- Page 1 Rev 1.2 EN 18.03.2013 Pre-Amplifier UBBV-Series Manual M a d e i n G e r m a n y...
- Page 2 Please read this manual carefully before starting up the preamplifier. The manual gives you useful instructions how to operate the unit correctly. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com...
-
Page 3: Table Of Contents
Operating at PBS ProbeSet Activating the UBBV preamplifier Power connection 10.0 Reading out the calibration data 11.0 Warranty 12.0 Developer-Net, User Forum and more! 13.0 Frequency charts for spectrum analyzers & antennas HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 4: Safety Instructions
20dBm. The output power of the UBBV-preamplifier could be up to 20dBm. Please ensure that your connected measurement unit will not be dama- ged due to this power. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 5: Scope Of Delivery
2.0 Scope of delivery Please check before initial operation the completeness of delivery. Please reclaim missing parts immediately at Aaronia or at your Aaronia dealer. Included in delivery are the following items: (1) Cleaning brush (2) SMA adapter for operation with external devices (optional) -
Page 6: Sma Connections
This version is fixed screwed with our HyperLOG X antenna series and is spe- cially suited for the respective antenna (see instruction at section 6.0 „Operating at HyperLOG X antennas“) and therefore cannot be used for other purposes! HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 7: Operating At Spectran
TRAN together with our LCS or MCS soft- ware, you have to activate the UBBV-pream- plifier in the menu “RefOff” (by choosing the headword “UBBV12”) in order that the SPECTRAN is calibrated correctly! HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 8: Operating At External Devices
SMA cables and you can plug in any spectrum analyzer, oscilloscope, anten- na etc.. If your measurement unit or antenna is equipped with a N-input, you will need our optional SMA to N adapter as well. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 9: Operating At Hyperlog X Antennas
ATTENTION: Please leave always the UBBV-preamplifier connected to the antenna (as delivered) as every remo- val and re-assembly could wear out the SMS jacks and could cause dama- ges! HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 10: Operating At Pbs Probeset
UBBV-preamplifier with our SMA adapter according to instruction „5.0 Operating at external devices“. Thereafter you can connect directly the SMA cable of the PBS Probe Set to the SMA jack. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 11: Activating The Ubbv Preamplifier
Please pay attention to the instruction in section 9.0. If the UBBV-preamplifier is switched on, a red control LED on the upper side of the preamplifier lights up. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 12: Power Connection
All cables/equipment, which you want to connect to the external power supp- ly of the preamplifier, have to deliver DC of 12V. Please use a standard jack plug with a diameter of 3,5mm (inner pole PLUS, outer pole MINUS). HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 13: Reading Out The Calibration Data
10.0 Reading out the calibration data Every Aaronia UBBV-preamplifier is already individually calibrated in our factory. The corresponding calibration data are stored at an EEprom in the preamplifier. These data you can read out at any time via USB-interface of the preamplifier. -
Page 14: Warranty
10 years warranty on all models. We offer 10 years warranty for all our UBBV-preamplifiers (battery excluded). We promptly exchange defective units in a non-bureaucratic way. HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 15: Developer-Net, User Forum And More
- Free Firmware updates - Free PC Analyzer-Software (for MAC OS, Linux and Windows) - P-CODE Programme, examples and SPECTRAN TUNING - User Forum incl. FAQ - News about latest Aaronia products HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com... -
Page 16: Frequency Charts For Spectrum Analyzers & Antennas
13.0 Frequency charts for analyzers & antennas HW UBBV / © 2010-2013 Aaronia AG, D-54597 Euscheid, www.aaronia.com...
