King Young S695G3 Installation Manual

INSTALLATION GUIDE
Item Checklist
Installation Guide
Installation
Guide
CPU Cooler
Driver DVD
Mainboard Layout
1
4
5
3
7
6
LI91_G3_1
Accessories Pack
Power Adapter
Power Cord
System Unit
1 1 Secondary COM Port Header Secondary COM Port Header
R1 R1
2 2 CPU Socket CPU Socket R2 R2
3 3 Optional Riser Card Slot Optional Riser Card Slot
R3 R3
4 4 Intel Giga LAN Chip Intel Giga LAN Chip R4 R4
5 5 SODIMM Slots SODIMM Slots
R5 R5
6 6 Intel Q370 Chip Intel Q370 Chip R6 R6
7 7 Super IO Chip Super IO Chip
R7 R7
2
8 8 CPU Cooling Fan Power Connector CPU Cooling Fan Power Connector R8 R8
9 9 CMOS Battery CMOS Battery
F1 F1
10 10 SATA Cable Connector SATA Cable Connector
F2 F2
11 11 SATA Power Connector SATA Power Connector
F3 F3
12 12 SATA HDD Connector SATA HDD Connector
F4 F4
13 13 Buzzler Buzzler
F5 F5
Standard LI91G3 Front IO Ports
8
9
F5
F4
10
11 Standard LI91G3 Rear IO Ports
12
13
R8 R7 R6 R5
Barebone System Unpacking Guide
1
Loose the screws on the rear panel
from the case.
2
Pull out the mainboard from the case.
Install CPU and CPU Cooler
GigaLAN Port GigaLAN Port
Two USB 3.1 Ports Two USB 3.1 Ports
PS/2 Keyboard and Mouse Ports PS/2 Keyboard and Mouse Ports
COM 1 COM 1
DVI-I Port DVI-I Port
DC 12~48V Barrel Jack Power In DC 12~48V Barrel Jack Power In
Line-Out Audio Port Line-Out Audio Port
DP (Display Port) DP (Display Port)
1 Release the CPU socket lever and lift the metal frame
Mic-In Phone Jack Mic-In Phone Jack
of the CPU socket
Power Button Power Button
Reset Button Reset Button
Three GigaLAN Ports Three GigaLAN Ports
Four USB 3.1 Ports Four USB 3.1 Ports
2 Remoe the CPU socket cover. Be aware do not touch
any pins in the CPU socket.
F3 F2 F1
R1
R2
3 Put the CPU to the socket. Align the CPU notches with
the socket alignment keys and gently put the CPU onto
R4 R3
the socket.
SODIMM Slot
1
1
2
1
4 When CPU is properly seated, replace the metal
frame and push the CPU socket lever back to its
locked position.
Glue the heatsink compound on the CPU surface.
5
Install CPU cooler on top of CPU. Tighten CPU cooler
with screws into pillaret.
6 Connect CPU FAN connector to mainboard CPU
FAN socket.
Specifications are for reference only and subject to change without notice.
Install Memory
1
SODIMM
2
Complete
1 Insert SODIMM into the SODIMM slot
0
on the motherboard by 30 .
2
Push down the SODIMM.
