AirZing
UV-C light purifier PRO 5030
TM
Product Name
Product Code
Input Voltage
Input Current
Power Consumption
Dimension
Installation Height
Operational Temp.
Storage Temp.
Relative Humidity
1) IR sensor might get less sensitivity once the room temperate exceeds 35°C
2) Once the system is switched off by IR sensor, it will not be switched on automatically, it needs to be turned on manually.
5030 AirZing
UV-C light purifier PRO 5030
TM
4062172156622
220~240V, 50/60Hz
0.16A
34W
L1058mm/W54mm/H78mm
2.5M—4M
-10°C ~ 40°C
1)
-20°C ~ 60°C
≤80%
RoHS
UV-C
Advertisement
Table of Contents
Related Manuals for Osram AirZing PRO 5030
Summary of Contents for Osram AirZing PRO 5030
- Page 1 AirZing UV-C light purifier PRO 5030 RoHS UV-C 5030 AirZing UV-C light purifier PRO 5030 Product Name Product Code 4062172156622 Input Voltage 220~240V, 50/60Hz Input Current 0.16A Power Consumption Dimension L1058mm/W54mm/H78mm Installation Height 2.5M—4M Operational Temp. -10°C ~ 40°C Storage Temp. -20°C ~ 60°C Relative Humidity ≤80%...
- Page 2 INSTALLATION INSTRUCTIONS Loose screws to remove the cover plate Relocate the lamp holders from the casing and fix them into grooves at both ends of the casing Drill holes at the predefined mounting positions, and Mount the cover plate on the casing and fix the cover plate with screws embed plastic plugs for M4 screws (prepared by customers)
- Page 3 2 meters form the ground. This switch shall be equipped with a locking device, which can only be operated by dedicated operator; The original design and testing of this product is based on OSRAM HNS T8 30W double-end UV ―...
- Page 4 Mitarbeiter bedient werden kann; Das ursprüngliche Design und die Tests dieses Produkts beruhen auf der Doppelend-UV-Leuchtstoffröhre ― OSRAM HNS T8 30W. Die Funktionsweise kann sich bei Verwendung anderer Lichtquellen verändern; Die OSRAM HNS-Röhre enthält Quecksilber; bitte befolgen Sie bei der Entsorgung gebrauchter ―...
- Page 5 L’interrupteur doit être équipé d’un dispositif de verrouillage qui ne peut être actionné que par un opérateur dédié ; Le design original et les essais du produit sont basés sur le tube UV à double culot OSRAM HNS T8 30 ―...
- Page 6 2 meter vanaf de grond zijn. Deze schakelaar moet worden uitgerust met een sluitsysteem dat alleen kan worden bediend door de betreffende operator; Het originele ontwerp en de testprocedure van dit product zijn gebaseerd op een OSRAM HNS T8 30W ―...
- Page 7 More information English OSRAM Kunshan Display Optic Co., Ltd. No.2 Building, No.179 Waihejing Road, Kushan FTZ, China...
