Part#: IB10DJH4A
Application:For 87-06 WRANGLER AND UNLIMITED
Item
Description
1
Driver/Left Sidebar
2
Passenger/Right Sidebar
3
Mounting Bracket
4
M12x50mm Hex Bolt
5
M12 Flat Washer
6
M12 Lock Washer
7
M8x30mm Hex Bolt
BLF
The instruction here is for your reference only. We strongly recommend the
professional installer for best result. We are not responsible for any damage
caused by the installation. Thank you for choosing our product!
Installation Instruction
QTY
Item
1
8
1
9
4
10
4
11
4
12
4
13
16
BRR
BRF
Page 1 of 3
Description
M8 Lock Washer
M8 Flat Washer
Driver Front Bar Bracket (BLF)
Driver Rear Bar Bracket (BLR)
Passenger Front Bar Bracket (BRF)
Passenger Rear Bar Bracket (BRR)
BLR
Mounting Brackets
REV: 20141201
QTY
16
16
1
1
1
1
