- Page 1 501156 FINE FURNITURE BENCH ASSEMBLY INSTRUCTION COASTER FINE FURNITURE www.coastercompany.com 2013/12/02 7 2014/7/25 Page 1 of 4...
- Page 2 501156 ITEM: ASSEMBLY INSTRUCTION Assembly Instruction ASSEMBLY TIPS: 1.Remove hardware from box and sort by size. 2.Please check to see that all hardware and parts are present prior to start of assembly. 3.please follow attached instructions in the same sequence as numbered to assurefast & easy assembly.
- Page 3 501156 ITEM: ASSEMBLY INSTRUCTION HARDWARE PACKAGE: DESCRIPTION FIGURE Φ 6pcs SCREW 4*40mm 16pcs ALLEN BOLT Φ1/4*14mm 4pcs Φ1/4*10mm LEVERLER ALLEN WRENCH Φ1/4*66mm You will need two people for this installation. And will take about thirty five minutes. STEP 1: Step 1: Place the cushion (A) upside down on a soft surface. Then align and attach the cushion frame (B) to the cushion (A) using the screws (1) tighten with the screw driver (NOT INCLUDED) 6PCS...
- Page 4 ASSEMBLY INSTRUCTION ITEM: 501156 STEP 2: Align and attach the crossbar (C) to the side (D) using allen bolt (2) tighten with allen wrench. Then screw four levelers into bottom of the bases. STEP 3: Align and holes of the base to them of cusion support and tighten them up with bolt and allen wrench.
