformity evaluation procedures have taken place. Automation PC 820 User's Manual V 1.20...
  • Page 285 A device component which allows access to other devices on a computer subsystem. A disk controller, for example, allows access to hard disks and disk drives and is responsible both for physical and logic drive access. Automation PC 820 User's Manual V 1.20...
  • Page 286 "Double In-line Memory Module" consisting of one or more RAM chips on a small circuit board that is connected with the motherboard of a computer. Direct Memory Access > Accelerated direct access to a computer’s RAM by bypassing the CPU. Automation PC 820 User's Manual V 1.20...
  • Page 287 / TFT displays transferred as 128 KB data blocks to the graphics card via the Display Data Channel (DDC). This EDID data can be used to set the graphics card to the monitor properties. Automation PC 820 User's Manual V 1.20...
  • Page 288 The first element inserted is the first one removed. Such an organization method is typical for a list of documents that are waiting to be printed. Automation PC 820 User's Manual V 1.20...
  • Page 289 An abbreviation for "Integrated Drive Electronics". A drive interface where the controller electronics are integrated in the drive. Automation PC 820 User's Manual V 1.20...
  • Page 290 Keypad modules are divided into two groups: Standard Keypad Modules (can be cascaded to a controller) and Special Keypad Modules (must be connected by an electrician according to the function e.g. Emergency Stop) Automation PC 820 User's Manual V 1.20...
  • Page 291 Million instructions per second > Measurement for the computing speed of computers. Mkey An abbreviation for "Module keyblock". A common term given to keys found on Provit display units. They can be freely configured with Mkey utilities. Automation PC 820 User's Manual V 1.20...
  • Page 292 .NET Framework (.NET Compact Framework). Abbreviation for "Original Equipment Manufacturer"; A company that integrates third-party and in-house manufactured components into their own product range and then distributes these products under its own name. Automation PC 820 User's Manual V 1.20...
  • Page 293 (and other portable computers), and intelligent electronic devices. Version 1 of the PCMCIA standard was introduced in 1990. PICMG PCI Industrial Computers Manufacturers Group; Goal; Use of commercial PCI bus for industrial environments, especially CompactPCI bus (www.picmg.org). Automation PC 820 User's Manual V 1.20...
  • Page 294 B&R Power Panel type. It is equipped with an RS232 interface, a CAN interface, a PCMCIA slot and integrated digital input/output channels. Additionally, up to six B&R System 2003 screw-in modules can be connected. 5.7" QVGA b/w LCD. Automation PC 820 User's Manual V 1.20...
  • Page 295 The various ROM memory types do allow random access, but they cannot be written to. The term RAM refers to a more temporary memory that can be written to as well as read. Automation PC 820 User's Manual V 1.20...
  • Page 296 An abbreviation for "Receive (RX) Data". A line for transferring serial data received from one device to another, e.g. from a modem to a computer. For connections complying with the RS- 232-C standard, the RXD is connected to pin 3 of the plug. Automation PC 820 User's Manual V 1.20...
  • Page 297 SUXGA Abbreviation for Super Ultra Extended Graphics Array; Generally a screen resolution of 2048×1536 pixels (4:3). An alternative name is QXGA (Quad Extended Graphics Array), which is 4x the pixel resolution of XGA. Automation PC 820 User's Manual V 1.20...
  • Page 298 An abbreviation for "Transmit (TX) Data". A line for the transfer of serial data sent from one device to another, e.g. from a computer to a modem. For connections complying with the RS- 232-C standard, the TXD is connected to pin 2 of the plug. Automation PC 820 User's Manual V 1.20...
  • Page 299 Abbreviation for "Ultra Extended Graphics Array" Generally a screen resolution of 1600 × 1200 pixels (aspect ratio 4:3, 12:9). An abbreviation for "Video Graphics Adapter". A video adapter which can handle all EGA (Enhanced Graphics Adapter) video modes and adds several new modes. Automation PC 820 User's Manual V 1.20...
  • Page 300 ETX® Standard (Rev. 2.7). However, if ISA signals are needed, a PCI-ISA can be implemented on the base board. The use of an LPC bus already in XTX™ is considerably cheaper than a bridge solution. Automation PC 820 User's Manual V 1.20...
  • Page 301 Block diagram - supply voltage ..............45 Figure 13: Power calculation - Automation PC 820............46 Figure 14: Block diagram - Automation PC 820 .............. 47 Figure 15: RS232/422/485 interface - operated in RS485 mode ........55 Figure 16: CPU board...................... 70 Figure 17: Main memory....................
