  • Page 1 INSTRUCTION MANUAL 2304-20 PULSE MODULE...

  • Page 3: Table Of Contents

    Contents Contents Introduction ............... 1 Inspection..............1 Safety Notes ............. 2 Notes on Use ............5 Chapter 1 Overview Product Overview ........11 Major Features .......... 12 Name and Function of the Parts....15 Dimension Diagrams ......... 17 Chapter 2 Settings Setting the Module ID ........
  • Page 4 Contents Chapter 4 Others Alarm Output ..........27 4.1.1 Output Rating......... 27 4.1.2 Internal Circuit........ 28 Insulation of Internal Circuit....... 30 Chapter 5 Specifications Basic Specifications ........31 Function Specifications ......32 General Specifications ......33 Chapter 6 Maintenance and Service Cleaning ............

  • Page 5: Introduction

    Introduction Introduction Thank you for purchasing the HIOKI “Model 2304- 20 PULSE MODULE”. To obtain maximum perfor- mance from the instrument, please read this man- ual first, and keep it handy for future reference. Inspection When you receive the instrument, inspect it care- fully to ensure that no damage occurred during shipping.

  • Page 6: Safety Notes

    Safety Notes Safety Notes This instrument is designed to comply with IEC 61010 Safety Standards, and has been thoroughly tested for safety prior to ship- ment. However, mishandling during use could result in injury or death, as well as damage to the instrument. Be certain that you understand the instructions and precau- tions in the manual before use.
  • Page 7 Safety Notes The following symbols in this manual indicate the relative importance of cautions and warnings Indicates that incorrect operation presents an extreme hazard that could result in serious injury or death to the user. Indicates that incorrect operation presents a sig- nificant hazard that could result in serious injury or death to the user.
  • Page 8 Safety Notes Measurement categories (Overvoltage categories) This instrument complies with CAT I safety requirements. To ensure safe operation of measurement instruments, IEC 61010 establishes safety standards for various electrical en- vironments, categorized as CAT I to CAT IV, and called mea- surement categories.

  • Page 9: Notes On Use

    Notes on Use Notes on Use Follow these precautions to ensure safe operation and to obtain the full benefits of the various func- tions. Operation and Installation environment. This instrument should be installed and operated indoors only, between 0 and 50°C and 80% RH or Do not allow the instrument less.
  • Page 10 Notes on Use To avoid damage to the instrument, protect it from physical shock when transporting and handling. Be especially careful to avoid physical shock from dropping. Do not obstruct the ventilation holes. Ventilation holes for heat radiation are provided on the top and rear panels of the instrument.
  • Page 11 Notes on Use Wiring • A qualified electrician shall perform the wir- ing to prevent electric shock. • Avoid live-line electrical work to prevent electric shock and accidents due to short- circuiting. • When tightening the screws, confirm that all screws are securely tightened. A loose screw may result in module errors, fire, or electric shock.
  • Page 12 Notes on Use • Connect the module to a power source that matches the rating in order to prevent fire. • Ensure that the power supply, input, and output are correctly wired according to the wiring dia- gram. (See the chapter on "Preparations" in the instructions manual for each module.) This will prevent fire, malfunction, and errors.
  • Page 13 Hioki representative for repair. Before using the instrument the first time, verify that it operates normally to ensure that the no damage occurred during storage or shipping. If you find any damage, contact your dealer or Hioki representative.
  • Page 14 Notes on Use...

  • Page 15: Chapter 1 Overview

    For example, the 2304-20 can be used to measure pulse output from a watthour meter or flowmeter. The 2304-20 is used with the power supply mod- ule, communications module, and module base. Usable 9766 CLAMP ON SENSOR...

  • Page 16: Major Features

    1.2 Major Features 1.2 Major Features The recording interval is selectable from 1 second to 60 minutes. The totals of measurements made during a record- ing interval can be recorded (with sampling once a second). The module has an alarm output terminal. The specified clamp sensor also makes it possible to count the current pulses output from the watt- hour meter without disconnecting the cables.
  • Page 17 1.2 Major Features Rough Estimate of Storable Data Quantity and Time Action at memory full: Continue recording (Endless) Recording Mode Instantaneous Value Quantity of storable 26000 data Recording interval 1 sec. 7.5 hours 2 sec. 14.5 hours 5 sec. 1.5 days 10 sec.
  • Page 18 1.2 Major Features Action at memory full: stop recording (Memory full stop) Recording Mode Instantaneous Value Quantity of storable 30000 data Recording interval 1 sec. 8.5 hours 2 sec. 17 hours 5 sec. 1.5 days 10 sec. 3.5 days 15 sec. 5 days 20 sec.

  • Page 19: Name And Function Of The Parts

    1.3 Name and Function of the Parts 1.3 Name and Function of the Parts Front Back POWER LED Module ID setting dial Mark area CH1 terminal CH2 terminal ALARM terminal...
  • Page 20 This terminal is electrically insulated from CH1 and CH2 terminals. Module ID Use the dial to set the module's identification setting dial *1: The module needs repair. Contact your dealer or Hioki repre- sentative. *2: The same module ID may be used by another module.

