- Page 1 ULTRASONIC AIR HUMIDIFIER PD ZS-10Z INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
11. AFTER-SALE SERVICE ...................... 14 Dear customer, Congratulations for your choice. The ultrasonic humidifier Puredry PD ZS-10Z excels for his quiet operation while having high performance. Please read the instruction manual carefully and get to know your humidifier through detailed instructions, so that you can eradicate dryness effectively with the most clever and economical way. -
Page 3: Safety Instructions
If these areas get wet, for whatever reason, dry them well before use. In case of doubt, dont use the humidifier and consult a professional electrician or call us at 2521103265 Puredry Hellas to speak with a qualified technician. -
Page 4: General Instructions
2. GENERAL INSTRUCTIONS Before using the humidifier for the first time, read carefully the instruction manual. After receiving the product, check the humidifier for any damage caused during the transportation. In case of damage, you must inform the seller immediately. Damages during transportation should be declared before you start using the humidifier. - Page 5 Make sure to drain all of the pollution and impurities and then connect to the machine pipe, the inner diameter of this equipment pipe joint is φ20, it adopts outer thread interface, when the interface connected with each other, make sure it is water or air tight.
-
Page 6: Product Structure
PRODUCT STRUCTURE PLEASE CHECK SKETCH 3 & 4. Sketch 3 1. Control panel 9.Soft tube 2. Emergency switch 10 Sensor interface 3. Lock 11.Mounting bracket 4. Electricity tank 12.Fix hole 5. Power supply 13.Spary outlet... - Page 7 6. Wheels 14.Hand-dug 7. Air inlet 15.Tank cover 8. Filter 16.Fix screw Sketch 4 Note: In order not to affect the mist production, emergency switch would be put into use when the timer error displays fault, after restoration the timer would continue to control the machine again.
-
Page 8: Control Panel
CONTROL PANEL DESCRIPTION POWER SWITCH Power switch: Press “Power” to start or stop power. HUMIDITY/TIME Humidity: Press “Set” button to adjust humidity, set through “+” or “-”. Time: Press “Set” to set time, use “+” or “-” to set time to start or stop machine. -
Page 9: System Function
SYSTEM FUNCTION HUMIDITY CONTROL When the humidity reaches the set level, the device will stop automatically. It will automatically start when the humidity drops to a certain level, the humidity range is 30-90%. The machine would stop up +5% of set humidity and restart below -5% of set humidity. -
Page 10: Pipe Layout
PIPE LAYOUT Please lay the pipeline strictly according to the requirement of manual. Seal the interface and makes it airproof, water proof, keep the pipeline smoothly, preventing leakage in the pipeline. In order to prevent spray outlet having its water falling back, the spray holes should be pointing 30 degree upward above the horizontal of the PVC cross-section. -
Page 11: Spray System
SPRAY SYSTEM Press Ring Seal Ring Piezo Seal Ring After long time running of the atomizer, if the spray capacity reduce or sprays water column, or some piezo can not make spray, please clean the water tank, atomizer and change new piezo ceramic. For the operation please take a reference of Sketch 8. Special Notice: it is the best state that the water level of water tank must be 3cm’s higher than atomizer sensor. -
Page 12: Maintanance
9. MAINTENANCE 1. Maintenance of the Water Tank: To minimize the impurities sticking on the atomizer, water shall be changed regularly by once per 7days however the automatic computer flushing system helps to minimize dirt and residue remain in the water tank. 2. - Page 13 3. Clean the filter: The filter shall be cleaned regularly by at least once a month in the following way: A. Unscrew the cover of the filter; B. Clear the dirt on filter element; C. Re-install the cover. 4. Working procedure of replacing piezo ceramic is as follows: A.
-
Page 14: Trouble Shooting
TROUBLE SHOOTING TROUBLE CAUSE TROUBLESHOOTING Indicator off A. No power A. Check the circuit and recover power supply B. Fuse is burnt B. Replace fuse of same C. Power switch is off specification C. Start power switch Supply no A. No water supply from the pipe A. - Page 15 TECHNICAL PARAMETER Spray Spray outlet Size Power Control Capacity Diameter Model Power Supply Manner (mm) (kg) (kg/h) (mm) 110 Single ZS-10Z 220V/50Hz 300W Auto 650*460*610 25.5 Outlet Puredry Hellas EE Phone numbers: 25211 03265, 25210 55992, 69816 65010 Mail: info@puredryhellas.com, service@puredryhellas.com...
-
Page 16: After-Sale Service
AFTER-SALE SERVICE Thank you for using our ultrasonic humidifier! Please read this manual carefully before installation and using this machine. The warranty period is one year for the general machine. If there are any quality issues during the warranty period, we would attend to it for free, but it does not include damage caused by human factor or misuse. - Page 17 Activate your Warranty Visit our web site and activate your warranty via the below link . https://www.puredryhellas.com/egguiseis Fill all the fields as shown below Once the warranty submission has been completed a confirmation message will þ be sent to your email...
Need help?
Do you have a question about the PD ZS-10Z and is the answer not in the manual?
Questions and answers
I have ZS-10Z ultrasonic humidifier in my laboratory. Problem is humidifier does not stop even it reached at desired set humidity level? If sensor is not working then there shall be E3 troubleshoot code? If my sensor is disturbed then how can I get new sensor?