  • Page 302 Creating a USB flash drive for B&R upgrade files........190 Figure 82: Creating a CompactFlash card for B&R upgrade files ......... 192 Figure 83: Automation PC 820 with MS-DOS ............... 193 Figure 84: Windows XP Professional Logo ..............195 Figure 85: Windows XP Embedded Logo..............
  • Page 303 Disconnecting the fan cable ................. 276 Figure 128: MTCX controller location ................277 Figure 129: B&R Key Editor screenshots (Version 3.00) ..........279 Figure 130: ADI development kit screenshots (Version 2.40) ......... 281 Automation PC 820 User's Manual V 1.20...
  • Page 304 Figure index Automation PC 820 User's Manual V 1.20...
  • Page 305 Table 43: Reset button ......................65 Table 44: Battery ......................... 66 Table 45: Meaning of battery status ..................66 Table 46: Hardware Security Key ..................67 Table 47: CompactFlash slot (CF1) ..................68 Automation PC 820 User's Manual V 1.20...
  • Page 306 Table 92: 945GME - Secondary IDE Master - Setting options.......... 138 Table 93: 945GME - Secondary IDE Slave - Setting options..........140 Table 94: 945GME - Advanced USB Configuration - Setting options ....... 142 Automation PC 820 User's Manual V 1.20...
  • Page 307 Device functions in Windows Embedded Standard 2009 ......... 201 Table 139: System support - ADI driver ................204 Table 140: Overview of standards ..................207 Table 141: Overview of limits and testing guidelines for emissions ........209 Automation PC 820 User's Manual V 1.20...
  • Page 308 Order data - CompactFlash cards ..............238 Table 186: Technical data - CompactFlash cards 5CFCRD.xxxx-03........239 Table 187: Order data - USB flash drives ................242 Table 188: Technical data - USB flash drive 5MMUSB.2048-00 ........243 Automation PC 820 User's Manual V 1.20...
  • Page 309 Contents of delivery - RS232 cables 9A0014.xx ..........269 Table 209: Model numbers - USB cables ................271 Table 210: Technical data - USB cables ................271 Table 211: Contents of delivery - USB cable ..............271 Automation PC 820 User's Manual V 1.20...
  • Page 310 Table index Automation PC 820 User's Manual V 1.20...
  • Page 311 5CASDL.0400-13....... 25 5CASDL.0430-13....... 25 5CAUSB.0018-00 ...... 25 5CAUSB.0050-00 ...... 25 9A0014.02 ......... 25 5CFCRD.0064-03 ...... 24 9A0014.05 ......... 25 5CFCRD.0128-03 ...... 24 9A0014.10 ......... 25 5CFCRD.016G-04 ..... 24 9S0000.01-010 ........26 5CFCRD.0256-03 ...... 24 Automation PC 820 User's Manual V 1.20...
  • Page 312 Model number index 9S0000.01-020 ........26 Automation PC 820 User's Manual V 1.20...
  • Page 313 Terminating switch ......... 58 CPU board monitor .......147 CE mark ........... 284 CPU configuration ........127 Certifications ..........225 Exit ............162 Changing the battery ....... 273 Graphics configuration ......123 Changing the fan ........276 Automation PC 820 User's Manual V 1.20...
  • Page 314 Excessive heat .......... 83 Wall mounting .........40 DIMM ............286 Directives ...........21 Disposal .............20 Fan control ......... 43, 277 Distribution of resources FDD ............288 I/O address assignment .......175 Fiber optics ..........288 RAM address assignment ....174 Automation PC 820 User's Manual V 1.20...
  • Page 315 Mounting plates ......... 82 Insulation resistance ........222 Cold-plate installation ......83 Interface ...........290 Feed-through mounting ......82 Interfaces ..........31, 48 Mounting the APC820 ....... 86 International Certifications .......225 MS-DOS ..........193 ISA ............290 MTBF ............292 Automation PC 820 User's Manual V 1.20...
  • Page 316 Link LED ..........59 Bus length ..........55 Node switch ..........60 Cable type ..........55 Speed LED ..........59 RTC ............. 66, 70 Station number .........60, 79 RTS ............296 Status / Error LED ......59, 78 Automation PC 820 User's Manual V 1.20...
  • Page 317 Link ............63 Upgrade information ........ 180 Power .............63 UPS ............299 Run ............63 USB ............299 Status LEDs ..........63 USB cable ..........271 Structure ............28 Cable specifications ......272 Supply voltage ........45, 48 Automation PC 820 User's Manual V 1.20...
  • Page 318 WUXGA ........... 300 Vibration during transport ......217 WXGA ............300 Vibration operation ........217 Video signals ..........48 Viruses ............20 Voltage dips ..........215 XGA ............300 Voltage fluctuations .........215 XTX ............300 Voltage range ..........223 Automation PC 820 User's Manual V 1.20...

This manual is also suitable for:

Apc8205pc820.sx01-005pc820.sx01-01

Table of Contents