  • Page 21: Dimension Diagrams

    1.4 Dimension Diagrams 1.4 Dimension Diagrams ± 22.5 ± ± 103.9 (Unit: mm)
  • Page 22 1.4 Dimension Diagrams...

  • Page 23: Chapter 2 Settings

    2.1 Setting the Module ID Chapter 2 Settings 2.1 Setting the Module ID You can connect up to 63 measurement modules to one communications module. Setting Procedure Use the module ID setting dial to set the ID No. of the module to a number from 01 and to 63. (You cannot set a number other than the above.) •...
  • Page 24 2.1 Setting the Module ID...

  • Page 25: Chapter 3 Preparations

    3.1 Installing the Module Chapter 3 Preparations 3.1 Installing the Module 3.1.1 Installing the Module Base Do not mount the module base on the ceiling where it may fall off. Fasten the module base to a DIN rail or the wall according to the procedure described in the 2391 or 2392 series MODULE BASE instruction man- ual.

  • Page 26: Connecting Input/Output Cables

    3.2 Connecting Input/Output Cables 3.2 Connecting Input/Output Cables Recommended Cable Single-wire: 0.14 to 1.5 mm Stranded-wire: 0.14 to 1.0 mm AWG: 26 to 16 Cable strip length: 5 mm 3.2.1 Connecting to CH1 Terminal (voltage/contact pulse signals input) • The CH1 and CH2 terminals are not insulated from each other.

  • Page 27: Connecting To Ch2 Terminal (9766 Clamp On Sensor)

    3.2 Connecting Input/Output Cables • In case of external noise, wind the cable around the ferrite clamp supplied as an accessory as shown below. • Note that measurement may be adversely affected by external noise or the electromagnetic environment when using a cable longer than 3 meters.
  • Page 28 3.2 Connecting Input/Output Cables Connecting the Energy Meter and 9766 Connect the supplied connec- tion cables to the C1 and C2 terminals of the energy meter. For more information on the cable connection, see the oper- ating manual for the composite power utility meter.

  • Page 29: Connecting Cables To The Alarm Terminal (Alarm Output)

    3.2 Connecting Input/Output Cables 3.2.3 Connecting Cables to the ALARM Terminal (Alarm output) Use a flat head screwdriver to loosen the screws on the supplied terminal block. Insert the cable for alarm output into the terminal block, then tighten the screws (at tightening torque of 0.25 N•m).

  • Page 30: Connection Locations Of Input/Output Cables

    3.2 Connecting Input/Output Cables 3.2.4 Connection Locations of Input/output Cables CH1 terminal Voltage/ Voltage/ (input) contact Not in use contact input (+) input (-) CH2 terminal (input) 9766 input 9766 input Not in use ALARM terminal Alarm Alarm Common (output) output output...

  • Page 31: Chapter 4 Others

    4.1 Alarm Output Chapter 4 Others 4.1 Alarm Output 4.1.1 Output Rating Ensure that the input does not exceed the maximum input voltage or current to avoid module damage, short-circuiting and electric shock resulting from heat building. Output method Open collector Maximum input 30 V, 20 mA max.

  • Page 32: Internal Circuit

    4.1 Alarm Output 4.1.2 Internal Circuit The alarm output circuit is configured as shown below. Photocoupler Internal circuit • Signal logic indicates the signal state in which a signal's function is enabled. • The output transistor works as a switch between signal output and ground in the module.
  • Page 33 4.1 Alarm Output Circuit diagram Power Power Relay Limit resistor Diode Output Output Connecting LED Connecting relay Wired-OR output Using on Wired-OR Logic • When connecting a relay or LED lamp, ensure that the relay or lamp operates at up to 30 V and 20 mA.

  • Page 34: Insulation Of Internal Circuit

    2304- Module, since measurements adversely affected. In the 2304-20, the input circuit and alarm output are insulated from the CAN bus as shown in the block diagram below. (Withstand voltage: 1.4 kVAC, 50/60 Hz, Response current: 5 mA, 1 minute)

  • Page 35: Chapter 5 Specifications

    5.1 Basic Specifications Chapter 5 Specifications 5.1 Basic Specifications Voltage/contact pulse input × 1 channel Simultaneous detection on 2 channels is also possible. Number of inputs Clamp-type current pulse input × 1CH (Detected using externally connected 9766 CLAMP ON SENSOR.) Voltage/contact pulse up to 4 kHz •...

  • Page 36: Function Specifications

    5.2 Function Specifications ±100 ppm rdg. ±1 dgt. Measurement Recording interval accuracy: ±2 ms accuracy Display range: Total of each channel at every interval (16,000,000 max.) Guaranteed 1 year accuracy period Sampling 1 time / sec. Input terminal 3 Input terminal block × 2 5.2 Function Specifications Actual time Time management using PC application...

  • Page 37: General Specifications

    New data will be added to the previous data at the start of recording. After recovering from a power outage, the Power outage 2304-20 automatically returns to the state protection held before the outage. 5.3 General Specifications ±100 ppm (Reference value at temperature Clock accuracy from 0 to 50°C without the communications...
  • Page 38 5.3 General Specifications Maximum rated 1.4 W power 1.4 kVAC Dielectric (Between input and alarm output, Input/Out- strength put and CAN bus) (50/60 Hz, Response cur- rent 5 mA, one minutes) Approx.22.5W × 96H × 85D mm (sans pro- Dimensions trusions) (0.89"W ×...

  • Page 39: Chapter 6 Maintenance And Service

    Hioki can- not be responsible for damage that occurs during shipment. • When transporting the 2304-20 Module or a sys- tem containing this module, tape the front of the module or take similar measures to avoid losing...
  • Page 40 6.2 Servicing...
